Advanced Operation

In addition to editing its settings via the panel knobs and sliders, the GAIA SH-01 also allows you to edit the following
parameters.

Patch Parameters

COMMON
Parameter Range
LFO KEY TRIGGER OFF, ON
FILTER ENVELOPE
0–+63
VELOCITY SENS
LEVEL VELOCITY SENS 0–+63
PATCH TEMPO
5–300
PITCH BEND RANGE
0–24
DOWN
PITCH BEND RANGE UP 0–24
PORTAMENTO TIME 0–127
PATCH OCTAVE SHIFT -3–+3
ARPEGGIO VARIATION A1–H8
PAN -63–+63
PAN LFO DEPTH 0–127
Explanation
If this is on, the LFO cycle will be restarted when you
press a key.
The MODULATION LFO cannot be controlled with
this setting.
Specifies how the cutoff frequency will be affected
by keyboard dynamics.
This effect can be obtained only when KEYBOARD
VELOCITY (p. 51) is set to "REAL. "
Specifies how the volume will be affected by
keyboard dynamics.
This effect can be obtained only when KEYBOARD
VELOCITY (p. 51) is set to "REAL. "
Specifies the patch tempo.
This effect can be obtained only when CLOCK
SOURCE (p. 52) is set to "PATCH. "
Specifies the amount of pitch change that will occur
when the pitch bend/modulation lever is moved all
the way to the left.
Specifies the amount of pitch change that will occur
when the pitch bend/modulation lever is moved all
the way to the right.
Specifies the time over which the pitch will change
to the next note.
Sets the octave for the patch.
Specifies how the arpeggio will be sounded.
Set the panning of the tone. "-63" is far left, "0" is
center, and "+63" is far right.
Specifies the depth to which LFO will affect the pan.
Panel operation
Hold down the [CANCEL/SHIFT] button and press the LFO
[TEMPO SYNC] button.
Button lit: ON
Button unlit: OFF
Hold down the [CANCEL/SHIFT] button and turn the [CUTOFF]
knob.
Hold down the [CANCEL/SHIFT] button and turn the AMP
[LEVEL] knob.
1. Press the [TAP TEMPO] button four or more times at
quarter-note intervals of the desired tempo.
2. Hold down the [SHIFT] button and move the pitch bend/
modulation lever all the way to the left or right.
3. Hold down the OCTAVE [DOWN/-] button and press a key
(C2–C4).
4. Press the [CANCEL/SHIFT] button.
1. Hold down the [SHIFT] button and move the pitch bend/
modulation lever all the way to the left or right.
2. Hold down the OCTAVE [UP/+] button and press a key
(C2–C4).
3. Press the [CANCEL/SHIFT] button.
While holding down the [PORTAMENTO] button, press the
OCTAVE [UP/+] or OCTAVE [DOWN/-] button.
Hold down the [PORTAMENTO] button and press one of the
NUMBER [1]–NUMBER [8] buttons.
Hold down the [PORTAMENTO] button and move the LFO
[FADE TIME] slider.
1. Hold down the [CANCEL/SHIFT] button and press the
[PORTAMENTO] button.
2. Use any of the following three methods to set the
portamento time.
• Press one of the NUMBER [1]–NUMBER [8] buttons.
• Turn the EFFECTS [CONTROL 1] knob.
• Move the LFO [FADE TIME] slider
3. Press the [CANCEL/SHIFT] button.
Hold down the [CANCEL/SHIFT] button and press the OCTAVE
[UP/+] or OCTAVE [DOWN/-] button.
Hold down [ARPEGGIO] button, and use the [BANK] button and
NUMBER [1]–NUMBER [8] button to select a bank and variation.
1. Hold down [CANCEL/SHIFT] button, and press the
[ARPEGGIO] button.
2. Use the [BANK] button and NUMBER [1]–NUMBER [8]
button to select the bank and variation.
3. Press the [CANCEL/SHIFT] button.
Hold down the [CANCEL/SHIFT] button and turn the OSC
[DETUNE] knob.
Hold down the [CANCEL/SHIFT] button and move the LFO
[AMP DEPTH] slider.
