Roland GAIA Synthesizer SH-01 Owner's Manual page 46

OSC
Parameter Range
SAW, SQR, PULSE,
WAVE
TRI, SIN, NOISE,
SUPER SAW
VARIATION
PITCH -24–+24
DETUNE -50–+50
SYNC/RING
OFF, SYNC, RING
PWM 0–127
PW 0–127
A 0–127
D 0–127
ENV DEPTH
-63–+63
FILTER
Parameter Range
BYPASS, LPF, HPF,
MODE
BPF, PKG
SLOPE -12dB, -24dB
CUTOFF 0–127
RESONANCE 0–127
CUTOFF KEY FOLLOW -100–+100
A
0–127
D 0–127
S 0–127
R 0–127
ENV DEPTH
-63–+63
46
Explanation
Selects the waveform that is the basis of the sound.
You can select variations of the currently selected
WAVE.
Adjusts the pitch in semitone steps.
Adjusts the pitch in steps of one cent.
Selects how tone 1 and tone 2 will be com-
bined.
Specifies the amount (depth) of LFO applied to PW
(Pulse Width).
Specifies the pulse width.
Specifies the attack time of the pitch envelope.
Specifies the decay time of the pitch envelope.
Specifies the depth to which the envelope will
modulate the pitch.
Explanation
Selects the type of filter.
Specifies the slope of the filter.
Specifies the cutoff frequency.
Specifies the resonance.
Specifies how the cutoff frequency will be affected
by the keyboard position.
Specifies the attack time of the filter envelope.
Specifies the decay time of the filter envelope.
Specifies the sustain level of the filter envelope.
Specifies the release time of the filter envelope.
Specifies the depth to which the envelope will
modulate the filter.
Panel operation
Press the [WAVE] button a number of times to make your
selection.
There are three variations for each waveform, and each time
you switch the variation, the illumination of the [WAVE] button
will change as follows: unlit red
Turn the [PITCH] knob.
Turn the [DETUNE] knob.
Press the [MOD] button to choose.
Move the [PWM] slider.
Move the [PW] slider.
Move the [A] slider.
Move the [D] slider.
Move the [ENV DEPTH] slider.
Panel operation
Press the [MODE] button to choose.
Press the [SLOPE] button to choose.
Turn the [CUTOFF] knob.
Turn the [RESONANCE] knob.
Turn the [KEY FOLLOW] knob.
Move the [A] slider.
Move the [D] slider.
Move the [S] slider.
Move the [R] slider.
Move the [ENV DEPTH] slider.
green unlit ...
