2. Using a No. 2 Phillips screwdriver, replace the three screws securing the diskette
drive to the peripheral assembly.
3. Position the peripheral assembly into the chassis, aligning the three holes on the
assembly with the three screws on the chassis.
4. Slide the peripheral assembly forward until it stops.
5. Using a No. 2 Phillips screwdriver, tighten the three screws securing the
peripheral assembly to the chassis.
6. Connect the following:
Diskette drive data cable
Diskette drive power cable
Smart card reader power cable
Note – Ensure that the cable assembly connectors are properly oriented by aligning
the connector keys.
7. If you removed any PCI cards, reinstall them on the riser board.
See Section 8.4.2 "Replacing a PCI Card" on page 8-13.
8. Detach the wrist strap, replace the system cover, and power on the system as
described in Chapter 9 "Finishing Component Replacement."
7.2

Smart Card Reader

To remove and replace the smart card reader, proceed as follows.
7.2.1

Removing the Smart Card Reader

1. Power off the system, remove the system cover, and attach an antistatic wrist strap
as described in Chapter 5 "Preparing for Component Removal and Replacement."
Caution – Use proper ESD grounding techniques when handling components. Wear
an antistatic wrist strap and use an ESD-protected mat. Store ESD-sensitive
components in antistatic bags before placing them on any surface.
2. If any long PCI cards are installed, remove them from the riser board connectors.
See Section 8.4.1 "Removing a PCI Card" on page 8-12.
Chapter 7 Removing and Replacing Storage Devices 7-3
