The following code example shows the audio diagnostic output message.
CODE EXAMPLE 4-16
Enter (0-13 tests, 14 -Quit, 15 -Menu) ===> 10
TEST='audio_test'
SUBTEST='cs4231_test'
Codec_ID='8a'
Version_ID='a0'
SUBTEST='external_lpbk'
###OBDIAG_MFG_START###
TEST='audio_test'
STATUS='FAILED'
SUBTEST='external_lpbk'
ERRORS='1 '
TTF='505 '
SPEED='299.80 MHz'
PASSES='1 '
MESSAGE='Error: External Audio Test not run: Please set the mfg-
mode to sys-ext.'
Enter (0-13 tests, 14 -Quit, 15 -Menu) ===>
4.7.2.11
EIDE Diagnostic
To start the EIDE diagnostic, type
diagnostic validates both the EIDE chip and the IDE bus subsystem.
The following code example shows the EIDE diagnostic output message.
CODE EXAMPLE 4-17
Enter (0-13 tests, 14 -Quit, 15 -Menu) ===> 11
TEST='ide_test'
SUBTEST='probe-cmd-device'
SUBTEST='hd-and-cd-check'
Enter (0-13 tests, 14 -Quit, 15 -Menu) ===>
Audio Diagnostic Output Message
at the OBdiag Menu prompt. The EIDE
11
EIDE
Diagnostic
Output Message
Chapter 4
Troubleshooting Procedures
4-21
