Audio SoundsAndAlerts RingTone
Select the ring tone for incoming calls.
Requires user role: USER
Value space: <Marbles/IceCrystals/Polaris/Alert/Discreet/Fantasy/Jazz/
Nordic/Echo/Rhythmic>
Range: Select a tone from the list of ring tones.
Example: Audio SoundsAndAlerts RingTone: Jazz
Audio SoundsAndAlerts RingVolume
Sets the ring tone volume for an incoming call.
Requires user role: USER
Value space: <0..100>
Range: The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Volume 0 = Off.
Example: Audio SoundsAndAlerts RingVolume: 50
Audio Volume
Set the volume on the loudspeaker.
Requires user role: USER
Value space: <0..100>
Range: The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Value 0 = Off.
Example: Audio Volume: 70
D14635.0 6 Profile C90 and Codec C90 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings

The Cameras settings

Cameras PowerLine Frequency
Applies to cameras supporting PowerLine frequency anti-flickering, i.e PrecisionHD 1080p
cameras.
Requires user role: ADMIN
Value space: <Auto/50Hz/60Hz>
Example: Cameras PowerLine Frequency: Auto
Cameras Camera [1..7] Backlight
The backlight functionality compensates for light shining directly at the camera (usually the sun
entering the window) to avoid a too dark image from the room.
Requires user role: ADMIN
Value space: <On/Off>
Example: Cameras Camera 1 Backlight: Off
Cameras Camera [1..7] Brightness Mode
Set the camera brightness mode.
Requires user role: ADMIN
Value space: <Auto/Manual>
Example: Cameras Camera 1 Brightness Mode: Auto
Cameras Camera [1..7] Brightness Level
Set the brightness level. NOTE: Requires the Camera Brightness Mode to be set to Manual.
Requires user role: ADMIN
Value space: <1..31>
Example: Cameras Camera 1 Brightness Level: 1
38
Password protection
Auto: Set to Auto to enable power frequency auto detection in the camera.
50Hz: Set to 50 Hz.
60Hz: Set to 60 Hz.
On: Turn on the camera backlight.
Off: Turn off the camera backlight.
Auto: The camera brightness is automatically set by the system.
Manual: Enable manual control of the camera brightness, e.g. the level of the brightness level
setting will be used for the camera.
Range: Select a value from 1 to 31.
