Cisco TelePresence Codec C90 Administrator's Manual page 84

Cisco TelePresence System Codec C90 and Profile 65" Dual using C90
Contents Introduction
Codec C90, continued...
MULTISITE FEATURES*
4-way 1080p30 High Definition SIP/H.323 MultiSite
Full Individual audio and video transcoding
Individual layouts in MultiSite CP (Takes out SelfView)
H.323/SIP/VoIP in the same conference
Support for Presentation (H.239/BFCP) from any
participant at resolutions up to 1080p30/WUXGA
Best Impression (Automatic CP Layouts)
H.264, Encryption, Dual Stream from any site
IP Downspeeding
Dial in/Dial out
Additional telephone call (no license required)
Conference rates up to 10 Mbps
PROTOCOLS
H.323
SIP
EMBEDDED ENCRYPTION
H.323/SIP point-to-point and multipoint calls
Standards-based: H.235 v2 & v3 and AES
Automatic key generation and exchange
Supported in Dual Stream & MultiSite
IP NETWORK FEATURES
DNS lookup for service configuration
Differentiated Services (QoS)
IP adaptive bandwidth management (including flow
control)
Auto gatekeeper discovery
Dynamic playout and lip-sync buffering
H.245 DTMF tones in H.323
Date and Time support via NTP
Packet Loss based Downspeeding
URI Dialing
TCP/IP
DHCP
802.1x Network authentication
ClearPath
IPV6 NETWORK SUPPORT
Single call stack support for both H323 and SIP
Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP,
HTTPS, DNS, DiffServ
Support for both Static and Autoconfig (stateless
address auto configuration)
D14635.0 6 Profile C90 and Codec C90 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings
SECURITY FEATURES
Management via HTTPS and SSH
IP Administration Password
Menu Administration Password
Disable IP services
Network Settings protection
NETWORK INTERFACES
1 × LAN/Ethernet (RJ-45) 10/100/1000 Mbit
1 × LAN/Ethernet (RJ-45) interface to be used for the
touch user interface device only
OTHER INTERFACES
USB host for future usage
USB device for future usage
GPIO – General purpose Input/Output
PRECISIONHD CAMERA (1080P)
1/3" CMOS
12 × zoom
+15°/-25° tilt, +/- 90° pan
43.5° vertical field of view
72° horizontal field of view
Focus distance 0.3 m–infinity
1920 × 1080 pixels progressive @ 60fps
Other formats supported (configurable through Dip-
switch):
1920 × 1080@60 Hz (HDMI only)
1920 × 1080@50 Hz (HDMI only)
1920 × 1080@30 Hz
1920 × 1080@25 Hz
1280 × 720@60 Hz
1280 × 720@50 Hz
1280 × 720@30 Hz
1280 × 720@25 Hz
Automatic or manual focus/brightness/whitebalance
Far-end camera control
Daisy-chain support (Visca protocol camera)
Dual HDMI and HD-SDI output
Upside-down mounting with automatic flipping of
Password protection
SYSTEM MANAGEMENT
Support for the Cisco TelePresence Management Suite
Total management via embedded SNMP, Telnet, SSH,
XML, SOAP
Remote software upload: via web server, SCP, HTTP,
HTTPS
1 × RS-232 local control and diagnostics
Remote control and on-screen menu system
DIRECTORY SERVICES
Support for Local directories (My Contacts)
Corporate Directory
Unlimited entries using Server directory supporting
LDAP and H.350
Unlimited number for Corporate directory (through
Cisco TelePresence Management Suite)
Received Calls with Date and Time
Placed Calls with Date and Time
Missed Calls with Date and Time
POWER
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz
175 W max for codec and main camera
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STORAGE AND TRANSPORT TEMPERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Length: 17.36 in. / 44.1 cm
Height: 3.67 in. / 9.3 cm
Depth: 11.8 in. / 30 cm
Weight: 11.22 lbs / 5.1 kg
* Requires option
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A
listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the
property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco
and any other company.
February 2011
84
Administrator guide
Appendices Appendices Contact us
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN 60950-1
Directive 2004/108/EC (EMC Directive)
– Standard EN 55022, Class B
– Standard EN 55024
– Standard EN 61000-3-2/-3-3
USA
Approved according to UL 60950-1
Complies with FCC15B Class B.
Canada
Approved according to CAN/CSA C22.2 No. 60950-1
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
