Video Output HDMI [1, 3] Resolution
Select the preferred resolution for the monitor connected to the video output HDMI connector.
This will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_
50/1280_720_60/1920_1080_50/1920_1080_60/1280_768_60/1360_768_60/1366_768
_60/1600_1200_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with
the connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1920x1200@60p
Example: Video Output HDMI 1 Resolution: 1920_1080_60
Video Output DVI [2, 4] MonitorRole
The DVI monitor role describes what video stream will be shown on the monitor connected to
the video output DVI-I connector. Applicable only if the monitor configuration is set to dual or
quadruple.
Requires user role: ADMIN
Value space: <First/Second/PresentationOnly/Third/Fourth>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Third: Use for remote participants (only for quadruple monitor setup).
Fourth: Use for remote participants (only for quadruple monitor setup).
Example: Video Output DVI 4 MonitorRole: First
Video Output DVI [2, 4] OverscanLevel
Some TVs or other monitors may not display the whole image sent out on the systems video
output, but cuts the outer parts of the image. In this case this setting can be used to let the
system not use the outer parts of video resolution. Both the video and the OSD menu will be
scaled in this case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: Video Output DVI 2 OverscanLevel: None
D14635.0 6 Profile C90 and Codec C90 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
Video Output DVI [2, 4] Resolution
Select the preferred resolution for the monitor connected to the video output DVI-I connector.
This will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_
50/1280_720_60/1920_1080_50/1920_1080_60/1280_768_60/1360_768_60/1366_768
_60/1600_1200_60/1920_1200_60>
Example: Video Output DVI 2 Resolution: 1920_1080_60
Video Output Composite [5] MonitorRole
The Composite monitor role describes what video stream will be shown on the monitor
connected to the video output Composite connector. Applicable only if the monitor configuration
is set to dual or quadruple.
Requires user role: ADMIN
Value space: <First/Second/PresentationOnly/Third/Fourth>
Example: Video Output Composite 5 MonitorRole: First
Video Output Composite [5] OverscanLevel
Some TVs or other monitors may not display the whole image sent out on the systems video
output, but cuts the outer parts of the image. In this case this setting can be used to let the
system not use the outer parts of video resolution. Both the video and the OSD menu will be
scaled in this case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Example: Video Output Composite 5 OverscanLevel: None
66
Password protection
Auto: The system will automatically try to set the optimal resolution based on negotiation with
the connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1920x1200@60p
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Third: Use for remote participants (only for quadruple monitor setup).
Fourth: Use for remote participants (only for quadruple monitor setup).
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
