Time TimeFormat
Set the time format.
Requires user role: USER
Value space: <24H/12H>
24H: Set the time format to 24 hours.
12H: Set the time format to 12 hours (AM/PM).
Example: Time TimeFormat: 24H
Time DateFormat
Set the date format.
Requires user role: USER
Value space: <DD_MM_YY/MM_DD_YY/YY_MM_DD>
DD_MM_YY: The date January 30th 2010 will be displayed: 30.01.10
MM_DD_YY: The date January 30th 2010 will be displayed: 01.30.10
YY_MM_DD: The date January 30th 2010 will be displayed: 10.01.30
Example: Time DateFormat: DD_MM_YY
D14635.0 6 Profile C90 and Codec C90 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings

The Video settings

Video Input Source [1..5] Name
Enter a name for the video input source.
Requires user role: ADMIN
Value space: <S: 0, 50>
Example: Video Input Source 1 Name: ""
Video Input Source [1] Connector
Select which video input connector to be active on video input source 1.
Requires user role: ADMIN
Value space: <HDMI/HDSDI/YPbPr>
Example: Video Input Source 1 Connector: HDMI
Video Input Source [2] Connector
Select which video input connector to be active on video input source 2.
Requires user role: ADMIN
Value space: <HDMI/HDSDI/YPbPr>
Example: Video Input Source 2 Connector: HDMI
Video Input Source [3] Connector
Select which video input connector to be active on video input source 3.
Requires user role: ADMIN
Value space: <HDMI/HDSDI/DVI>
Example: Video Input Source 3 Connector: DVI
60
Password protection
Format: String with a maximum of 50 characters.
HDMI: Select HDMI when you want to use the HDMI 1 as input source 1.
HDSDI: Select HD-SDI when you want to use the HD-SDI 1 as input source 1.
YPbPr: Select YPbPr when you want to use the YPbPr 1 (Component) as input source 1.
Connect to the first row of Y, Pb and Pr connectors.
HDMI: Select HDMI when you want to use the HDMI 2 as input source 2.
HDSDI: Select HD-SDI when you want to use the HD-SDI 2 as input source 2.
YPbPr: Select YPbPr when you want to use the YPbPr 2 (Component) as input source 2.
Connect to the second row of Y, Pb and Pr connectors.
DVI: Select DVI-I when you want to use the DVI-I 3 as input source 3.
HDMI: Select HDMI when you want to use the HDMI 3 as input source 3.
HDSDI: Select HD-SDI when you want to use the HD-SDI 3 as input source 3.
