Standby WakeupAction
Define the camera position when leaving standby mode.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/
Preset8/Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/
RestoreCameraPosition/DefaultCameraPosition>
None: No action.
Preset1 to Preset15: When leaving standby the camera position will be set to the position
defined by the selected preset.
RestoreCameraPosition: When leaving standby the camera position will be set to the position it
had before entering standby.
DefaultCameraPosition: When leaving standby the camera position will be set to the factory
default position.
Example: Standby WakeupAction: RestoreCameraPosition
D14635.0 6 Profile C90 and Codec C90 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings

The SystemUnit settings

SystemUnit Name
Enter a System Name to define a name of the system unit. If the H.323 Alias ID is configured
on the system then this ID will be used instead of the system name. The system name will be
displayed:
Requires user role: ADMIN
Value space: <S: 0, 50>
Example: SystemUnit Name: "Meeting Room"
SystemUnit MenuLanguage
Select the language to be used in the menus on screen.
Requires user role: USER
Value space: <English/ChineseSimplified/ChineseTraditional/Czech/Danish/
Dutch/Finnish/French/German/Hungarian/Italian/Japanese/Korean/Norwegian/
Polish/PortugueseBrazilian/Russian/Spanish/SpanishLatin/Swedish/Turkish>
Example: SystemUnit MenuLanguage: English
SystemUnit ContactInfo Type
Describes which parameter to put in the status field in the upper left corner on the screen display.
The information can also be read with the command xStatus SystemUnit ContactInfo.
Requires user role: ADMIN
Value space: <Auto/None/IPv4/IPv6/H323Id/E164Alias/SipUri/SystemName>
Example: SystemUnit ContactInfo Type: Auto
58
Password protection
1) When the codec is acting as an SNMP Agent.
2) Towards a DHCP server.
Format: String with a maximum of 50 characters.
Auto: Shows the address which another system can dial to reach this system, depending on
the default call protocol and system registration.
None: Do not show any contact information.
IPv4: Shows the IPv4 address as the contact information.
IPv6: Shows the IPv6 address as the contact information.
H323Id: Shows the H323 ID as the contact information.
E164Alias: Shows the H323 E164 Alias as the contact information.
SipUri: Shows the SIP URI as the contact information.
SystemName: Shows the system name as the contact information.
