SiEN18-622
1. Open the suction grille
Slide both knobs simultaneously as shown and then pull
them downward.
(Do the same procedure for closing).
(Refer to Fig. 1)
(If chains are present. Unhook the chains.)
(Refer to Fig.2)
2. Remove the air filters.
Remove the air filters by pulling its cloth forward.
(Refer to Fig. 3)
3. Clean the air filter
Use a vacuum cleaner A) or wash the air filter with water B).
A) Using a vacuum cleaner
B) Washing with water
When the air filter is very
dirty, use soft brush and
neutral detergent.
Remove water and dry in the shade.
System Configuration
Fig. 1
Fig. 2
Fig 3
NOTE
• Do not wash the air conditioner with hot water of more than
50°C, as doing so may result in discoloration and/or
deformation.
• Do not expose it to fire, as doing so may result in burning.
4. Fix the air filter
Align the two hangers and push the air filter up. Confirm
that four hangers are fixed.
(Refer to Fig.4)
5. Close the suction grille.
Refer to item No. 1.
6. After turning on the power, press FILTER SIGN RESET
button.
The display " " (TIME TO CLEAN AIR FILTER)
vanishes.
How to clean air outlet, suction grille and outside
panels
• Clean with soft cloth.
• When it is difficult to remove stains, use water or neutral
detergent.
• Clean the suction grille when it is shut.
NOTE
• Do not use gasoline, benzine, thinner, polishing powder,
liquid insecticide. It may cause discoloring or warping.
• Do not let the indoor unit get wet. It may cause an electric
shock or a fire.
• Do not use water or air of 50°C or higher for cleaning air
filters and outside panels.
Start up after a long stop
Confirm the following
• Check that the air inlet and outlet are not blocked.
Remove any obstacle.
• Check if the earth is connected
Might there be a broken wire somewhere?
Contact your dealer if there are any problems.
Ceiling Mounted Cassette Type
