EasyCoder 3240 Printer Getting Started Guide

Loading Media for Self-Strip Printing

10. Unroll several inches of media and insert it between the two media guides
1-10
Use self-strip printing in applications where you want to apply labels to a
surface immediately. After printing a label, the printer prints out the label with
the backing removed. The rewinder hub collects the backing after passing over
the self-strip assist roller. The rewinder hub can hold the backing from an entire
roll of media.
Note: Attached to the media roll is a small label with a three-digit sensitivity number
printed on it. Make sure you save this label. You need this information to set the
correct media sensitivity number. Refer to "Setting the Media Sensitivity Number" in
Chapter 3 for more information.
Note: If you lift the printhead while printing with self-strip, you may not receive the
best performance from the Precision Print technology. If you must lift the printhead,
remove accumulated liner from the takeup hub before resuming print.
To load self-strip media
1. Open the printer.
2. Raise the printhead by rotating the head lift lever clockwise to release it.
3. Turn the supply roll retainer counterclockwise to release it and slide it to
the outer end of the supply roll post. Turn the supply roll retainer clockwise
to lock it in place.
4. Lift the media brake up and slide it towards the front of the printer until it
reaches its resting position.
5. Place the media roll on the supply roll post and position it firmly against
the printer.
6. Lift up on the media brake, slide it toward the back of the printer, and
lower it onto the media roll.
7. Turn the supply roll retainer counterclockwise and slide it up to the edge of
the media roll. Turn the supply roll retainer clockwise to secure.
Note: If you are using a narrow roll of media (less than 1 inch), insert the media
support between the roll of media and the supply roll retainer before you secure it
in place.
8. Unscrew the edge guide and slide it to the outer edge of the lower media
guide. Screw the edge guide in place.
9. Pull down on the lower media guide to access the media path.
and out the front of the printer. Release the lower media guide.
