P370/P470 Keyless RF Scanners Product Reference Guide
3. Plug the other end of the cable into the COM1 connector on the cradle.
COM1
Power port
Figure 1-1. Ports on the Cradle
4. Connect the power connector of the power supply into the Power port on the
cradle.
5. Connect the appropriate line cord to the power supply and into an AC receptacle.
6. The indicator light on the cradle blinks, signifying successful power-up.
Figure 1-2. Power Supply Port
7. Rotate the antenna to the vertical position.
1-4
