Page 1 DS6708 Digital Scanner Product Reference Guide...
Page 3 DS6708 Digital Scanner Product Reference Guide 72E-86039-01 Revision A October 2006...
Page 4 Technologies, Inc., intellectual property rights. An implied license only exists for equipment, circuits, and subsystems contained in Symbol products. Symbol, Spectrum One, and Spectrum24 are registered trademarks of Symbol Technologies, Inc. Bluetooth is a registered trademark of Bluetooth SIG. Microsoft, Windows and ActiveSync are either registered trademarks or trademarks of Microsoft Corporation.
Page 5: Revision History
Revision History Changes to the original manual are listed below: Change Date Description -01 Rev A 10/2006 Initial Release.
Page 6 DS6708 Digital Scanner Product Reference Guide...
Page 7: Table Of Contents
Setting Up the Digital Scanner ... 1-3 Installing the Interface Cable ... 1-3 Removing the Interface Cable ... 1-3 Connecting a Synapse Cable Interface (DS6708 0nly) ... 1-4 Connecting Power (if required) ... 1-4 Configuring the Digital Scanner ... 1-4 Mounting the Digital Scanner ...
Page 8 DS6708 Digital Scanner Product Reference Guide Chapter 3: Maintenance & Technical Specifications Introduction ... 3-1 Maintenance ... 3-1 Troubleshooting ... 3-2 Technical Specifications ... 3-4 Digital Scanner Signal Descriptions ... 3-6 Chapter 4: User Preferences & Miscellaneous Digital Scanner Options Introduction ...
Page 9 Chapter 6: USB Interface Introduction ... 6-1 Connecting a USB Interface ... 6-2 USB Parameter Defaults ... 6-3 USB Host Parameters ... 6-4 USB Device Type ... 6-4 USB Country Keyboard Types - Country Codes ... 6-5 USB Keystroke Delay ... 6-7 USB CAPS Lock Override ...
Page 10 DS6708 Digital Scanner Product Reference Guide Chapter 9: Wand Emulation Interface Introduction ... 9-1 Connecting Using Wand Emulation ... 9-2 Wand Emulation Parameter Defaults ... 9-3 Wand Emulation Host Parameters ... 9-4 Wand Emulation Host Types ... 9-4 Leading Margin (Quiet Zone) ... 9-5 Polarity ...
Page 11 Chapter 12: 123Scan Introduction ... 12-1 123Scan Parameter ... 12-2 Chapter 13: Symbologies Introduction ... 13-1 Scanning Sequence Examples ... 13-1 Errors While Scanning ... 13-2 Symbology Parameter Defaults ... 13-2 UPC/EAN ... 13-6 Enable/Disable UPC-A ... 13-6 Enable/Disable UPC-E ... 13-6 Enable/Disable UPC-E1 ...
Page 12 DS6708 Digital Scanner Product Reference Guide Enable/Disable Code 93 ... 13-27 Set Lengths for Code 93 ... 13-27 Code 11 ... 13-29 Code 11 ... 13-29 Set Lengths for Code 11 ... 13-29 Code 11 Check Digit Verification ... 13-31 Transmit Code 11 Check Digits ...
Page 13 Enable/Disable PDF417 ... 13-54 Enable/Disable MicroPDF417 ... 13-54 Code 128 Emulation ... 13-55 Data Matrix ... 13-56 Maxicode ... 13-56 QR Code ... 13-57 Redundancy Level ... 13-57 Redundancy Level 1 ... 13-57 Redundancy Level 2 ... 13-58 Redundancy Level 3 ... 13-58 Redundancy Level 4 ...
Page 14 DS6708 Digital Scanner Product Reference Guide Send Pause ... 14-27 Skip Ahead ... 14-28 Skip Back ... 14-29 Send Preset Value ... 14-31 Modify Data ... 14-31 Remove All Spaces ... 14-31 Crunch All Spaces ... 14-31 Stop Space Removal ... 14-32 Remove Leading Zeros ...
Page 15 Appendix D: Numeric Bar Codes Numeric Bar Codes ... D-1 Cancel ... D-2 Appendix E: ASCII Character Sets Glossary Index Table of Contents...
Page 16 DS6708 Digital Scanner Product Reference Guide...
Page 17: About This Guide
About This Guide Introduction The DS6708 Digital Scanner Product Reference Guide provides general instructions for setting up, operating, maintaining and troubleshooting the DS6708 digital scanner. The DS6708 premier digital decoder does not support imaging. For imaging features and NOTE parameters, refer to the DS6707 Digital Imager Scanner Product Reference Guide, p/n 72E-83978-xx.
Page 18: Notational Conventions
DS6708 Digital Scanner Product Reference Guide • Chapter 9, Wand Emulation Interface host when Wand Emulation communication is needed. • Chapter 10, Keyboard Wedge Interface digital scanner. • Chapter 11, Scanner Emulation Interface Scanner Emulation host. • Chapter 12, 123Scan describes the 123Scan PC-based scanner configuration tool, and provides the bar code to scan to communicate with the 123Scan program.
Page 19: Related Documents
Indicates Default Related Documents The DS6708 Quick Start Guide, p/n 72-83973-xx, provides general information for getting started with the DS6708 digital scanner, and includes basic set up and operation instructions. For the latest version of this guide and all Symbol guides, go to: http://www.symbol.com/manuals.
Page 20: Symbol Global Interaction Center
DS6708 Digital Scanner Product Reference Guide Symbol Global Interaction Center For service information, warranty information or technical assistance contact or call the Symbol Global Interaction Center in your region. For the most up-to-date contact information, visit: http://www.symbol.com/contactsupport. Country/Region United States Symbol Technologies, Inc.
Page 21 Country/Region Deutschland/ Symbol Technologies GmbH Germany Waldstrasse 66 D-63128 Dietzenbach, Germany Italia/Italy Symbol Technologies Italia S.R.L. Via Cristoforo Columbo, 49 20090 Trezzano S/N Navigilo Milano, Italy Latin America 2730 University Dr. Sales Support Coral Springs, FL 33065 USA México/Mexico Symbol Technologies Mexico Ltd.
Page 22 DS6708 Digital Scanner Product Reference Guide Country/Region South Africa Symbol Technologies Africa Inc. Block B2 Rutherford Estate 1 Scott Street Waverly 2090 Johannesburg Republic of South Africa España/Spain Symbol Technologies S.L. Avenida de Bruselas, 22 Edificio Sauce Alcobendas, Madrid 28108...
Page 23: Chapter 1 Getting Started
Getting Started Introduction The DS6708 Digital Scanner combines superior 1D and 2D omnidirectional bar code scanning and sub-second image capture and transfer to provide the best value in a digital scanner. Whether in hand-held mode or hands-free mode in a stand, the digital scanner ensures comfort and ease of use for extended periods of time.
Page 24: Supported Interfaces
1 - 2 DS6708 Digital Scanner Product Reference Guide Supported Interfaces The DS 6708 digital scanner supports: Keyboard Wedge connection to a host. The host interprets scanned data as keystrokes. This interface • supports the following international keyboards (for Windows® environment): North America, German, French, French Canadian, Spanish, Italian, Swedish, UK English, Portuguese-Brazilian, and Japanese.
Page 25: Setting Up The Digital Scanner
Setting Up the Digital Scanner Installing the Interface Cable Plug the interface cable modular connector into the cable interface port on the bottom of the scanner handle. (See Figure 1-2.) Gently tug the cable to ensure the connector is properly secured. Connect the other end of the interface cable to the host (see the specific host chapter for information on host connections).
Page 26: Connecting A Synapse Cable Interface (Ds6708 0Nly)
1 - 4 DS6708 Digital Scanner Product Reference Guide Connecting a Synapse Cable Interface (DS6708 0nly) Refer to the Synapse Interface Guide provided with the Synapse cable for detailed setup NOTE instructions Symbol’s Synapse Smart Cables enable interfacing to a variety of hosts. The Synapse cable has built-in intelligence to detect that host.
Page 27: Mounting The Digital Scanner
Mounting the Digital Scanner Desk Mount Use the optional desk mount for convenient and protective placement of the digital scanner on a flat surface. Simply place the mount on the surface. The rubber feet hold the mount securely in place when inserting and removing the digital scanner.
Page 28 1 - 6 DS6708 Digital Scanner Product Reference Guide For convenience, print this page and use the template below for mounting hole locations. Insert mounting screw Wall Mounting Template Figure 1-7 Insert mounting screw 2.98”...
Page 29: Chapter 2: Scanning
Chapter 2 Chapter 2 Scanning Introduction This chapter provides beeper and LED definitions, techniques involved in scanning bar codes, general instructions and tips about scanning, and decode zone diagrams. Beeper Parts Figure 2-8 Scan Window Trigger Scanning...
Page 30: Beeper Definitions
2 - 2 DS6708 Digital Scanner Product Reference Guide Beeper Definitions The digital scanner issues different beep sequences and patterns to indicate status. sequences that occur during both normal scanning and while programming the digital scanner. Beeper Definitions Table 2-1...
Page 31 Beeper Definitions (Continued) Table 2-1 Beeper Sequence Fast warble beep Aborting MPDF sequence. Low/high beeps Flushing an already empty MPDF buffer. ADF Programming: Normal Data Entry. Duration of tones are short. High/low beeps Enter another digit. Add leading zeros to the front if necessary. Low/low beeps Enter another alphabetic character or scan the End of Message bar code.
Page 32: Led Definitions
2 - 4 DS6708 Digital Scanner Product Reference Guide LED Definitions In addition to beep sequences, the digital scanner uses a two-color LED to indicate status. LED colors that display during scanning. Standard LED Definitions Table 2-2 No power is applied to the digital scanner, or the digital scanner is on and ready to scan.
Page 33: Aiming
Center the symbol in any orientation within the aiming pattern. Be sure the entire symbol is within the rectangular area formed by the brackets in the pattern. 1D bar code Linear bar code Symbol Aiming Pattern Centering Symbol in Aiming Pattern Figure 2-11 Hold the trigger until the digital scanner beeps, indicating the bar code is successfully decoded.
Page 34: Scanning In Hands-Free Mode
2 - 6 DS6708 Digital Scanner Product Reference Guide Scanning in Hands-Free Mode The optional Intellistand adds greater flexibility to scanning operation. When the digital scanner is seated in the stand’s “cup,” the digital scanner’s built-in sensor places the digital scanner in hands-free mode. When the digital scanner is removed from the stand it operates in its normal hand-held mode.
Page 35: Decode Zones
Top of scanner 5 mil Code 39 100% 13 mil UPC 10.1 15.2 20.3 DS6708 Digital Scanner Decode Zone for 1D Bar Codes Figure 2-14 Note: Typical performance at 68˚F (20˚C) on high quality symbols. Top of scanner 6.6 mil PDF417...
Page 36 2 - 8 DS6708 Digital Scanner Product Reference Guide...
Page 37: Chapter 3 Maintenance & Technical Specifications
Chapter 3 Chapter 3 Maintenance & Technical Specifications Introduction This chapter provides suggested scanner maintenance, troubleshooting, technical specifications, and signal descriptions (pinouts). Maintenance Cleaning the scan window is the only maintenance required. A dirty window can affect scanning accuracy. • Do not allow abrasive material to touch the window.
Page 38: Troubleshooting
3 - 2 DS6708 Digital Scanner Product Reference Guide Troubleshooting Troubleshooting Table 3-1 Problem The aiming pattern does not appear when pressing the trigger. Scanner emits short low/short medium/short high beep sequence (power-up beep sequence) more than once. Digital scanner emits aiming pattern, but does not decode the bar code.
Page 39 Troubleshooting (Continued) Table 3-1 Problem Digital scanner decodes bar code, but does not transmit the data to the host. Host displays scanned data incorrectly. Digital scanner emits high/high/high/low beeps when not in use. Digital scanner emits low/high beeps during programming. Digital scanner emits low/high/low/high beeps during programming.
Page 40: Technical Specifications
3 - 4 DS6708 Digital Scanner Product Reference Guide Troubleshooting (Continued) Table 3-1 Problem Digital scanner emits low/high/low beeps. Digital scanner emits a power-up beep after changing USB host type. Digital scanner emits one high beep when not in use.
Page 41 Technical Specifications (Continued) Table 3-2 Item Postal U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch MaxiCode, DataMatrix (ECC 200), and QR Code Nominal Working Distance 5 mil (Code 39): (SR - Standard Range focus) 13 mil (100% UPC/EAN):0.5 - 9.7 in. (1.3 - 24.6 cm) 20 mil (Code 39): PDF417 (10 Mil): Datamatrix (10 Mil):...
Page 42: Digital Scanner Signal Descriptions
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Bottom of digital scanner Cable interface port Pin 1 applies to the connectors on the DS6708 digital scanner and are for Keyboard RS-232 Wedge Reserved Reserved Reserved Power Power Power Ground Ground...
Page 43: Chapter 4: User Preferences & Miscellaneous Digital Scanner Options
Chapter 4 Chapter 4 User Preferences & Miscellaneous Digital Scanner Options Introduction If desired, program the digital scanner to perform various functions, or activate different features. This chapter describes each user preference feature and provides the programming bar codes necessary for selecting these features.
Page 44: Scanning Sequence Examples
4 - 2 DS6708 Digital Scanner Product Reference Guide Scanning Sequence Examples In most cases, scanning one bar code sets the parameter value. For example, to set the beeper tone to high, scan the High Frequency (beeper tone) bar code listed under issues a fast warble beep and the LED turns green, signifying a successful parameter entry.
Page 45 User Preferences Parameter Defaults (Continued) Table 4-4 Parameter Beep After Good Decode Miscellaneous Options Transmit Code ID Character Prefix Value Suffix 1 Value Suffix 2 Value Scan Data Transmission Format FN1 Substitution Values Transmit “No Read” Message Synapse Interface User Preferences & Miscellaneous Digital Scanner Options Paramete Default r Number...
Page 46: User Preferences
4 - 4 DS6708 Digital Scanner Product Reference Guide User Preferences Set Default Parameter Scan this bar code to return all parameters to the default values listed in Parameter Scanning Parameter # ECh To disable decoding of parameter bar codes, scan the Disable Parameter Scanning bar code below. Note that the Set Defaults parameter bar code can still be decoded.
Page 47: Beeper Tone
Beeper Tone Parameter # 91h To select a decode beep frequency (tone), scan the Low Frequency, Medium Frequency, or High Frequency bar code. Low Frequency (02h) High Frequency (00h) User Preferences & Miscellaneous Digital Scanner Options Medium Frequency (Optimum Setting) 4 - 5 (01h)
Page 48: Beeper Volume
4 - 6 DS6708 Digital Scanner Product Reference Guide Beeper Volume Parameter # 8Ch To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume bar code. Low Volume (02h) High Volume (00h) Power Mode Parameter # 80h This parameter determines whether or not power remains on after a decode attempt.
Page 49: Time Delay To Low Power Mode
Time Delay to Low Power Mode Parameter # 92h This parameter only applies when Power Mode is set to Reduced Power. NOTE This parameter sets the time the digital scanner remains active after decoding. The digital scanner wakes upon trigger pull or when the host attempts to communicate with the digital scanner. 1 Second (11h) 1 Minute...
Page 50: Trigger Mode
4 - 8 DS6708 Digital Scanner Product Reference Guide Time Delay to Low Power Mode (continued) 15 Minutes (2Bh) Trigger Mode Parameter # 8Ah Select one of the following trigger modes for the digital scanner: • Level - A trigger pull activates decode processing. Decode processing continues until the bar code is decoded, the trigger is released, or the Decode Session Timeout is reached.
Page 51: Picklist Mode
Trigger Mode (continued) Auto Aim (09h) Picklist Mode Parameter # F0h 92h Picklist mode enables the digital scanner to decode only bar codes that are aligned under the laser crosshair. Select one of the following picklist modes for the digital scanner: •...
Page 52: Decode Session Timeout
4 - 10 DS6708 Digital Scanner Product Reference Guide Decode Session Timeout Parameter # 88h This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. The default timeout is 9.9 seconds.
Page 53: Beep After Good Decode
User Preferences & Miscellaneous Digital Scanner Options 4 - 11 Beep After Good Decode Parameter # 38h Scan a bar code below to select whether or not the digital scanner beeps after a good decode. If selecting Do Not Beep After Good Decode, the beeper still operates during parameter menu scanning and to indicate error conditions.
Page 54: Miscellaneous Scanner Parameters
4 - 12 DS6708 Digital Scanner Product Reference Guide Miscellaneous Scanner Parameters Transmit Code ID Character Parameter # 2Dh A Code ID character identifies the code type of a scanned bar code. This is useful when the digital scanner is decoding more than one code type.
Page 55: Prefix/Suffix Values
Prefix/Suffix Values Key Category Parameter # P = 63h, S1 = 62h, S2 = 64h Decimal Value Parameter # P = 69h, S1 = 68h, S2 = 6Ah A prefix and/or one or two suffixes can be appended to scan data for use in data editing. To set a value for a prefix or suffix, scan a four-digit number (i.e., four bar codes from corresponds to that value.
Page 56: Scan Data Transmission Format
4 - 14 DS6708 Digital Scanner Product Reference Guide Scan Data Transmission Format Parameter # EBh To change the scan data format, scan one of the following eight bar codes corresponding to the desired format. If using this parameter do not use ADF rules to set the prefix/suffix...
Page 57: Fn1 Substitution Values
Scan Data Transmission Format (continued) <PREFIX> <DATA> <SUFFIX 2> (06h) FN1 Substitution Values Key Category Parameter # 67h Decimal Value Parameter # 6Dh The Wedge and USB HID Keyboard hosts support a FN1 Substitution feature. When enabled any FN1 character (0x1b) in an EAN128 bar code is substituted with a value. This value defaults to 7013 (Enter Key). When using host commands to set the FN1 substitution value, set the key category parameter to 1, then set the 3-digit keystroke value.
Page 58: Transmit "No Read" Message
4 - 16 DS6708 Digital Scanner Product Reference Guide Transmit “No Read” Message Parameter # 5Eh Scan a bar code below to select whether or not to transmit a No Read message. When enabled, the characters NR are transmitted when a bar code is not decoded. When disabled, if a symbol does not decode, nothing is sent to the host.
Page 59 User Preferences & Miscellaneous Digital Scanner Options 4 - 17 Synapse Interface (continued) Auxiliary Synapse Port Connection (32h) “Plug and Play” Synapse Connection (0Ah)
Page 60 4 - 18 DS6708 Digital Scanner Product Reference Guide...
Page 61: Chapter 5: Decoding Preferences
Chapter 5 Chapter 5 Decoding Preferences Introduction If desired, program the digital scanner to perform various functions, or activate different features. This chapter describes decoding preference features and provides the programming bar codes for selecting these features. The digital scanner ships with the settings shown in the (also see Appendix A, Standard Default Parameters default values suit requirements, programming is not necessary.
Page 62: Errors While Scanning
5 - 2 DS6708 Digital Scanner Product Reference Guide Errors While Scanning Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter. Decoding Preferences Parameter Defaults Table 5-5 lists the defaults for decoding preferences parameters. There are two ways to change the default values: •...
Page 63: Decoding Preferences
Decoding Preferences 5 - 3 Decoding Preferences The parameters in this chapter control bar code decoding characteristics. Decoding Illumination Parameter # F0h, 2Ah Selecting Enable Decoding Illumination causes the digital scanner to flash illumination to aid decoding. Select Disable Decoding Illumination to prevent the digital scanner from using decoding illumination. Enabling illumination usually results in superior images.
Page 64: Illumination Bank Control
5 - 4 DS6708 Digital Scanner Product Reference Guide Illumination Bank Control Parameter # F1h 3Bh Selecting an illumination bank control parameter allows the user to control the illumination banks on the scan engine. Full (0) (default): The full illumination system is enabled.
Page 65: Decode Aiming Pattern
Decode Aiming Pattern Parameter # F0h, 32h This parameter only applies when in Decode Mode. Select Enable Decode Aiming Pattern to project the aiming pattern during bar code capture, or Disable Decode Aiming Pattern to turn the aiming pattern off. With picklist enabled, the decode aiming pattern flashes even when the Decode Aiming NOTE Pattern is disabled.
Page 66 5 - 6 DS6708 Digital Scanner Product Reference Guide...
Page 67: Chapter 6 Usb Interface
Chapter 6 Chapter 6 USB Interface Introduction This chapter describes how to set up the digital scanner with a USB host. The digital scanner connects directly to a USB host, or a powered USB hub, and is powered by it. No additional power supply is required. Throughout the programming bar code menus, default values are indicated with asterisks ( Indicates Default Most computer monitors allow scanning the bar codes directly on the screen.
Page 68: Connecting A Usb Interface
6 - 2 DS6708 Digital Scanner Product Reference Guide Connecting a USB Interface USB Series A Connector USB Connection Figure 6-1 The digital scanner connects with USB-capable hosts including: • Desktop PCs and notebooks Apple™ iMac, G4, iBooks (North America only) IBM SurePOS terminals •...
Page 69: Usb Parameter Defaults
On first installation when using Windows, the software prompts to select or install the Human Interface Device driver. To install this driver, provided by Windows, click Next through all the choices and click Finished on the last choice. The digital scanner powers up during this installation. To modify any other parameter options, scan the appropriate bar codes in this chapter.
Page 70: Usb Host Parameters
6 - 4 DS6708 Digital Scanner Product Reference Guide USB Host Parameters USB Device Type Select the desired USB device type. When changing USB Device Types, the digital scanner automatically resets. The digital NOTE scanner issues the standard startup beep sequences.
Page 71: Usb Country Keyboard Types - Country Codes
USB Country Keyboard Types - Country Codes Scan the bar code corresponding to the keyboard type. This setting applies only to the USB HID Keyboard Emulation device. When changing USB country keyboard types the digital scanner automatically resets. The NOTE digital scanner issues the standard startup beep sequences.
Page 72 6 - 6 DS6708 Digital Scanner Product Reference Guide USB Country Keyboard Types - Country Codes (continued) Spanish Windows Italian Windows Swedish Windows UK English Windows Japanese Windows (ASCII) Portuguese-Brazilian Windows...
Page 73: Usb Keystroke Delay
USB Keystroke Delay This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan a bar code below to increase the delay when hosts require a slower transmission of data. No Delay Long Delay (40 msec) USB CAPS Lock Override This option applies only to the HID Keyboard Emulation device.
Page 74: Usb Ignore Unknown Characters
6 - 8 DS6708 Digital Scanner Product Reference Guide USB Ignore Unknown Characters This option applies only to the HID Keyboard Emulation device and IBM device. Unknown characters are characters the host does not recognize. When Send Bar Codes With Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound.
Page 75: Emulate Keypad With Leading Zero
Emulate Keypad with Leading Zero When enabled, character sequences sent over the numeric keypad are sent as ISO characters which have a leading zero. For example ASCII A would be sent as “ALT MAKE” 0 0 6 5 “ALT BREAK”. Disable Keypad Emulation with Leading Zero USB Keyboard FN 1 Substitution This option applies only to the USB HID Keyboard Emulation device.
Page 76: Function Key Mapping
6 - 10 DS6708 Digital Scanner Product Reference Guide Function Key Mapping ASCII values under 32 are normally sent as a control-key sequences (see parameter is enabled, the keys in bold are sent in place of the standard key mapping. Table entries that do not have a bold entry remain the same whether or not this parameter is enabled.
Page 77: Convert Case
USB Interface 6 - 11 Convert Case When enabled, the digital scanner converts all bar code data to the selected case. No Case Conversion Convert All to Upper Case Convert All to Lower Case...
Page 78: Ascii Character Set For Usb
6 - 12 DS6708 Digital Scanner Product Reference Guide ASCII Character Set for USB USB Prefix/Suffix Values Table 6-2 Full ASCII Code 39 Prefix/ Suffix Value Encode Char.acter 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010 1011...
Page 79 USB Prefix/Suffix Values (Continued) Table 6-2 Full ASCII Code 39 Prefix/ Suffix Value Encode Char.acter 1025 1026 1027 1028 1029 1030 1031 1032 Space 1033 1034 1035 1036 1037 1038 1039 1040 1041 1042 1043 1044 1045 1046 1047 1048 1049 1050 1051...
Page 80 6 - 14 DS6708 Digital Scanner Product Reference Guide USB Prefix/Suffix Values (Continued) Table 6-2 Full ASCII Code 39 Prefix/ Suffix Value Encode Char.acter 1053 1054 1055 1056 1057 1058 1059 1060 1061 1062 1063 1064 1065 1066 1067 1068...
Page 81 USB Prefix/Suffix Values (Continued) Table 6-2 Full ASCII Code 39 Prefix/ Suffix Value Encode Char.acter 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100 1101 1102 1103 1104 1105 1106 1107 1108...
Page 82 6 - 16 DS6708 Digital Scanner Product Reference Guide USB Prefix/Suffix Values (Continued) Table 6-2 Full ASCII Code 39 Prefix/ Suffix Value Encode Char.acter 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124...
Page 83 USB ALT Key Character Set Table 6-3 ALT Keys 2064 ALT 2 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E 2070 ALT F 2071 ALT G 2072 ALT H 2073 ALT I 2074 ALT J 2075 ALT K...
Page 84 6 - 18 DS6708 Digital Scanner Product Reference Guide USB GUI Key Character Set Table 6-4 GUI Key 3000 3048 3049 3050 3051 3052 3053 3054 3055 3056 3057 3065 3066 3067 3068 3069 3070 3071 3072 3073 3074 3075...
Page 85 USB GUI Key Character Set (Continued) Table 6-4 GUI Key 3080 GUI P 3081 GUI Q 3082 GUI R 3083 GUI S 3084 GUI T 3085 GUI U 3086 GUI V 3087 GUI W 3088 GUI X 3089 GUI Y 3090 GUI Z Note: GUI Shift Keys - The Apple™...
Page 86 6 - 20 DS6708 Digital Scanner Product Reference Guide USB F Key Character Set Table 6-5 F Keys 5001 5002 5003 5004 5005 5006 5007 5008 5009 5010 5011 5012 5013 5014 5015 5016 5017 5018 5019 5020 5021 5022...
Page 87 USB Numeric Keypad Character Set Table 6-6 Numeric Keypad 6042 6043 6044 undefined 6045 6046 6047 6048 6049 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock Keystroke USB Interface 6 - 21...
Page 88 6 - 22 DS6708 Digital Scanner Product Reference Guide USB Extended Keypad Character Set Table 6-7 Extended Keypad 7001 7002 7003 7004 7005 7006 7007 7008 7009 7010 7011 7012 7013 7014 7015 7016 7017 7018 Keystroke Break Delete PgUp...
Page 89: Introduction
Chapter 7 Chapter 7 RS-232 Interface Introduction This chapter describes how to set up the digital scanner with an RS-232 host. The RS-232 interface is used to connect the digital scanner to point-of-sale devices, host computers, or other devices with an available RS-232 port (e.g., com port).
Page 90: Connecting An Rs-232 Interface
7 - 2 DS6708 Digital Scanner Product Reference Guide Connecting an RS-232 Interface This connection is made directly from the digital scanner to the host computer. Serial Port Connector to Host RS-232 Direct Connection Figure 7-1 Interface cables vary depending on configuration. The connectors illustrated in NOTE are examples only.
Page 91: Rs-232 Parameter Defaults
RS-232 Parameter Defaults Table 7-1 lists the defaults for RS-232 host parameters. To change any option, scan the appropriate bar code(s) provided in the RS-232 Host Parameters section beginning on page 7-4. Appendix A, Standard Default Parameters NOTE and miscellaneous default parameters. RS-232 Host Default Table Table 7-1 Parameter...
Page 92: Rs-232 Host Parameters
7 - 4 DS6708 Digital Scanner Product Reference Guide RS-232 Host Parameters Various RS-232 hosts are set up with their own parameter default settings Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, OPOS/JPOS, Olivetti, or Omron sets the defaults listed below.
Page 93 RS-232 Host Parameters (continued) Selecting ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, OPOS/JPOS, Olivetti, or Omron enables the transmission of code ID characters listed in programmable and are separate from the Transmit Code ID feature. Do not enable the Transmit Code ID feature for these terminals.
Page 94: Host Types
7 - 6 DS6708 Digital Scanner Product Reference Guide RS-232 Host Types To select an RS-232 host interface, scan one of the following bar codes. Standard RS-232 ICL RS-232 Wincor-Nixdorf RS-232 Mode A Wincor-Nixdorf RS-232 Mode B Olivetti ORS4500 Omron Scanning Enable RS-232 (No Variant) activates the RS-232 driver, but does not change port settings (e.g.,...
Page 95: Baud Rate
RS-232 Host Types (continued) OPOS/JPOS Baud Rate Baud rate is the number of bits of data transmitted per second. Set the digital scanner's baud rate to match the baud rate setting of the host device. Otherwise, data may not reach the host device or may reach it in distorted form.
Page 96 7 - 8 DS6708 Digital Scanner Product Reference Guide Baud Rate (continued) Baud Rate 9600 Baud Rate 19,200 Baud Rate 38,400 Baud Rate 57,600 Baud Rate 115,200...
Page 97: Parity
Parity A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. • Select Odd parity and the parity bit value is set to 0 or 1, based on data, to ensure that an odd number of 1 bits are contained in the coded character.
Page 98: Stop Bit Select
7 - 10 DS6708 Digital Scanner Product Reference Guide Stop Bit Select The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. The number of stop bits selected (one or two) depends on the number the receiving terminal is programmed to accommodate.
Page 99: Check Receive Errors
Check Receive Errors Select whether or not the parity, framing, and overrun of received characters are checked. The parity value of received characters is verified against the parity parameter selected above. Check For Received Errors Hardware Handshaking The data interface consists of an RS-232 port designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS).
Page 100 7 - 12 DS6708 Digital Scanner Product Reference Guide Hardware Handshaking (continued) None: Scan the bar code below if no Hardware Handshaking is desired. • Standard RTS/CTS: Scan the bar code below to select Standard RTS/CTS Hardware Handshaking. • •...
Page 101: Software Handshaking
Hardware Handshaking (continued) RTS/CTS Option 3 Software Handshaking This parameter offers control of the data transmission process in addition to, or instead of, that offered by hardware handshaking. There are five options. If Software Handshaking and Hardware Handshaking are both enabled, Hardware Handshaking takes precedence.
Page 102 7 - 14 DS6708 Digital Scanner Product Reference Guide Software Handshaking (continued) XOFF is received during a transmission. Data transmission then stops after sending the current byte. When the digital scanner receives an XON character, it sends the rest of the data message. The digital scanner waits indefinitely for the XON.
Page 103: Host Serial Response Time-Out
Host Serial Response Time-out This parameter specifies how long the digital scanner waits for an ACK, NAK, or CTS before determining that a transmission error has occurred. This only applies when in one of the ACK/NAK Software Handshaking modes, or RTS/CTS Hardware Handshaking option. Minimum: 2 Sec Medium: 5 Sec Maximum: 9.9 Sec...
Page 104: Rts Line State
7 - 16 DS6708 Digital Scanner Product Reference Guide RTS Line State This parameter sets the idle state of the Serial Host RTS line. Scan a bar code below to select Low RTS or High RTS line state. Host: Low RTS Beep on <BEL>...
Page 105: Intercharacter Delay
RS-232 Interface 7 - 17 Intercharacter Delay This parameter specifies the intercharacter delay inserted between character transmissions. Minimum: 0 msec Low: 25 msec Medium: 50 msec High: 75 msec Maximum: 99 msec...
Page 106: Nixdorf Beep/Led Options
7 - 18 DS6708 Digital Scanner Product Reference Guide Nixdorf Beep/LED Options When Nixdorf Mode B is selected, this indicates when the digital scanner should beep and turn on its LED after a decode. Normal Operation (Beep/LED immediately after decode)
Page 107: Ascii Character Set For Rs-232
ASCII Character Set for RS-232 The values in Table 7-4 can be assigned as prefixes or suffixes for ASCII character data transmission. Prefix/Suffix Values Table 7-4 Prefix/Suffix Value Code 39 Encode Character 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010...
Page 108 7 - 20 DS6708 Digital Scanner Product Reference Guide Prefix/Suffix Values (Continued) Table 7-4 Prefix/Suffix Value Code 39 Encode Character 1026 1027 1028 1029 1030 1031 1032 Space 1033 1034 1035 1036 1037 1038 1039 1040 1041 1042 1043 1044...
Page 109 Prefix/Suffix Values (Continued) Table 7-4 Full ASCII Prefix/Suffix Value Code 39 Encode Character 1055 1056 1057 1058 1059 1060 1061 1062 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 RS-232 Interface 7 - 21...
Page 110 7 - 22 DS6708 Digital Scanner Product Reference Guide Prefix/Suffix Values (Continued) Table 7-4 Prefix/Suffix Value Code 39 Encode Character 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100 1101 1102 1103...
Page 111 Prefix/Suffix Values (Continued) Table 7-4 Full ASCII Prefix/Suffix Value Code 39 Encode Character 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 1127 7013 RS-232 Interface 7 - 23 ASCII Character Undefined ENTER...
Page 112 7 - 24 DS6708 Digital Scanner Product Reference Guide...
Page 113: Chapter 8: Ibm 468X / 469X Interface
Chapter 8 Chapter 8 IBM 468X / 469X Interface Introduction This chapter describes how to set up the digital scanner with an IBM 468X/469X host. Throughout the programming bar code menus, default values are indicated with asterisks ( Indicates Default Most computer monitors allow scanning the bar codes directly on the screen.
Page 114: Connecting To An Ibm 468X/469X Host
8 - 2 DS6708 Digital Scanner Product Reference Guide Connecting to an IBM 468X/469X Host This connection is made directly from the digital scanner to the host interface. Host Port Connector IBM Direct Connection Figure 8-2 Interface cables vary depending on configuration. The connectors illustrated in NOTE are examples only.
Page 115: Ibm Parameter Defaults
IBM Parameter Defaults Table 8-5 lists the defaults for IBM host parameters. To change any option, scan the appropriate bar code(s) provided in the Parameter Descriptions section beginning on page 8-4. Appendix A, Standard Default Parameters NOTE and miscellaneous default parameters. IBM Host Default Table Table 8-5 Parameter...
Page 116: Ibm 468X/469X Host Parameters
8 - 4 DS6708 Digital Scanner Product Reference Guide IBM 468X/469X Host Parameters Port Address This parameter sets the IBM 468X/469X port used. Scanning one of these bar codes enables the RS-485 interface on the digital scanner. NOTE None Selected...
Page 117: Convert Unknown To Code 39
IBM 468X / 469X Interface 8 - 5 Convert Unknown to Code 39 Scan a bar code below to enable or disable the conversion of unknown bar code type data to Code 39. Enable Convert Unknown to Code 39 Disable Convert Unknown to Code 39...
Page 118 8 - 6 DS6708 Digital Scanner Product Reference Guide...
Page 119: Chapter 9: Wand Emulation Interface
Chapter 9 Chapter 9 Wand Emulation Interface Introduction This chapter describes how to set up the digital scanner with a wand emulation host when Wand Emulation communication is needed. The digital scanner connects to an external wand decoder or to a decoder integrated in a mobile computer or Point-of-Sale (POS) terminal.
Page 120: Connecting Using Wand Emulation
9 - 2 DS6708 Digital Scanner Product Reference Guide Connecting Using Wand Emulation To perform Wand Emulation, connect the digital scanner to a mobile computer, or a controller which collects the wand data and interprets it for the host. Mobile Computer...
Page 121: Wand Emulation Parameter Defaults
Wand Emulation Parameter Defaults Table 9-6 lists the defaults for Wand Emulation host types. To change any option, scan the appropriate bar code(s) provided in Wand Emulation Host Parameters on page Appendix A, Standard Default Parameters NOTE and miscellaneous default parameters. Wand Emulation Default Table Table 9-6 Parameter...
Page 122: Wand Emulation Host Parameters
9 - 4 DS6708 Digital Scanner Product Reference Guide Wand Emulation Host Parameters Wand Emulation Host Types Select a Wand Emulation host by scanning one of the bar codes below. Symbol OmniLink Interface Controller Symbol PTC Terminal (Telxon) Symbol PDT Terminal (MSI)
Page 123: Leading Margin (Quiet Zone)
Leading Margin (Quiet Zone) Scan a bar code below to select a leading margin duration. A leading margin is the time that precedes the first bar of the scan, (in milliseconds). The minimum allowed value is 80 msec and the maximum is 250 msec. This parameter accommodates older wand decoders which cannot handle short leading margins.
Page 124: Polarity
9 - 6 DS6708 Digital Scanner Product Reference Guide Polarity Polarity determines how the digital scanner's Wand Emulation interface creates the Digitized Barcode Pattern (DBP). DBP is a digital signal that represents the scanned bar code. Different decoders expect the DBP to be in a certain format.
Page 125: Convert All Bar Codes To Code 39
Convert All Bar Codes to Code 39 By default, the Wand Emulation interface sends data to the attached host in the same symbology that was decoded. This can be a problem for customers with older systems that do not recognize newer symbologies (for example, RSS).
Page 126: Convert Code 39 To Full Ascii
9 - 8 DS6708 Digital Scanner Product Reference Guide Convert Code 39 to Full ASCII By default, any characters that do not have a corresponding character in the Code 39 symbology set are replaced by a space. If this parameter is enabled, the data sent to the wand Interface is encoded in Code 39 Full ASCII.
Page 127: Chapter 10 Keyboard Wedge Interface
Chapter 10 Chapter 10 Keyboard Wedge Interface Introduction This chapter describes how to set up a Keyboard Wedge interface with the digital scanner. With this interface, the digital scanner is connected between the keyboard and host computer, and translates bar code data into keystrokes.
Page 128: Connecting A Keyboard Wedge Interface
10 - 2 DS6708 Digital Scanner Product Reference Guide Connecting a Keyboard Wedge Interface Keyboard Connector Figure 10-1. Keyboard Wedge Connection with Y-cable To connect the Keyboard Wedge interface Y-cable: Interface cables vary depending on configuration. The connectors illustrated in NOTE are examples only.
Page 129: Keyboard Wedge Parameter Defaults
Keyboard Wedge Parameter Defaults Table 10-7 lists the defaults for Keyboard Wedge host parameters. To change any option, scan the appropriate bar code(s) in the Keyboard Wedge Host Parameters section beginning on page 10-4. Appendix A, Standard Default Parameters NOTE and miscellaneous default parameters.
Page 130: Keyboard Wedge Host Parameters
10 - 4 DS6708 Digital Scanner Product Reference Guide Keyboard Wedge Host Parameters Keyboard Wedge Host Types Select the Keyboard Wedge host by scanning one of the bar codes below. IBM PC/AT & IBM PC Compatibles IBM PS/2 (Model 30)
Page 131: Keyboard Wedge Country Types - Country Codes
Keyboard Wedge Country Types - Country Codes Scan the bar code corresponding to the keyboard type. If the keyboard type is not listed, see Numeric Keypad Emulation on page North American French Windows French Canadian Windows XP/2000 Keyboard Wedge Interface 10 - 5 10-8.
Page 132 10 - 6 DS6708 Digital Scanner Product Reference Guide Keyboard Wedge Country Types - Country Codes (continued) Italian Windows Swedish Windows UK English Windows Japanese Windows Portuguese-Brazilian Windows...
Page 133: Ignore Unknown Characters
Ignore Unknown Characters Unknown characters are characters the host does not recognize. When Send Bar Codes With Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound on the digital scanner. When Do Not Send Bar Codes With Unknown Characters is selected, bar code data is sent up to the first unknown character, then the digital scanner issues an error beep.
Page 134: Intra-Keystroke Delay
10 - 8 DS6708 Digital Scanner Product Reference Guide Intra-Keystroke Delay When enabled, an additional delay is inserted between each emulated key depression and release. This sets the Keystroke Delay parameter to a minimum of 5 msec as well. Enable...
Page 135: Caps Lock On
Caps Lock On When enabled, the digital scanner emulates keystrokes as if the Caps Lock key is always pressed. Enable Caps Lock On Caps Lock Override When enabled, on AT or AT Notebook hosts, the keyboard ignores the state of the Caps Lock key. Therefore, an ‘A’...
Page 136: Convert Wedge Data
10 - 10 DS6708 Digital Scanner Product Reference Guide Convert Wedge Data When enabled, the digital scanner converts all bar code data to the selected case. Convert to Upper Case No Convert Function Key Mapping ASCII values under 32 are normally sent as control key sequences (see parameter is enabled, the keys in bold are sent in place of the standard key mapping.
Page 137: Fn1 Substitution
FN1 Substitution When this is enabled, the digital scanner replaces FN1 characters in an EAN128 bar code with a keystroke chosen by the user (see FN1 Substitution on page Enable Send Make and Break When enabled, the scan codes for releasing a key are not sent. *Send Make and Break Scan Codes Keyboard Wedge Interface 10 - 11 10-11).
Page 138: Keyboard Maps
10 - 12 DS6708 Digital Scanner Product Reference Guide Keyboard Maps The following keyboard maps are provided for prefix/suffix keystroke parameters. To program the prefix/suffix values, see the bar codes on 7014 5001 5002 5003 5004 5005 7009 IBM PS2 Type Keyboard...
Page 139 5001 5002 5011 5003 5004 5005 5006 5007 5008 5009 5010 1048 5012 1046 (1048 if double key) NCR 7052 32-Key Figure 10-7 1068 1067 1065 1066 1075 1072 1074 1073 1079 1080 1082 1081 5002 5001 5011 5003 5004 5005 5006 5007...
Page 140: Ascii Character Set For Keyboard Wedge
10 - 14 DS6708 Digital Scanner Product Reference Guide ASCII Character Set for Keyboard Wedge Code 39 Full ASCII interprets the bar code special character ($ + % /) preceding a Code 39 NOTE character and assigns an ASCII character value to the pair. For example, when Code 39 Full ASCII is enabled and +B is scanned, it is interpreted as b, %J as ?, and %V as @.
Page 141 Keyboard Wedge ASCII Character Set (Continued) Table 10-8 Full ASCII ASCII Value Code 39 Encode Char.acter 1022 1023 1024 1025 1026 1027 1028 1029 1030 1031 1032 Space 1033 1034 1035 1036 1037 1038 1039 1040 1041 1042 1043 1044 1045 1046 1047...
Page 142 10 - 16 DS6708 Digital Scanner Product Reference Guide Keyboard Wedge ASCII Character Set (Continued) Table 10-8 Full ASCII ASCII Value Encode Char.acter 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 1061 1062 1063 1064 1065...
Page 143 Keyboard Wedge ASCII Character Set (Continued) Table 10-8 Full ASCII ASCII Value Code 39 Encode Char.acter 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100 1101 1102...
Page 144 10 - 18 DS6708 Digital Scanner Product Reference Guide Keyboard Wedge ASCII Character Set (Continued) Table 10-8 Full ASCII ASCII Value Encode Char.acter 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119...
Page 145 Keyboard Wedge ALT Key Character Set Table 10-9 ALT Keys 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E 2070 ALT F 2071 ALT G 2072 ALT H 2073 ALT I 2074 ALT J 2075 ALT K 2076...
Page 146 10 - 20 DS6708 Digital Scanner Product Reference Guide Keyboard Wedge GUI Key Character Set Table 10-10 GUI Keys 3000 3048 3049 3050 3051 3052 3053 3054 3055 3056 3057 3065 3066 3067 3068 3069 3070 3071 3072 3073 3074...
Page 147 Keyboard Wedge GUI Key Character Set (Continued) Table 10-10 GUI Keys 3084 GUI T 3085 GUI U 3086 GUI V 3087 GUI W 3088 GUI X 3089 GUI Y 3090 GUI Z Keyboard Wedge F Key Character Set Table 10-11 F Keys 5001 5002...
Page 148 10 - 22 DS6708 Digital Scanner Product Reference Guide Keyboard Wedge F Key Character Set (Continued) Table 10-11 F Keys 5021 5022 5023 5024 Keyboard Wedge Numeric Keypad Character Set Table 10-12 Numeric Keypad 6042 6043 6044 6045 6046 6047...
Page 149 Keyboard Wedge Extended Keypad Character Set (Continued) Table 10-13 Extended Keypad 7004 7005 Pg Dn 7006 Pause 7007 Scroll Lock 7008 Backspace 7009 7010 Print Screen 7011 Insert 7012 Home 7013 Enter 7014 Escape 7015 Up Arrow 7016 Dn Arrow 7017 Left Arrow 7018...
Page 150 10 - 24 DS6708 Digital Scanner Product Reference Guide...
Page 151: Chapter 11: Scanner Emulation Interface
Chapter 11 Chapter 11 Scanner Emulation Interface Introduction This chapter describes how to set up the digital scanner with a Scanner Emulation host. Use this mode when Scanner Emulation communication is needed. In this mode, the digital scanner connects to an external decoder or to a decoder integrated in a mobile computer or Point-of-Sale (POS) terminal.
Page 152: Connecting Using Scanner Emulation
11 - 2 DS6708 Digital Scanner Product Reference Guide Connecting Using Scanner Emulation To perform Scanner Emulation, connect the digital scanner to a mobile computer, or a controller which collects the data and interprets it for the host. Scanner Emulation Connection Figure 11-1 Interface cables vary depending on configuration.
Page 153: Scanner Emulation Parameter Defaults
Scanner Emulation Parameter Defaults Table 11-1 lists the defaults for the Scanner Emulation host. To change any option, scan the appropriate bar code(s) provided in the Scanner Emulation Host Parameters section beginning on page 11-4. Appendix A, Standard Default Parameters NOTE and miscellaneous default parameters.
Page 154: Scanner Emulation Host
11 - 4 DS6708 Digital Scanner Product Reference Guide Scanner Emulation Host Scan the bar code below to enable the Scanner Emulation host. Scanner Emulation Host Parameters Beep Style The Scanner Emulation host supports three beep styles. • Beep On Successful Transmit: The digital scanner beeps when the attached decoder issues the decode signal to the digital scanner, so the digital scanner and the attached decoder beep at the same time.
Page 155: Parameter Pass-Through
Parameter Pass-Through The Scanner Emulation host can process parameter bar code messages and send them to the attached decoder. In this way, customers using Symbol compliant decoders can control the behavior of the entire system by scanning the necessary parameters only once. For example, to enable D 2 of 5, scan the D 2 of 5 Enable parameter bar code.
Page 156: Module Width
11 - 6 DS6708 Digital Scanner Product Reference Guide Convert Newer Code Types (continued) When decoding these code types with this parameter disabled, the digital scanner issues Convert Error beeps and transmits no data. The amount of data in the scanned newer bar code type should not exceed that of the conversion code type.
Page 157: Convert All Bar Codes To Code 39
Convert All Bar Codes to Code 39 Scan a bar code below to enable or disable the conversion of all bar code data to Code 39. *Do Not Convert Bar Codes To Code 39 Code 39 Full ASCII Conversion By default, any characters that do not have a corresponding character in the Code 39 symbology set are replaced by a space.
Page 158: Transmission Timeout
11 - 8 DS6708 Digital Scanner Product Reference Guide Transmission Timeout The Scanner Emulation host transmits bar code data to the attached decoder and waits for the decoder to assert the Decode signal, indicating successful transmission. If, after a specified amount of time, the Decode signal is not asserted (indicating that the attached decoder has not successfully received the bar code data), the digital scanner issues transmit error beeps.
Page 159: Ignore Unknown Characters
Ignore Unknown Characters Unknown characters are characters the decoder does not recognize. When Ignore Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound. When Convert Error on Unknown Characters is selected, bar codes containing at least one unknown character are not sent to the decoder, and a convert error beep sounds.
Page 160: Check For Decode Led
11 - 10 DS6708 Digital Scanner Product Reference Guide Leading Margin (continued) 5 ms Leading Margin Check For Decode LED The attached decoder normally asserts the Decode line to signal to the Scanner Emulation host that it successfully decoded the transmitted bar code. Some decoders, however, do not assert the Decode signal. In this case, the digital scanner emits transmit error beeps to indicate that the bar code was not successfully transmitted.
Page 161: Chapter 12 123Scan
Chapter 12 Chapter 12 123Scan Introduction 123Scan is a Windows ® -based utility that programs the digital scanner with all parameters including Advanced Data Formatting (ADF) Rules. An ADF rule modifies bar code data before it is sent to the host to ensure compatibility between bar coded data and the host application.
Page 162: 123Scan Parameter
12 - 2 DS6708 Digital Scanner Product Reference Guide 123Scan Parameter To communicate with the 123Scan program, load 123Scan, included in the documentation CD-ROM, onto the host computer, and scan the bar code below. Refer to 123Scan instructions for programming the digital scanner.
Page 163: Chapter 13: Symbologies
Chapter 13 Chapter 13 Symbologies Introduction This chapter describes symbology features and provides the programming bar codes for selecting these features. Before programming, follow the instructions in To set feature values, scan a single bar code or a short bar code sequence. The settings are stored in non-volatile memory and are preserved even when the digital scanner is powered down.
Page 164: Errors While Scanning
13 - 2 DS6708 Digital Scanner Product Reference Guide Errors While Scanning Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter. Symbology Parameter Defaults Table 13-1 lists the defaults for all symbologies parameters. There are two ways to change the default values: Scan the appropriate bar codes in this guide.
Page 165 Parameter Defaults (Continued) Table 13-1 Parameter Convert UPC-E1 to A EAN-8/JAN-8 Extend UCC Coupon Extended Code Code 128 Code 128 UCC/EAN-128 ISBT 128 Code 39 Code 39 Trioptic Code 39 Convert Code 39 to Code 32 (Italian Pharmacy Code) Code 32 Prefix Set Length(s) for Code 39 Code 39 Check Digit Verification Transmit Code 39 Check Digit...
Page 166 13 - 4 DS6708 Digital Scanner Product Reference Guide Parameter Defaults (Continued) Table 13-1 Parameter Transmit I 2 of 5 Check Digit Convert I 2 of 5 to EAN 13 Discrete 2 of 5 (DTF) Discrete 2 of 5 Set Length(s) for D 2 of 5...
Page 167 Parameter Defaults (Continued) Table 13-1 Parameter Convert RSS to UPC/EAN Composite Composite CC-C Composite CC-A/B Composite TLC-39 UPC Composite Mode Composite Beep Mode UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes 2-D Symbologies PDF417 MicroPDF417 Code 128 Emulation Data Matrix Maxicode QR Code Symbology-Specific Security Levels...
Page 168: Upc/Ean
13 - 6 DS6708 Digital Scanner Product Reference Guide UPC/EAN Enable/Disable UPC-A Parameter # 01h To enable or disable UPC-A, scan the appropriate bar code below Enable UPC-A (01h) Enable/Disable UPC-E Parameter # 02h To enable or disable UPC-E, scan the appropriate bar code below...
Page 169: Enable/Disable Upc-E1
Enable/Disable UPC-E1 Parameter # 0Ch UPC-E1 is disabled by default. To enable or disable UPC-E1, scan the appropriate bar code below. UPC-E1 is not a UCC (Uniform Code Council) approved symbology. NOTE Enable UPC-E1 (01h) Enable/Disable EAN-8/JAN-8 Parameter # 04h To enable or disable EAN-8/JAN-8, scan the appropriate bar code below Enable EAN-8/JAN-8 (01h)
Page 170: Enable/Disable Ean-13/Jan-13
13 - 8 DS6708 Digital Scanner Product Reference Guide Enable/Disable EAN-13/JAN-13 Parameter # 03h To enable or disable EAN-13/JAN-13, scan the appropriate bar code below. Enable EAN-13/JAN-13 (01h) Enable/Disable Bookland EAN Parameter # 53h To enable or disable Bookland EAN, scan the appropriate bar code below.
Page 171: Decode Upc/Ean/Jan Supplementals
Decode UPC/EAN/JAN Supplementals Parameter # 10h Supplementals are bar codes appended according to specific format conventions (e.g., UPC A+2, UPC E+2, EAN 13+2). Six options are available. If Decode UPC/EAN/JAN Only With Supplementals is selected, UPC/EAN/JAN symbols without • supplementals are not decoded. •...
Page 172: Upc/Ean/Jan Supplemental Redundancy
13 - 10 DS6708 Digital Scanner Product Reference Guide Decode UPC/EAN/JAN Supplementals (continued) Enable 378/379 Supplemental Mode (04h) Enable Smart Supplemental Mode (03h) UPC/EAN/JAN Supplemental Redundancy Parameter # 50h With Autodiscriminate UPC/EAN/JAN Supplementals selected, this option adjusts the number of times a symbol without supplementals is decoded before transmission.
Page 173: Transmit Upc-A Check Digit
Transmit UPC-A Check Digit Parameter # 28h The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-A check digit. It is always verified to guarantee the integrity of the data.
Page 174: Transmit Upc-E1 Check Digit
13 - 12 DS6708 Digital Scanner Product Reference Guide Transmit UPC-E1 Check Digit Parameter # 2Ah The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-E1 check digit. It is always verified to guarantee the integrity of the data.
Page 175: Upc-A Preamble
UPC-A Preamble Parameter # 22h Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-A preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.
Page 176: Upc-E Preamble
13 - 14 DS6708 Digital Scanner Product Reference Guide UPC-E Preamble Parameter # 23h Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0”...
Page 177: Upc-E1 Preamble
UPC-E1 Preamble Parameter # 24h Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E1 preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.
Page 178: Convert Upc-E To Upc-A
13 - 16 DS6708 Digital Scanner Product Reference Guide Convert UPC-E to UPC-A Parameter # 25h Enable this to convert UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, the data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit).
Page 179: Ean-8/Jan-8 Extend
EAN-8/JAN-8 Extend Parameter # 27h When enabled, this parameter adds five leading zeros to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. When disabled, EAN-8 symbols are transmitted as is. Enable EAN/JAN Zero Extend (01h) UCC Coupon Extended Code Parameter # 55h When enabled, this parameter decodes UPC-A bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’, and UPC-A/EAN-128 Coupon Codes.
Page 180: Code 128
13 - 18 DS6708 Digital Scanner Product Reference Guide Code 128 Enable/Disable Code 128 Parameter # 08h To enable or disable Code 128, scan the appropriate bar code below. Enable Code 128 (01h) Enable/Disable UCC/EAN-128 Parameter # 0Eh To enable or disable UCC/EAN-128, scan the appropriate bar code below.
Page 181: Enable/Disable Isbt 128
Enable/Disable ISBT 128 Parameter # 54h ISBT 128 is a variant of Code 128 used in the blood bank industry. Scan a bar code below to enable or disable ISBT 128. If necessary, the host must perform concatenation of the ISBT data. Enable ISBT 128 (01h) Code 39...
Page 182: Enable/Disable Trioptic Code 39
13 - 20 DS6708 Digital Scanner Product Reference Guide Enable/Disable Trioptic Code 39 Parameter # 0Dh Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges. Trioptic Code 39 symbols always contain six characters. To enable or disable Trioptic Code 39, scan the appropriate bar code below.
Page 183: Code 32 Prefix
Code 32 Prefix Parameter # E7h Scan the appropriate bar code below to enable or disable adding the prefix character “A” to all Code 32 bar codes. Convert Code 39 to Code 32 must be enabled for this parameter to function. NOTE Enable Code 32 Prefix (01h)
Page 184 13 - 22 DS6708 Digital Scanner Product Reference Guide • Length Within Range - Select this option to decode a Code 39 symbol with a specific length range. Select lengths using numeric bar codes in decode Code 39 symbols containing between 4 and 12 characters, first scan Code 39 - Length Within Range.
Page 185: Code 39 Check Digit Verification
Code 39 Check Digit Verification Parameter # 30h When this feature is enabled, the digital scanner checks the integrity of all Code 39 symbols to verify that the data complies with specified check digit algorithm. Only Code 39 symbols which include a modulo 43 check digit are decoded.
Page 186: Code 39 Full Ascii Conversion
13 - 24 DS6708 Digital Scanner Product Reference Guide Code 39 Full ASCII Conversion Parameter # 11h Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set. To enable or disable Code 39 Full ASCII, scan the appropriate bar code below.
Page 187: Buffer Data
Code 39 Buffering - Scan & Store (continued) This feature affects Code 39 only. If selecting Buffer Code 39, we recommend configuring the digital scanner to decode Code 39 symbology only. Buffer Code 39 (Enable) (01h) While there is data in the transmission buffer, selecting Do Not Buffer Code 39 is not allowed. The buffer holds 200 bytes of information.
Page 188: Transmit Buffer
13 - 26 DS6708 Digital Scanner Product Reference Guide Transmit Buffer There are two methods to transmit the Code 39 buffer. Scan the Transmit Buffer bar code below. Only a start character, a plus (+), and a stop character. The digital scanner transmits and clears the buffer.
Page 189: Enable/Disable Code 93
Code 93 Enable/Disable Code 93 Parameter # 09h To enable or disable Code 93, scan the appropriate bar code below. Enable Code 93 (01h) Set Lengths for Code 93 Parameter # L1 = 1Ah, L2 = 1Bh The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.
Page 190 13 - 28 DS6708 Digital Scanner Product Reference Guide Set Lengths for Code 93 (continued) Code 93 - One Discrete Length Code 93 - Two Discrete Lengths Code 93 - Length Within Range Code 93 - Any Length...
Page 191: Set Lengths For Code 11
Code 11 Code 11 Parameter # 0Ah To enable or disable Code 11, scan the appropriate bar code below. Enable Code 11 (01h) Set Lengths for Code 11 Parameter # L1 = 1Ch, L2 = 1Dh The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.
Page 192 13 - 30 DS6708 Digital Scanner Product Reference Guide Set Lengths for Code 11 Code 11 - One Discrete Length Code 11 - Two Discrete Lengths Code 11 - Length Within Range Code 11 - Any Length...
Page 193: Code 11 Check Digit Verification
Code 11 Check Digit Verification Parameter # 34h This feature allows the digital scanner to check the integrity of all Code 11 symbols to verify that the data complies with the specified check digit algorithm. This selects the check digit mechanism for the decoded Code 11 bar code.
Page 194: Interleaved 2 Of 5 (Itf)
13 - 32 DS6708 Digital Scanner Product Reference Guide Interleaved 2 of 5 (ITF) Enable/Disable Interleaved 2 of 5 Parameter # 06h To enable or disable Interleaved 2 of 5, scan the appropriate bar code below, and select an Interleaved 2 of 5 length from the following pages.
Page 195 Symbologies 13 - 33 Set Lengths for Code 11 (continued) Due to the construction of the I 2 of 5 symbology, it is possible for a scan line covering only NOTE a portion of the code to be interpreted as a complete scan, yielding less data than is encoded in the bar code.
Page 196: I 2 Of 5 Check Digit Verification
13 - 34 DS6708 Digital Scanner Product Reference Guide I 2 of 5 Check Digit Verification Parameter # 31h When this feature is enabled, the digital scanner checks the integrity of all I 2 of 5 symbols to verify the data complies with either the specified Uniform Symbology Specification (USS), or the Optical Product Code Council (OPCC) check digit algorithm.
Page 197: Convert I 2 Of 5 To Ean-13
Convert I 2 of 5 to EAN-13 Parameter # 52h Enable this parameter to convert 14-character I 2 of 5 codes to EAN-13, and transmit to the host as EAN-13. To accomplish this, the I 2 of 5 code must be enabled, and the code must have a leading zero and a valid EAN-13 check digit.
Page 198: Set Lengths For Discrete 2 Of 5
13 - 36 DS6708 Digital Scanner Product Reference Guide Set Lengths for Discrete 2 of 5 Parameter # L1 = 14h, L2 = 15h The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.
Page 199 Symbologies 13 - 37 Set Lengths for Discrete 2 of 5 (continued) D 2 of 5 - One Discrete Length D 2 of 5 - Two Discrete Lengths D 2 of 5 - Length Within Range D 2 of 5 - Any Length...
Page 200: Codabar (Nw - 7)
13 - 38 DS6708 Digital Scanner Product Reference Guide Codabar (NW - 7) Enable/Disable Codabar Parameter # 07h To enable or disable Codabar, scan the appropriate bar code below. Enable Codabar (01h) Set Lengths for Codabar Parameter # L1 = 18h, L2 = 19h The length of a code refers to the number of characters (i.e., human readable characters), including check...
Page 201 Symbologies 13 - 39 Set Lengths for Codabar (continued) Any Length - Scan this option to decode Codabar symbols containing any number of characters within • the digital scanner capability. Codabar - One Discrete Length Codabar - Two Discrete Lengths Codabar - Length Within Range Codabar - Any Length...
Page 202: Clsi Editing
13 - 40 DS6708 Digital Scanner Product Reference Guide CLSI Editing Parameter # 36h When enabled, this parameter strips the start and stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Enable this feature if the host system requires this data format.
Page 203: Msi
Enable/Disable MSI Parameter # 0Bh To enable or disable MSI, scan the appropriate bar code below. Enable MSI (01h) Set Lengths for MSI Parameter # L1 = 1Eh, L2 = 1Fh The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.
Page 204 13 - 42 DS6708 Digital Scanner Product Reference Guide Set Lengths for MSI (continued) • Any Length - Scan this option to decode MSI symbols containing any number of characters within the digital scanner capability. Due to the construction of the MSI symbology, it is possible for a scan line covering only a...
Page 205: Msi Check Digits
MSI Check Digits Parameter # 32h With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits bar code to enable verification of the second check digit.
Page 206: Msi Check Digit Algorithm
13 - 44 DS6708 Digital Scanner Product Reference Guide MSI Check Digit Algorithm Parameter # 33h Two algorithms are possible for the verification of the second MSI check digit. Select the bar code below corresponding to the algorithm used to encode the check digit.
Page 207: Us Planet
US Planet Parameter # 5Ah To enable or disable US Planet, scan the appropriate bar code below. Enable US Planet (01h) UK Postal Parameter # 5Bh To enable or disable UK Postal, scan the appropriate bar code below. Enable UK Postal (01h) Symbologies 13 - 45 Disable US Planet...
Page 208: Transmit Uk Postal Check Digit
13 - 46 DS6708 Digital Scanner Product Reference Guide Transmit UK Postal Check Digit Parameter # 60h Select whether to transmit UK Postal data with or without the check digit. Transmit UK Postal Check Digit (01h) Japan Postal Parameter # F0h, 22h To enable or disable Japan Postal, scan the appropriate bar code below.
Page 209: Australian Postal
Australian Postal Parameter # F0h, 23h To enable or disable Australian Postal, scan the appropriate bar code below. Enable Australian Postal (01h) Dutch Postal Parameter # F0h, 46h To enable or disable Dutch Postal, scan the appropriate bar code below. Enable Dutch Postal (01h) Symbologies 13 - 47...
Page 210: Transmit Us Postal Check Digit
13 - 48 DS6708 Digital Scanner Product Reference Guide Transmit US Postal Check Digit Parameter # 5Fh Select whether to transmit US Postal data with or without the check digit. Transmit US Postal Check Digit (01h) Do Not Transmit US Postal Check Digit...
Page 211: Rss-14
RSS (Reduced Space Symbology) The variants of RSS are RSS 14, RSS Expanded, and RSS Limited. The limited and expanded versions have stacked variants. Scan the appropriate bar code below to enable or disable each variant of RSS. RSS-14 Parameter # F0h 52h Enable RSS 14 (01h) RSS Limited...
Page 212: Rss Expanded
13 - 50 DS6708 Digital Scanner Product Reference Guide RSS Expanded Parameter # F0h 54h Enable RSS Expanded (01h) Convert RSS to UPC/EAN Parameter # F0h, 8Dh This parameter only applies to RSS-14 and RSS Limited symbols not decoded as part of a Composite symbol.
Page 213: Composite
Composite Composite CC-C Parameter # F0h 55h Scan a bar code below to enable or disable Composite bar codes of type CC-C. Enable CC-C (01h) Composite CC-A/B Parameter # F0h 56h Scan a bar code below to enable or disable Composite bar codes of type CC-A/B. Enable CC-A/B (01h) Symbologies 13 - 51...
Page 214: Composite Tlc-39
13 - 52 DS6708 Digital Scanner Product Reference Guide Composite TLC-39 Parameter # F0h 73h Scan a bar code below to enable or disable Composite bar codes of type TLC-39. Enable TLC39 (01h) UPC Composite Mode Parameter # F0h 58h UPC symbols can be “linked”...
Page 215: Composite Beep Mode
Composite Beep Mode Parameter # F0h, 8Eh To select the number of decode beeps when a composite bar code is decoded, scan the appropriate bar code. Single Beep after both are decoded (00h) Double Beep after both are decoded (02h) UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes Parameter # F0h, ABh Select whether to enable or disable this mode.
Page 216: 2D Symbologies
13 - 54 DS6708 Digital Scanner Product Reference Guide 2D Symbologies Enable/Disable PDF417 Parameter # 0Fh To enable or disable PDF417, scan the appropriate bar code below. Enable PDF417 (01h) Enable/Disable MicroPDF417 Parameter # E3h To enable or disable MicroPDF417, scan the appropriate bar code below.
Page 217: Code 128 Emulation
Code 128 Emulation Parameter # 7Bh When this parameter is enabled, the scanner transmits data from certain MicroPDF417 symbols as if it was encoded in Code 128 symbols. Transmit AIM Symbology Identifiers must be enabled for this parameter to work. If Code 128 Emulation is enabled, these MicroPDF417 symbols are transmitted with one of the following prefixes: if the first codeword is 903-907, 912, 914, 915...
Page 218: Data Matrix
13 - 56 DS6708 Digital Scanner Product Reference Guide Data Matrix Parameter # F0h, 24h To enable or disable Data Matrix, scan the appropriate bar code below. Enable Data Matrix (01h) Maxicode Parameter # F0h, 26h To enable or disable Maxicode, scan the appropriate bar code below.
Page 219: Qr Code
QR Code Parameter # F0h,25h To enable or disable QR Code, scan the appropriate bar code below. Enable QR Code (01h) Redundancy Level Parameter # 4Eh The digital scanner offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality.
Page 220: Redundancy Level 2
13 - 58 DS6708 Digital Scanner Product Reference Guide Redundancy Level 2 The following code types must be successfully read twice before being decoded: Redundancy Level 2 Codes Table 13-3 Code Type Redundancy Level 3 Code types other than the following must be successfully read twice before being decoded. The following...
Page 221 Redundancy Level (continued) Redundancy Level 1 (01h) Redundancy Level 3 (03h) Symbologies 13 - 59 Redundancy Level 2 (02h) Redundancy Level 4 (04h)
Page 222: Security Level
13 - 60 DS6708 Digital Scanner Product Reference Guide Security Level Parameter # 4Dh The digital scanner offers four levels of decode security for delta bar codes, which include the Code 128 family, UPC/EAN, and Code 93. Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and digital scanner aggressiveness, so choose only that level of security necessary for any given application.
Page 223: Intercharacter Gap Size
Intercharacter Gap Size Parameter # F0h, 7Dh The Code 39 and Codabar symbologies have an intercharacter gap that is typically quite small. Due to various bar code-printing technologies, this gap can grow larger than the maximum size allowed, preventing the digital scanner from decoding the symbol.
Page 224: Macro Pdf Features
13 - 62 DS6708 Digital Scanner Product Reference Guide Macro PDF Features Macro PDF is a special feature for concatenating multiple PDF symbols into one file. The digital scanner can decode symbols that are encoded with this feature, and can store more than 64 Kb of decoded data stored in up to 50 MacroPDF symbols.
Page 225: Chapter 14 Advanced Data Formatting
Chapter 14 Chapter 14 Advanced Data Formatting Introduction Advanced Data Formatting (ADF) is a means of customizing data before transmission to the host device. Scan data can be edited to suit particular requirements. ADF can be implemented through scanning a related series of bar codes, which begin on installing the 123Scan utility (see programmed with Advanced Data Formatting (ADF) Rules.
Page 226: Using Adf Bar Codes
14 - 2 DS6708 Digital Scanner Product Reference Guide Using ADF Bar Codes When programming a rule, make sure the rule is logically correct. Plan ahead before scanning. To program each data formatting rule: Start the Rule. Scan the •...
Page 227: Rule 1: The Code 128 Scanning Rule
Rule 1: The Code 128 Scanning Rule Step Bar Code Begin New Rule Code 128 Send next 5 characters Send <CTRL M> Send next 5 characters Send <CTRL P> Send next 2 characters Send <CTRL D> Save Rule Rule 2: The UPC Scanning Rule Step Bar Code Begin New Rule...
Page 228: Rules Hierarchy (In Bar Codes)
14 - 4 DS6708 Digital Scanner Product Reference Guide But, when there is a sale, send only the following: 24 (class key) 56712437 (stock key) and the cashier will key the price manually. To implement this, first enter an ADF rule that applies to the normal situation, such as: Scan Rule Belongs to Set 1.
Page 229: Default Rules
And the SECOND rule states: When scanning a Code 128 bar code of length 12, send the first four characters, then send the ENTER key, then send all remaining data. If a Code 128 bar code of length 12 were scanned, the THIRD rule would be in effect. The SECOND rule would appear to not function.
Page 230: Save Rule
14 - 6 DS6708 Digital Scanner Product Reference Guide Save Rule Scan the bar code below to save the rule. Erase Use these bar codes to erase criteria, actions, or rules. Erase Criteria And Start Again Erase Previously Saved Rule Quit Entering Rules Scan the bar code below to quit entering rules.
Page 231: Disable Rule Set
Disable Rule Set Use these bar codes to disable rule sets. Disable Rule Set 1 Disable Rule Set 3 Disable All Rule Sets Advanced Data Formatting 14 - 7 Disable Rule Set 2 Disable Rule Set 4...
Page 232: Criteria
14 - 8 DS6708 Digital Scanner Product Reference Guide Criteria Code Types Select any number of code types to be affected. All selected codes must be scanned in succession, prior to selecting other criteria. To select all code types, do not scan any code type.
Page 233 Advanced Data Formatting 14 - 9 Code Types (continued) IATA 2 OF 5 I 2 OF 5 Code 93 UPC-A UPC-E EAN-8 EAN-13...
Page 234 14 - 10 DS6708 Digital Scanner Product Reference Guide Code Types (continued) UCC/EAN 128 UPC-E1 Bookland EAN Trioptic Code 39 Code 11 Code 32...
Page 235 Advanced Data Formatting 14 - 11 Code Types (continued) ISBT 128 Coupon Code US Postnet US Planet UK Postal Japan Postal Australian Postal...
Page 236 14 - 12 DS6708 Digital Scanner Product Reference Guide Code Types (continued) Dutch Postal PDF417 MicroPDF Macro PDF Macro MicroPDF MaxiCode Datamatrix...
Page 237 Advanced Data Formatting 14 - 13 Code Types (continued) QR Code TLC 39 UPC/EAN Composites RSS and EAN128 Composites When selecting composite bar codes, enable AIM IDs if parsing UPC or EAN composite data, NOTE or data from an application that uses symbol separators.
Page 238: Code Lengths
14 - 14 DS6708 Digital Scanner Product Reference Guide Code Lengths Define the number of characters the selected code type must contain. Do not select any code length to select code types of any length. Scan these bar codes to define the number of characters the selected code types must contain. Select one length per rule only.
Page 239 Code Lengths (continued) 7 Characters 9 Characters 11 Characters 13 Characters Advanced Data Formatting 14 - 15 8 Characters 10 Characters 12 Characters...
Page 240 14 - 16 DS6708 Digital Scanner Product Reference Guide Code Lengths (continued) 15 Characters 17 Characters 19 Characters 14 Characters 16 Characters 18 Characters 20 Characters...
Page 241 Code Lengths (continued) 21 Characters 23 Characters 25 Characters 27 Characters Advanced Data Formatting 14 - 17 22 Characters 24 Characters 26 Characters...
Page 242: Message Containing A Specific Data String
14 - 18 DS6708 Digital Scanner Product Reference Guide Code Lengths (continued) 29 Characters Message Containing A Specific Data String Use this feature to select whether the formatting affects data that begins with a specific character or data string, or contains a specific character or data string.
Page 243 Specific String, Any Location Scan the bar code below, then, using the representing the position (use a leading “zero” if necessary). Then scan the desired character or characters (up to a total of 8) on the Alphanumeric Keyboard beginning on page bar code on page 14-95.
Page 244: Numeric Keypad
14 - 20 DS6708 Digital Scanner Product Reference Guide Numeric Keypad Bar codes on this page should not be confused with those on the alphanumeric keyboard.
Page 245 Advanced Data Formatting 14 - 21 Numeric Keypad (continued) Cancel...
Page 246: Rule Belongs To Set
14 - 22 DS6708 Digital Scanner Product Reference Guide Rule Belongs To Set Select the set a rule belongs to. (There are four possible rule sets.) See more information about rule sets. Scan a bar code below to select which set a rule belongs to.
Page 247: Actions
Actions Select how to format the data for transmission. Send Data Send all data that remains, send all data up to a specific character selected from the beginning on page 14-86, or send the next N characters. N = any number from 1 to 254 selected from the Alphanumeric Keyboard beginning on page Send Data Up To Character Send Next Character...
Page 248 14 - 24 DS6708 Digital Scanner Product Reference Guide Send Data (continued) Send Next 5 Characters Send Next 7 Characters Send Next 9 Characters Send Next 11 Characters Send Next 6 Characters Send Next 8 Characters Send Next 10 Characters...
Page 249 Send Data (continued) Send Next 13 Characters Send Next 15 Characters Send Next 17 Characters Advanced Data Formatting 14 - 25 Send Next 12 Characters Send Next 14 Characters Send Next 16 Characters Send Next 18 Characters...
Page 250: Setup Field(S)
14 - 26 DS6708 Digital Scanner Product Reference Guide Send Data (continued) Send Next 19 Characters Setup Field(s) Setup Field(s) Definitions Table 14-1 Parameter Move Cursor Move Cursor To a Character Scan the printable ASCII character from the on page after the matching character.
Page 251: Move Cursor
Advanced Data Formatting 14 - 27 Move Cursor Scan a bar code below to move the cursor in relation to a specified character. Then enter a character by scanning a bar code from the Alphanumeric Keyboard beginning on page 14-86. If there is no match when the rule is interpreted and the rule fails, the next rule is checked.
Page 252: Skip Ahead
14 - 28 DS6708 Digital Scanner Product Reference Guide Skip Ahead Use the following bar codes to skip ahead characters. Skip Ahead 1 Character Skip Ahead 3 Characters Skip Ahead 5 Characters Skip Ahead 7 Characters Skip Ahead 2 Characters...
Page 253: Skip Back
Advanced Data Formatting 14 - 29 Skip Ahead (continued) Skip Ahead 8 Characters Skip Ahead 9 Characters Skip Ahead 10 Characters Skip Back Use the following bar codes to skip back characters. Skip Back 1 Character Skip Back 2 Characters Skip Back 3 Characters...
Page 254 14 - 30 DS6708 Digital Scanner Product Reference Guide Skip Back (continued) Skip Back 5 Characters Skip Back 7 Characters Skip Back 9 Characters Skip Back 4 Characters Skip Back 6 Characters Skip Back 8 Characters Skip Back 10 Characters...
Page 255: Send Preset Value
Advanced Data Formatting 14 - 31 Send Preset Value Use these bar codes to send preset values. These values must be set using the Scan Prefix and Scan Suffix page 4-13 bar codes on Send Prefix Send Suffix Modify Data Modify data in the ways listed.
Page 256: Stop Space Removal
14 - 32 DS6708 Digital Scanner Product Reference Guide Stop Space Removal Scan the bar code below to disable space removal. Stop Space Removal Remove Leading Zeros Scan the bar code below to remove all leading zeros. Remove Leading Zeros Stop Zero Removal Scan the bar code below to disable the removal of zeros.
Page 257: Pad Data With Spaces
Pad Data with Spaces To pad data to the left, scan the bar code containing the desired number of spaces. This parameter is activated by Send commands. Pad Spaces To Length 1 Pad Spaces To Length 3 Pad Spaces To Length 5 Pad Spaces To Length 7 Advanced Data Formatting 14 - 33 Pad Spaces To Length 2...
Page 258 14 - 34 DS6708 Digital Scanner Product Reference Guide Pad Data with Spaces (continued) Pad Spaces To Length 8 Pad Spaces To Length 9 Pad Spaces To Length 10 Pad Spaces To Length 11 Pad Spaces To Length 12 Pad Spaces To Length 13...
Page 259 Pad Data with Spaces (continued) Pad Spaces To Length 15 Pad Spaces To Length 17 Pad Spaces To Length 19 Pad Spaces To Length 21 Advanced Data Formatting 14 - 35 Pad Spaces To Length 16 Pad Spaces To Length 18 Pad Spaces To Length 20...
Page 260 14 - 36 DS6708 Digital Scanner Product Reference Guide Pad Data with Spaces (continued) Pad Spaces To Length 23 Pad Spaces To Length 25 Pad Spaces To Length 27 Pad Spaces To Length 22 Pad Spaces To Length 24 Pad Spaces To Length 26...
Page 261: Pad Data With Zeros
Pad Data with Spaces (continued) Pad Spaces To Length 29 Stop Pad Spaces Pad Data with Zeros To pad data to the left, scan the bar code containing the desired number of zeros. This parameter is activated by Send commands. Pad Zeros To Length 1 Pad Zeros To Length 3 Advanced Data Formatting 14 - 37...
Page 262 14 - 38 DS6708 Digital Scanner Product Reference Guide Pad Data with Zeros (continued) Pad Zeros To Length 5 Pad Zeros To Length 7 Pad Zeros To Length 9 Pad Zeros To Length 4 Pad Zeros To Length 6 Pad Zeros To Length 8...
Page 263 Pad Data with Zeros (continued) Pad Zeros To Length 11 Pad Zeros To Length 13 Pad Zeros To Length 15 Pad Zeros To Length 17 Advanced Data Formatting 14 - 39 Pad Zeros To Length 12 Pad Zeros To Length 14 Pad Zeros To Length 16...
Page 264 14 - 40 DS6708 Digital Scanner Product Reference Guide Pad Data with Zeros (continued) Pad Zeros To Length 19 Pad Zeros To Length 21 Pad Zeros To Length 23 Pad Zeros To Length 18 Pad Zeros To Length 20 Pad Zeros To Length 22...
Page 265 Pad Data with Zeros (continued) Pad Zeros To Length 25 Pad Zeros To Length 27 Pad Zeros To Length 29 Stop Pad Zeros Advanced Data Formatting 14 - 41 Pad Zeros To Length 26 Pad Zeros To Length 28 Pad Zeros To Length 30...
Page 266: Beeps
14 - 42 DS6708 Digital Scanner Product Reference Guide Beeps Select a beep sequence for each ADF rule. Beep Once Beep Three Times Send Keystroke (Control Characters and Keyboard Characters) Control Characters Scan the “Send __” bar code for the keystroke to send...
Page 267 Control Characters (continued) Send Control D Send Control F Send Control H Advanced Data Formatting 14 - 43 Send Control C Send Control E Send Control G Send Control I...
Page 268 14 - 44 DS6708 Digital Scanner Product Reference Guide Control Characters (continued) Send Control J Send Control L Send Control N Send Control P Send Control K Send Control M Send Control O...
Page 269 Control Characters (continued) Send Control R Send Control T Send Control V Advanced Data Formatting 14 - 45 Send Control Q Send Control S Send Control U Send Control W...
Page 270 14 - 46 DS6708 Digital Scanner Product Reference Guide Control Characters (continued) Send Control X Send Control Z Send Control \ Send Control Y Send Control [ Send Control ]...
Page 271: Keyboard Characters
Advanced Data Formatting 14 - 47 Control Characters (continued) Send Control 6 Send Control - Keyboard Characters Scan the “Send __” bar code for the keyboard characters to send. Send Space Send ! Send “ Send #...
Page 272 14 - 48 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send $ Send % Send & Send ‘ Send ( Send ) Send *...
Page 273 Keyboard Characters (continued) Send , Send . Send 0 Advanced Data Formatting 14 - 49 Send + Send - Send / Send 1...
Page 274 14 - 50 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send 2 Send 4 Send 6 Send 8 Send 3 Send 5 Send 7...
Page 275 Keyboard Characters (continued) Send : Send < Send > Advanced Data Formatting 14 - 51 Send 9 Send ; Send = Send ?
Page 276 14 - 52 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send @ Send B Send D Send F Send A Send C Send E...
Page 277 Keyboard Characters (continued) Send H Send J Send L Advanced Data Formatting 14 - 53 Send G Send I Send K Send M...
Page 278 14 - 54 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send N Send P Send R Send T Send O Send Q Send S...
Page 279 Keyboard Characters (continued) Send V Send X Send Z Advanced Data Formatting 14 - 55 Send U Send W Send Y Send [...
Page 280 14 - 56 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send \ Send ^ Send ` Send b Send ] Send _ Send a...
Page 281 Keyboard Characters (continued) Send d Send f Send h Advanced Data Formatting 14 - 57 Send c Send e Send g Send i...
Page 282 14 - 58 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send j Send l Send n Send p Send k Send m Send o...
Page 283 Advanced Data Formatting 14 - 59 Keyboard Characters (continued) Send q Send r Send s Send t Send u Send v Send w...
Page 284 14 - 60 DS6708 Digital Scanner Product Reference Guide Keyboard Characters (continued) Send x Send z Send | Send ~ Send y Send { Send }...
Page 285: Send Alt Characters
Send ALT Characters Send Alt 2 Send Alt B Send Alt D Send Alt F Advanced Data Formatting 14 - 61 Send Alt A Send Alt C Send Alt E...
Page 286 14 - 62 DS6708 Digital Scanner Product Reference Guide Send ALT Characters (continued) Send Alt H Send Alt J Send Alt L Send Alt G Send Alt I Send Alt K Send Alt M...
Page 287 Send ALT Characters (continued) Send Alt N Send Alt P Send Alt R Send Alt T Advanced Data Formatting 14 - 63 Send Alt O Send Alt Q Send Alt S...
Page 288 14 - 64 DS6708 Digital Scanner Product Reference Guide Send ALT Characters (continued) Send Alt V Send Alt X Send Alt Z Send Alt U Send Alt W Send Alt Y Send Alt [...
Page 289 Advanced Data Formatting 14 - 65 Send ALT Characters (continued) Send Alt \ Send Alt ] Send Alt 6 Send Alt -...
Page 290: Send Keypad Characters
14 - 66 DS6708 Digital Scanner Product Reference Guide Send Keypad Characters Send Keypad * Send Keypad - Send Keypad / Send Keypad 1 Send Keypad + Send Keypad . Send Keypad 0...
Page 291 Send Keypad Characters (continued) Send Keypad 3 Send Keypad 5 Send Keypad 7 Advanced Data Formatting 14 - 67 Send Keypad 2 Send Keypad 4 Send Keypad 6 Send Keypad 8...
Page 292 14 - 68 DS6708 Digital Scanner Product Reference Guide Send Keypad Characters (continued) Send Keypad 9 Send Keypad Enter Send Keypad Numlock Send Break Key Send Delete Key Send Page Up Key Send End Key...
Page 293 Advanced Data Formatting 14 - 69 Send Keypad Characters (continued) Send Page Down Key Send Pause Key Send Scroll Lock Key Send Backspace Key Send Tab Key Send Print Screen Key Send Insert Key...
Page 294 14 - 70 DS6708 Digital Scanner Product Reference Guide Send Keypad Characters (continued) Send Home Key Send Enter Key Send Escape Key Send Up Arrow Key Send Down Arrow Key Send Left Arrow Key Send Right Arrow Key...
Page 295: Send Function Key
Send Function Key Send F1 Key Send F3 Key Send F5 Key Send F7 Key Advanced Data Formatting 14 - 71 Send F2 Key Send F4 Key Send F6 Key...
Page 296 14 - 72 DS6708 Digital Scanner Product Reference Guide Send Function Key (continued) Send F8 Key Send F9 Key Send F10 Key Send F11 Key Send F12 Key Send F13 Key Send F14 Key...
Page 297 Send Function Key (continued) Send F15 Key Send F17 Key Send F19 Key Send F21 Key Advanced Data Formatting 14 - 73 Send F16 Key Send F18 Key Send F20 Key...
Page 298 14 - 74 DS6708 Digital Scanner Product Reference Guide Send Function Key (continued) Send F23 Key Send PF1 Key Send PF3 Key Send F22 Key Send F24 Key Send PF2 Key Send PF4 Key...
Page 299 Send Function Key (continued) Send PF5 Key Send PF7 Key Send PF9 Key Send PF11 Key Advanced Data Formatting 14 - 75 Send PF6 Key Send PF8 Key Send PF10 Key...
Page 300 14 - 76 DS6708 Digital Scanner Product Reference Guide Send Function Key (continued) Send PF13 Key Send PF15 Key Send PF17 Key Send PF12 Key Send PF14 Key Send PF16 Key Send PF18 Key...
Page 301 Send Function Key (continued) Send PF19 Key Send PF21 Key Send PF23 Key Send PF25 Key Advanced Data Formatting 14 - 77 Send PF20 Key Send PF22 Key Send PF24 Key...
Page 302: Send Right Control Key
14 - 78 DS6708 Digital Scanner Product Reference Guide Send Function Key (continued) Send PF27 Key Send PF29 Key Send Right Control Key The “Send Right Control Key” action will send a tap (press and release) of the Right Control Key.
Page 303: Send Graphic User Interface (Gui) Characters
Send Graphic User Interface (GUI) Characters The “Send Graphic User Interface Character” actions will tap the specified key while holding the System Dependent Graphic User Interface (GUI) Key. The definition of the Graphic User Interface key is dependant upon the attached system: Send GUI 0 Send GUI 2 Send GUI 4...
Page 304 14 - 80 DS6708 Digital Scanner Product Reference Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI 6 Send GUI 8 Send GUI A Send GUI C Send GUI 7 Send GUI 9 Send GUI B...
Page 305 Advanced Data Formatting 14 - 81 Send Graphic User Interface (GUI) Characters (continued) Send GUI D Send GUI E Send GUI F Send GUI G Send GUI H Send GUI I Send GUI J...
Page 306 14 - 82 DS6708 Digital Scanner Product Reference Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI K Send GUI M Send GUI O Send GUI Q Send GUI L Send GUI N Send GUI P...
Page 307 Send Graphic User Interface (GUI) Characters (continued) Send GUI S Send GUI U Send GUI W Advanced Data Formatting 14 - 83 Send GUI R Send GUI T Send GUI V Send GUI X...
Page 308: Turn On/Off Rule Sets
14 - 84 DS6708 Digital Scanner Product Reference Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI Y Turn On/Off Rule Sets Use these bar codes to turn rule sets on and off. Turn On Rule Set 1 Turn On Rule Set 3...
Page 309 Turn On/Off Rule Sets (continued) Use these bar codes to turn rule sets on and off. Turn Off Rule Set 1 Turn Off Rule Set 3 Advanced Data Formatting 14 - 85 Turn Off Rule Set 2 Turn Off Rule Set 4...
Page 310: Alphanumeric Keyboard
14 - 86 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard Space (Dash)
Page 311 Alphanumeric Keyboard (continued) “ ‘ Advanced Data Formatting 14 - 87 &...
Page 312 14 - 88 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard (continued) < >...
Page 313 Alphanumeric Keyboard (continued) (Underscore) Advanced Data Formatting 14 - 89...
Page 314 14 - 90 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard (continued) Numeric bar codes below should not be confused with those on the numeric keypad NOTE...
Page 315 Alphanumeric Keyboard (continued) Advanced Data Formatting 14 - 91...
Page 316 14 - 92 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard (continued)
Page 317 Alphanumeric Keyboard (continued) Advanced Data Formatting 14 - 93...
Page 318 14 - 94 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard (continued)
Page 319 Alphanumeric Keyboard (continued) Cancel Advanced Data Formatting 14 - 95 End of Message...
Page 320 14 - 96 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard (continued)
Page 321 Alphanumeric Keyboard (continued) Advanced Data Formatting 14 - 97...
Page 322 14 - 98 DS6708 Digital Scanner Product Reference Guide Alphanumeric Keyboard (continued)
Page 323 Advanced Data Formatting 14 - 99 Alphanumeric Keyboard (continued)
Page 324 14 - 100 DS6708 Digital Scanner Product Reference Guide...
Page 325: Appendix A: Standard Default Parameters
Appendix A Appendix A Standard Default Parameters Standard Default Parameters Table Table A-1 Parameter User Preferences Set Default Parameter Parameter Scanning Beeper Tone Beeper Volume Power Mode Time Delay to Low Power Mode Trigger Mode Picklist Mode Decode Session Timeout Timeout Between Decodes, Same Symbol Beep After Good Decode Miscellaneous Scanner Options...
Page 326 A - 2 DS6708 Digital Scanner Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Parameter Decoding Preferences Decoding Illumination Illumination Bank Control Decode Aiming Pattern USB Host Parameters USB Device Type USB Country Keyboard Types (Country Codes) USB Keystroke Delay...
Page 327 Standard Default Parameters Table (Continued) Table A-1 Parameter Intercharacter Delay Nixdorf Beep/LED Options Ignore Unknown Characters IBM 468X/469X Host Parameters Port Address Convert Unknown to Code 39 Wand Emulation Host Parameters Wand Emulation Host Types Leading Margin Polarity Ignore Unknown Characters Convert All Bar Codes to Code 39 Convert Code 39 to Full ASCII Keyboard Wedge Host Parameters...
Page 328 A - 4 DS6708 Digital Scanner Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Parameter Undecoded Scanner Emulation Beep Style Parameter Pass-Through Convert Newer Code Types Module Width Convert All Bar Codes to Code 39 Code 39 Full ASCII Conversion...
Page 329 Standard Default Parameters Table (Continued) Table A-1 Parameter UPC-E1 Preamble Convert UPC-E to A Convert UPC-E1 to A EAN-8/JAN-8 Extend UCC Coupon Extended Code Code 128 Code 128 UCC/EAN-128 ISBT 128 Code 39 Code 39 Trioptic Code 39 Convert Code 39 to Code 32 (Italian Pharmacy Code) Code 32 Prefix Set Length(s) for Code 39...
Page 330 A - 6 DS6708 Digital Scanner Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Parameter Interleaved 2 of 5 (ITF) Interleaved 2 of 5 (ITF) Set Lengths for I 2 of 5 I 2 of 5 Check Digit Verification...
Page 331 Standard Default Parameters Table (Continued) Table A-1 Parameter Transmit US Postal Check Digit RSS (Reduced Space Symbology) RSS 14 RSS Limited RSS Expanded Convert RSS to UPC/EAN Composite Composite CC-C Composite CC-A/B Composite TLC-39 UPC Composite Mode Composite Beep Mode UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes 2D Symbologies...
Page 332 A - 8 DS6708 Digital Scanner Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Parameter Macro PDF Flush Macro PDF Buffer Abort Macro PDF Entry User selection is required to configure this interface and this is the most common selection.
Page 333: Symbol Code Identifiers
Appendix B Appendix B Programming Reference Symbol Code Identifiers Symbol Code Characters Table B-2 Code Character Code Type UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13 Code 39, Code 32 Codabar Code 128 Code 93 Interleaved 2 of 5 Discrete 2 of 5, or Discrete 2 of 5 IATA Code 11 UCC/EAN-128 Bookland EAN...
Page 334 B - 2 DS6708 Digital Scanner Product Reference Guide Symbol Code Characters (Continued) Table B-2 Code Character Code Type US Planet Japan Postal UK Postal Dutch Postal Australian Postal UK Postal...
Page 335: Aim Code Identifiers
AIM Code Identifiers Each AIM Code Identifier contains the three-character string ]cm where: = Flag Character (ASCII 93) c = Code Character (see m = Modifier Character (see Aim Code Characters Table B-3 Code Character Code 39, Code 39 Full ASCII, Code Code 128, Coupon (Code 128 portion) Data Matrix...
Page 336 B - 4 DS6708 Digital Scanner Product Reference Guide The modifier character is the sum of the applicable option values based on Modifier Characters Table B-4 Code Type Option Value Example: A Full ASCII bar code with check character W, A+I+MI+DW, is transmitted as Code 39 ]A7AIMID where 7 = (3+4).
Page 337: Upc/Ean
Modifier Characters (Continued) Table B-4 Code Type Option Value D 2 of 5 Example: A D 2 of 5 bar code 4123, is transmitted as ]S04123 UPC/EAN Example: A UPC-A bar code 012345678905 is transmitted as ]E00012345678905 Bookland EAN Example: A Bookland EAN bar code 123456789X is transmitted as ]X0123456789X Code 11 RSS Family Example: An RSS-14 bar code 100123456788902 is transmitted as ]e001100123456788902.
Page 338 B - 6 DS6708 Digital Scanner Product Reference Guide Modifier Characters (Continued) Table B-4 Code Type Option Value PDF417, Micro Example: A PDF417 bar code ABCD, with no transmission protocol enabled, is transmitted as PDF417 ]L2ABCD. Data Matrix MaxiCode Option Reader set to conform to protocol defined in 1994 PDF417 symbology specifications.
Page 339 Modifier Characters (Continued) Table B-4 Code Type Option Value QR Code Appendix B: Programming Reference B - 7 Option Model 1 symbol. Model 2 symbol, ECI protocol not implemented. Model 2 symbol, ECI protocol implemented. Model 2 symbol, ECI protocol not implemented, FNC1 implied in first position.
Page 340 B - 8 DS6708 Digital Scanner Product Reference Guide...
Page 341: Appendix C: Sample Bar Codes Code 39
Sample Bar Codes Appendix C Appendix C Sample Bar Codes Code 39 123ABC UPC/EAN UPC-A, 100% 12345 67890...
Page 342: Ean-13, 100%
C - 2 DS6708 Digital Scanner Product Reference Guide EAN-13, 100% 3 456789 012340 Code 128 12345678901234567890123456789012345678901234 Interleaved 2 of 5 12345678901231...
Page 343: Rss 14
Appendix C: Sample Bar Codes C - 3 RSS 14 RSS 14 must be enabled to read the bar code below (see RSS-14 on page 13-49). NOTE 7612341562341 PDF417 Data Matrix...
Page 344: Maxicode
C - 4 DS6708 Digital Scanner Product Reference Guide Maxicode QR Code US Postnet...
Page 345: Uk Postal
Appendix C: Sample Bar Codes C - 5 UK Postal...
Page 346 C - 6 DS6708 Digital Scanner Product Reference Guide...
Page 347: Numeric Bar Codes
Appendix D Appendix D Numeric Bar Codes Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s). Numeric Bar Codes...
Page 348 D - 2 DS6708 Digital Scanner Product Reference Guide Numeric Bar Codes (continued) Cancel To correct an error or change a selection, scan the bar code below. Cancel...
Page 349: Ascii Character Sets
Appendix E Appendix E ASCII Character Sets ASCII Value Table Table E-1 ASCII Value Full ASCII Code 39 Encode Char 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010 1011 1012 1013 1014 1015 1016 1017 1018 1019 The keystroke in bold is sent only if the Function Key Mapping is enabled.
Page 350 E - 2 DS6708 Digital Scanner Product Reference Guide ASCII Value Table (Continued) Table E-1 ASCII Value 1020 1021 1022 1023 1024 1025 1026 1027 1028 1029 1030 1031 1032 1033 1034 1035 1036 1037 1038 1039 1040 1041 1042...
Page 351 ASCII Value Table (Continued) Table E-1 ASCII Value Full ASCII Code 39 Encode Char 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 1061 1062 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 The keystroke in bold is sent only if the Function Key Mapping is enabled.
Page 352 E - 4 DS6708 Digital Scanner Product Reference Guide ASCII Value Table (Continued) Table E-1 ASCII Value 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096...
Page 353 ASCII Value Table (Continued) Table E-1 ASCII Value Full ASCII Code 39 Encode Char 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 The keystroke in bold is sent only if the Function Key Mapping is enabled.
Page 354 E - 6 DS6708 Digital Scanner Product Reference Guide ALT Key Standard Default Tables Table E-2 ALT Keys 2064 2065 2066 2067 2068 2069 2070 2071 2072 2073 2074 2075 2076 2077 2078 2079 2080 2081 2082 2083 2084 2085...
Page 355 USB GUI Key Character Set Table E-3 GUI Key 3000 3048 3049 3050 3051 3052 3053 3054 3055 3056 3057 3065 3066 3067 3068 3069 3070 3071 3072 3073 3074 3075 3076 3077 3078 3079 Note: GUI Shift Keys - The Apple™ iMac keyboard has an apple key on either side of the space bar.
Page 356 E - 8 DS6708 Digital Scanner Product Reference Guide USB GUI Key Character Set (Continued) Table E-3 GUI Key 3080 3081 3082 3083 3084 3085 3086 3087 3088 3089 3090 Note: GUI Shift Keys - The Apple™ iMac keyboard has an apple key on either side of the space bar.
Page 357 PF Key Standard Default Table (Continued) Table E-4 PF Keys 4014 PF 14 4015 PF 15 4016 PF 16 Appendix E: ASCII Character Sets E - 9 Keystroke...
Page 358 E - 10 DS6708 Digital Scanner Product Reference Guide F key Standard Default Table Table E-5 F Keys 5001 5002 5003 5004 5005 5006 5007 5008 5009 5010 5011 5012 5013 5014 5015 5016 5017 5018 5019 5020 5021 5022...
Page 359 Numeric Key Standard Default Table Table E-6 Numeric Keypad 6042 6043 6044 Undefined 6045 6046 6047 6048 6049 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock Extended Keypad Standard Default Table Table E-7 Extended Keypad 7001 Break 7002...
Page 360 E - 12 DS6708 Digital Scanner Product Reference Guide Extended Keypad Standard Default Table (Continued) Table E-7 Extended Keypad 7008 7009 7010 7011 7012 7013 7014 7015 7016 7017 7018 Keystroke Backspace Print Screen Insert Home Enter Escape Up Arrow...
Page 361 Glossary Glossary API. An interface by means of which one software component communicates with or controls another. Usually used to refer to services provided by one software component to another, usually via software interrupts or function calls Aperture. The opening in an optical system defined by a lens or baffle that establishes the field of view. Application Programming Interface.
Page 362 Glossary - 2 Bit. Binary digit. One bit is the basic unit of binary information. Generally, eight consecutive bits compose one byte of data. The pattern of 0 and 1 values within the byte determines its meaning. Bits per Second (bps). Bits transmitted or received. Bit.
Page 363 Code 3 of 9 (Code 39). A versatile and widely used alphanumeric bar code symbology with a set of 43 character types, including all uppercase letters, numerals from 0 to 9 and 7 special characters (- . / + % $ and space). The code name is derived from the fact that 3 of 9 elements representing a character are wide, while the remaining 6 are narrow.
Page 364 Glossary - 4 Discrete 2 of 5. A binary bar code symbology representing each character by a group of five bars, two of which are wide. The location of wide bars in the group determines which character is encoded; spaces are insignificant. Only numeric characters (0 to 9) and START/STOP characters may be encoded.
Page 365 Host Computer. A computer that serves other terminals in a network, providing such services as computation, database access, supervisory programs and network control. IDE. Intelligent drive electronics. Refers to the solid-state hard drive type. IEC. International Electrotechnical Commission. This international agency regulates laser safety by specifying various laser operation classes based on power output during operation.
Page 366 Glossary - 6 IP Address. (Internet Protocol address) The address of a computer attached to an IP network. Every client and server station must have a unique IP address. A 32-bit address used by a computer on a IP network. Client workstations have either a permanent address or one that is dynamically assigned to them each session.
Page 367 MDN. Mobile Directory Number. The directory listing telephone number that is dialed (generally using POTS) to reach a mobile unit. The MDN is usually associated with a MIN in a cellular telephone -- in the US and Canada, the MDN and MIN are the same value for voice cellular users.
Page 368 Glossary - 8 Parameter. A variable that can have different values assigned to it. PC Card. A plug-in expansion card for laptop computers and other devices, also called a PCMCIA card. PC Cards are 85.6mm long x 54 mm wide, and have a 68 pin connector. There are several different kinds: Type I;...
Page 369 Router. A device that connects networks and supports the required protocols for packet filtering. Routers are typically used to extend the range of cabling and to organize the topology of a network into subnets. See Subnet. RS-232. An Electronic Industries Association (EIA) standard that defines the connector, connector pins, and signals used to transfer data serially from one device to another.
Page 370 Glossary - 10 Subnet Mask. A 32-bit number used to separate the network and host sections of an IP address. A custom subnet mask subdivides an IP network into smaller subsections. The mask is a binary pattern that is matched up with the IP address to turn part of the host ID address field into a field for subnets.
Page 371 Tolerance. Allowable deviation from the nominal bar or space width. Transmission Control Protocol/Internet Protocol. See TCP/IP. Trivial File Transfer Protocol. See TFTP. TSR. See Terminate and Stay Resident. UPC. Universal Product Code. A relatively complex numeric symbology. Each character consists of two bars and two spaces, each of which is any of four widths.
Page 372 Glossary - 12...
Page 373 Index Numerics 123Scan parameters ......12-2 2D bar codes code 128 emulation ....13-55 Data Matrix .
Page 374 Index - 2 DS6708 Digital Scanner Product Reference Guide specific data string ..... 14-18 turn off rule sets ....14-84, 14-85 zero removal .
Page 375 ignore unknown characters ... . 11-9 leading margin ....11-9, 11-10 module width ..... . . 11-6 parameter pass-through .
Page 376 Index - 4 DS6708 Digital Scanner Product Reference Guide full ASCII ......13-24 lengths .
Page 377 check digits ......13-43 lengths ......13-41, 13-42 MSI .
Page 378 Index - 6 DS6708 Digital Scanner Product Reference Guide...
Page 379 We’d like to know what you think about this Manual. Please take a moment to fill out this questionnaire and fax this form to: (631) 738-4618, or mail to: Symbol Technologies, Inc. One Symbol Plaza M/S B-10 Holtsville, NY 11742-1300...
Page 382 Symbol Technologies, Inc. One Symbol Plaza Holtsville, New York 11742-1300 http://www.symbol.com 72E-86039-01 Revision A - October 2006...

Symbol DS6708 Product Reference Manual

About this Guide

Chapter 1 Getting Started

Chapter 2: Scanning

Chapter 3 Maintenance & Technical Specifications

Chapter 4: User Preferences & Miscellaneous Digital Scanner Options

Chapter 5: Decoding Preferences

Chapter 6 USB Interface

Chapter 7: RS-232 Interface Introduction

Chapter 8: IBM 468X / 469X Interface

Chapter 9: Wand Emulation Interface

Chapter 10 Keyboard Wedge Interface

Chapter 11: Scanner Emulation Interface

Chapter 12 123Scan

Chapter 13: Symbologies

Chapter 14 Advanced Data Formatting

Quick Links

Related Manuals for Symbol DS6708

Summary of Contents for Symbol DS6708
