To replace the palm rest assembly:
1
Complete the steps in
2
Remove the modular drive by following the instructions in
drive" on page
10.
3
Remove the memory bay cover by following the instructions in
memory modules" on page
4
If the convertible notebook has IEEE 802.11 wireless networking built in, unplug the
antenna cables from the IEEE 802.11 mini PCI card by following the instructions in
"Replacing the IEEE 802.11 Mini PCI card" on page
5
Remove the hard drive by following the instructions in
on page
31.
6
Remove the hinge cover by following the instructions in
on page
37.
7
Remove the keyboard cover by following the instructions in
cover" on page
38.
8
Remove the keyboard by following the instructions in
page
40.
9
Remove the LCD panel by following the instructions in
assembly" on page
"Preparing the convertible notebook" on page
12.
44.
www.gateway.com
Replacing the palm rest assembly
6.
"Replacing the modular
"Adding or replacing
24.
"Replacing the hard drive kit"
"Replacing the hinge covers"
"Replacing the keyboard
"Replacing the keyboard" on
"Replacing the LCD panel
61
