Gateway Convertible Notebook pc Service Manual page 25

To replace the processor:
1
Complete the steps in
2
Loosen the six memory bay cover screws that secure the memory cover. (These screws
cannot be removed.)
3
Remove the memory bay cover.
Tips & Tricks
4
Remove the cooling assembly by following the instructions in
assembly" on page
"Preparing the convertible notebook" on page
Screw
Screw
Be careful not to break off the tabs located on the bottom of the cover.
Slide the cover in the direction shown. If the cover does not slide
easily, wiggle the cover to loosen it.
16.
www.gateway.com
Screw Screw
Screw Screw
Replacing the processor
6.
"Replacing the cooling
21
