Gateway Convertible Notebook pc Service Manual page 22

Replacing Gateway Convertible Notebook Components
4
Remove the four screws that are stamped with the numbers 1 through 4 next to them.
Make sure that you remove the screws in reverse numerical order.
Caution
Caution
5
Remove the two remaining screws that connect the cooling assembly to the system
board.
18
When removing the cooling assembly's screws from the numbered
holes, remove them in reverse numerical order.
Screw
Screw
There are thermal pads beneath the cooling assembly. Do not remove
the thermal pads.
www.gateway.com
Screw
Screw
Screw
Screw
