Installing the Access Point
Connecting the Equipment
STEP 1
STEP 2
STEP 3
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster
Using a Standard Switch to Connect the WAP200 to the
Network
To connect the WAP200 access point to your network using a standard switch,
follow these steps.
Use the supplied Ethernet cable to connect the Ethernet port of the access point to
an Ethernet port on the switch.
Connect the included power adapter to the Power port of the WAP200 access
point.
Plug the power adapter into an electrical outlet.
The LEDs on the front panel light up when the WAP200 access point powers on.
4
13
