Cisco WAP200 Administration Manual page 55

Configuring the WAP200 Access Point
Configuring Wireless Settings
STEP 3
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster
• VLAN Tag—Set the tagging option for the default VLAN ID. This has to match
your switch's settings. The default is untagged.
• AP Management VLAN—When the VLAN option is enabled, the value
entered (VLAN ID) in this field defines the VLAN that connects to the access
point. The default value is 1. The VLAN should be accessible from the wired
side in order to use the web-based utility. To access the web-based utility
from the wireless side, the SSID needs to map to the same VLAN ID.
Remember to enable wireless web access in the Administration >
Management window.
• VLAN ID—Select a VLAN ID (1– 4094) for the SSID where you want to map
the traffic to on the wired side. The wireless traffic does not carry VLAN
information. Multiple SSIDs can map to the same VLAN on the wired side.
To use wireless security which requires RADIUS server (802. 1 X)
NOTE
authentication, make the VLAN ID the same as the AP management
VLAN ID. This restriction in will be removed in a future releases.
Configure QoS settings by providing the following information for the VLAN global
settings for the access point:
• Default CoS (Priority)—Select Enabled to assign a default CoS value to
each SSID. This option is automatically enabled when the VLAN option is
enabled. The default is Disabled.
• U-APSD—This option is only available when Wi-Fi Multimedia (WMM) is
enabled on any of the SSIDs. Select Enabled to have client devices with
Unscheduled Automatic Power Save Delivery (U-APSD) capability take
advantage of the power save mode. The default is Disabled.
• SSID Name—Displays the SSIDs defined in the Basic Wireless Settings
window (Wireless > Basic Settings). If an SSID has been disabled, the
options cannot be configured.
• VLAN ID—Select a VLAN ID (1–4094) for the SSID for where you want to
map the traffic to, on the wired side. The wireless traffic does not carry VLAN
information. Multiple SSIDs can map to the same VLAN on the wired side.
• Priority—To assign the default priority (802. 1 p CoS bits) for packets coming
in from each wireless network, select a value from the drop-down menu. The
default is Low.
