Figure 1.
Features
•
•
•
•
•
•
Laptop with
HDMI Output
MPS 601
1
A
3
POWER
12V
RGBHV
0.5A MAX
2
4
B
HDMI
USB
Extron
TLP 710TV
7" Tabletop
TouchLink
Touchpanel
MPS 601 Application Diagram
Presentation System Integration — Integrates HDMI, RGB, and audio sources into
presentation systems.
Inputs — Includes four female HDMI type-A and two female 15-pin HD connectors for
video; two female 3.5 mm TRS connectors for analog audio.
Output — Includes one female HDMI type-A connector.
Four HDMI inputs and two RGB inputs — Provides switching between HDMI and
analog video sources.
Digitizes analog video and audio signals — Provides a single video format and
cable connection to the display.
HDMI audio embedding — Embeds analog input audio signals onto the HDMI output
signal.
Flat Panel Display with Speakers
HDMI
HDMI
INPUTS
OUTPUT
5
HDMI
6
HDMI
HDMI
HDMI
Laptop with
HDMI Output
Ethernet
TCP/IP
Network
Extron
Extron
MPS 601
Media Presentation
Switcher
C
G
T
C G
T
C G
T
+V
1
3
5
CONTACT IN / TALLY OUT
REMOTE
RS-232
2
4
6
C
G
T
C G
T
C G
T
Tx Rx G
Extron
IPL 250
RS-232
IP Link Control
Processor
COM1
COM 2
IR
Tx Rx
RTS CTS
Tx Rx
1
2
S G S G
POWER
LAN
12V
500mA
INPUT
COM 3
IR
MAX
3
4
1 2 3 4
Tx Rx
S G S G
Ethernet
MPS 601 • Introduction
RELAY
1
2
RELAY
3
4
2
