Remote Control

Mute all outputs
[MUTE]
Mute status
[MUTE?]
Change output volume level - specific
[VOLoox]
Set output volume level - specific
[VOLooxxx]
Volume level - left
[VOLL?]
Change channel volume level - left
[VOLLoox]
Set channel volume level - left
[VOLLooxxx]
Change channel volume level - right
[VOLRoox]
Volume level - right
[VOLR?]
5-6 MSG Matrix Switchers • Remote Control
Toggle between mute and unmute for all outputs.
Returns mute status for all outputs
Changes the volume level for a specific output.
• Where:
oo = 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x = + (plus sign) to increment the output volume.
x = - (minus sign) to decrement the output volume.
x = @ to return the output volume to factory default.
x = ? to request the current volume level.
Sets the volume level for a specific output.
• Where:
oo = 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
xxx = -550 - 090
Note: 090 equals maximum gain (+9dB), 000 equals factory
default (unity gain), and -550 equals minimum gain (-55dB).
Returns all left audio output levels.
Changes the left channel volume level for a specific output.
• Where:
oo = 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x = + (plus sign) to increment the output volume.
x = - (minus sign) to decrement the output volume.
x = @ to return the output volume to factory default.
x = ? to request the current volume level.
Sets the left channel volume level for a specific output.
• Where:
oo = 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
xxx = -550 - 090
Note: 090 equals maximum gain (+9dB), 000 equals factory
default (unity gain), and -550 equals minimum gain (-55dB).
Changes the right channel volume level for a specific output.
• Where:
oo = 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x = + (plus sign) to increment the output volume.
x = - (minus sign) to decrement the output volume.
x = @ to return the output volume to factory default.
x = ? to request the current volume level.
Returns all right audio output levels.
