MTPX Series
MTP TwiSTed Pair
MaTrix SwiTcherS
A New Generation of Twisted Pair
A / V Integration
twisted pair
Six models in sizes from 8x16
➤
to 32x32
Local video inputs and outputs
➤
Local audio inputs and outputs
➤
Audio input gain/attenuation
➤
adjustment
Local audio output volume control
➤
Video pre-peaking on 25% of
➤
the outputs
QS-FPC
- QuickSwitch Front Panel
™
➤
Controller
Compatible with Extron MTP Series
➤
products, including MTP U Series
Universal Twisted Pair Receivers
www.extron.com
Advertisement
Related Manuals for Extron electronics Crosstalk 1632
Summary of Contents for Extron electronics Crosstalk 1632
- Page 1 MTPX Series MTP TwiSTed Pair MaTrix SwiTcherS A New Generation of Twisted Pair A / V Integration twisted pair Six models in sizes from 8x16 ➤ to 32x32 Local video inputs and outputs ➤ Local audio inputs and outputs ➤ Audio input gain/attenuation ➤...
- Page 2 introduction The Extron MTPX Series Twisted Pair Matrix Switchers offer an innovative new feature set to simplify the complexity of a twisted pair A/V system. Local video and audio inputs and outputs enable direct connection of equipment that is located within the same rack as the MTPX Matrix. This greatly simplifies system complexity by eliminating additional MTP transmitters and receivers.
- Page 3 MTPx Series Models SiX i/o SizeS MTPX Series Twisted Pair Matrix Switchers are available in six fixed I/O sizes from 8x16 to 32x32. Each model is compatible with Extron MTP Series transmitters and receivers, including the MTP U Series Universal Mini Twisted Pair receivers. They are capable of routing video signals, along with audio or RS-232 control signals.
- Page 4 Overview Global presets Allow you to set up I/O configurations and QS-FPC - QuickSwitch store them in memory for future use Front Panel Controller A separate button for each input and output, enables simple, intuitive operation MTPX 3232 Front Panel Compatible with Extron MTP products Works with all MTP Series transmitters,...
-
Page 5: Application Diagram
application diagram Rack Mounted PC Control System Extron MTPX 3232 MTP Matrix Switcher V ID 0 .5 Extron MTP T SV A Transmitter .5 A Extron MTP T 15HD A Transmitter Extron MTP U R RSA SEQ Universal Receiver V ID B -Y Y /C R -Y... -
Page 6: Specifications
specifications Specifications Video Gain ... Unity Crosstalk 816, 168, 1616 models ... -80 dB @ 1 MHz, -55 dB @ 10 MHz, -45 dB @ 30 MHz, -37 dB @ 100 MHz 1632, 3216, 3232 models ... -69 dB @ 1 MHz, -48 dB @ 10 MHz, -39 dB @ 30 MHz, -32dB @ 100 MHz Switching speed ...
