IP Addressing

What is an IP Address?

A full explanation of IP addressing is beyond the scope of this user guide. However, the
following details provide enough information to get started.
An IP address is a 32-bit binary number that is used to identify each device on an Ethernet
network. This number is usually represented by four decimal numbers (each in the range
or 0 to 255) separated by dots, such as 198.123.34.240. This is called "dotted decimal
notation."
An IP address is divided into two parts:
•
•
Each address on a given network must have the same network identifier value but have
a unique host identifier. As a result, there are different classes of addresses the define the
range of valid addresses and which parts of the address are used for the network and host
identifiers.
The most common IP address classes are:
Class Name
Class A
Class B
Class C
NNN

Choosing IP Addresses

If the computer and QGE 100 are directly connected or connected via their own
independent network, follow the guidelines below for choosing the IP addresses.
However, if you intend to connect your computer and QGE 100 to an existing network,
notify the network administrator and ask them to allocate suitable IP addresses.
On an independent network, it is generally recommended that you use the Class C format
(from 192.0.0.1 to 223.255.255.254).
There are two rules for choosing IP addresses:
•
•
Applying these rules to Class C addresses, the first three decimal values of your IP address
must all be the same, while the last value is used to uniquely identify each device.
The following is an example of a valid Class C addressing scheme:
Device
QGE 100 viewing computer
QGE 100 encoder 1
QGE 100 encoder 2
NOTE:
Network identifier
Host identifier
Valid Address Range
0.0.0.1 to 127.255.255.254
128.0.0.1 to 191.255.255.254
192.0.0.1 to 223.255.255.254
refers to the network identifier and
Network identifier must be the same for each IP address
Host identifier must be unique for each address.
The host identifiers (41, 42, and 43 in the above example) do not need to be
sequential or in any particular order. However, it is recommended that you
group the numbers for simplicity.
Identifier Arrangement
NNN.HHH.HHH.HHH
NNN.NNN.HHH.HHH
NNN.NNN.NNN.HHH
refers to the host identifier.
HHH
IP Address
208.132.180.41
208.132.180.42
208.132.180.43
QGE 100 • Reference Information 49 49
