ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parenthe-
ses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The
number following the parentheses is the quantity needed for assembly. Note: If a part is not in the hardware
kit, check to see if it has been preassembled.
M4 x 16mm M4 x 19mm
Screw (92)–6 Screw (25)–4
M6 x 12mm
Screw (84)–12
M10 x 20mm Patch
Screw (79)–5
M6 Locknut
(74)–4
M6 x 38mm
Bolt (108)–4
M8 Locknut
M8 Washer
(77)–4
(33)–4
M8 x 18mm
Patch Screw
(80)–4
M10 x 95mm Patch
Screw (82)–4
5
.
M10 Split
Washer (109)–5
M8 x 45mm Button
Bolt (76)–4
