About Your New Printer

With your new RHINO label printer, you can create a
wide variety of high-quality, self-adhesive labels.
You can choose to print your labels in many
different sizes and styles. The printer uses RHINO
Industrial label cartridges in widths of 1/4" (6 mm),
3/8" (9 mm), 1/2" (12 mm), or 3/4" (19 mm). RHINO
label cartridges are also available in a wide range of
materials, such as flexible nylon, permanent
polyester, vinyl, non-adhesive tag, and heat shrink
tubes.
Visit www.dymo.com for information on the full
line of labels and accessories for your printer.
Warranty Registration
Visit www.dymo.com/register to register your
label printer online. During the registration process,
you will need the serial number, which is located
inside the battery compartment.

Getting Started

Follow the instructions in this section to start using
your printer for the first time.

Connecting the Power

The printer can be powered with batteries or AC
power. A rechargeable Lithium-ion battery pack
and AC power adapter are included with some
models. Visit www.dymo.com for information on
obtaining an optional rechargeable battery pack.
For optimal power, use the optional
rechargeable Lithium-ion battery pack for portable
use when not connected to the AC power adapter.
To save power, the printer will automatically turn
off after five minutes of inactivity.

Inserting the Batteries

The printer can operate using six AA alkaline
batteries.
To insert the batteries
1. Press the thumb latch on the back of the
printer to remove the battery compartment
cover. See Figure 2.
2. Insert the batteries into the battery
compartment. See Figure 2.
3. Replace the battery compartment cover.
Remove the batteries if the printer will not be
used for a long period of time.

Connecting the Optional Power Adapter

The printer uses a 110V-240V power adapter.
Connecting the power adapter with the battery
pack inserted recharges the battery pack.
To connect the power adapter
1. Plug the power adapter into the power
connector on the top of the printer. See Figure 3.
2. Plug the other end of the power adapter into a
power outlet.
5
Press thumb
latch to open
Figure 2
Figure 3
