When Home State is Enabled, the valid settings for
FEC
• Code Rate — 3/4 or 5/16
• Modulation — QPSK or BPSK
• FEC — Turbo

Set Current Configuration as Home State

This command sets the SLM-5650A's current configuration as its Home State
settings. Assuming the modem has been properly configured using the Modem
Configuration page (Tx and Rx parameters) and the Vipersat STDMA page
(Selective TDMA setting), these parameter values will be copied into the Home
State configuration. Rather than entering each of these values individually, this
command can be used as a shortcut for establishing the Home State settings.
Click on the Set Current Config As Home button in the Home State page to
execute this command. Once saved, the modem will be configured with the
Home State settings at boot time and when manually reset with the Force
Modem to Home State command.
Tip: This command is useful when an SLM-5650A's initial set up is completed

Force Modem to Home State

If at any time it is desired to have an SLM-5650A return to its Home State, the
Force Modem to Home State command can be executed. The Home State
parameter values are "forced" into the Base Modem configuration so that they
match. The Base Modem parameters will be updated to reflect the configuration
that has been set from this menu.
To maintain any parameter changes in flash memory, select Save from the Main
Menu bar.
C h a p t e r 3 - U s i n g t h e W e b S e r ve r I n t e r f a c e ( W S I )
are as follows:
and the unit is functioning as desired in a network.
V i p e r s a t C o n f i g u r a t io n
,
Code Rate Modulation
, and
3-39
