HP ENVY Sleekbook 6 Maintenance And Service Manual

Hp envy
Table of Contents

Advertisement

Quick Links

HP ENVY Sleekbook 6 and
HP ENVY Ultrabook 6
Maintenance and Service Guide
IMPORTANT! This document is intended for HP
authorized service providers only.

Advertisement

Table of Contents
loading

Summary of Contents for HP ENVY Sleekbook 6

  • Page 1 HP ENVY Sleekbook 6 and HP ENVY Ultrabook 6 Maintenance and Service Guide IMPORTANT! This document is intended for HP authorized service providers only.
  • Page 2 Logo is a trademark of its proprietor. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
  • Page 3 Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not place the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.
  • Page 4 Safety warning notice...
  • Page 5: Table Of Contents

    Table of contents 1 Product description ......................1 2 External component identification ..................6 Display ........................... 6 Button, speakers, and subwoofer ....................8 Keys ............................9 Lights ............................ 10 TouchPad ..........................11 Left side ..........................12 Right side ..........................14 Bottom ..........................
  • Page 6 Base enclosure ......................43 Battery ........................44 Hard drive ......................46 RTC battery ......................49 TouchPad module ....................51 WLAN module ......................53 Memory module ...................... 54 Fan ........................56 System board ......................57 Fan-Heat sink ......................62 Media card reader assembly (smart card reader) ............64 Subwoofer ......................
  • Page 7 Remove everything and reinstall Windows ..........90 Recovering using HP Recovery Manager ............. 90 What you need to know ............. 91 Using the HP Recovery partition to recover a minimized image (select models only) ..............91 Using HP Recovery media to recover ........... 92 Changing the computer boot order ..........
  • Page 8 viii...
  • Page 9: Product Description

    Description HP ENVY HP ENVY Sleekbook 6 Ultrabook 6 √ Product Name HP ENVY Sleekbook 6 √ HP ENVY Ultrabook 6 √ Processors AMD® A10-4655M 2.00-GHz (SC turbo up to 2.80- GHz) processor (4.00-MB L2 cache, 1333-MHz FSB, DDR3, quad core, 25 W) √...
  • Page 10 Category Description HP ENVY HP ENVY Sleekbook 6 Ultrabook 6 √ Chipset AMD A70M fusion controller hub (FCH) √ Intel HM77 Express Chipset √ Graphics Internal graphics: ● AMD Radeon™ HD 7620G on computer models equipped with an A10-4655M processor ●...
  • Page 11 Category Description HP ENVY HP ENVY Sleekbook 6 Ultrabook 6 Memory (continued) √ √ DDR3L-1600MHz single channel support DDR3-1333MHz single channel support (DDR3-1600 downgrade to 1333) √ √ Supports up to 16384-GB of system RAM √ √ Supports the following configurations: ●...
  • Page 12 Category Description HP ENVY HP ENVY Sleekbook 6 Ultrabook 6 √ √ Audio and video HP TrueVision high-definition webcam (fixed, no tilt, (continued) 1280×720 by 30 frames per second) √ √ Ethernet Integrated 10/100/1000 GB network interface card (NIC) √...
  • Page 13 √ Taps enabled as default √ √ Power requirements Supports the following HP AC adapters: ● 65-W (non-smart) PFC RC V EM 2-wire HP AC adapter √ √ Supports the following batteries: ● 4-cell, 60WHr 4.1 AH Li-ion battery √...
  • Page 14: External Component Identification

    External component identification Display Component Description Internal display switch Turns off the display and initiates Sleep if the display is closed while the power is on. NOTE: The internal display switch is not visible from the outside of the computer. WLAN antennas (2)* Send and receive wireless signals to communicate with wireless local area networks (WLANs).
  • Page 15 Component Description HP TrueVision HD Webcam Records video, captures still photographs, and allows video conferences and online chat by means of streaming video. To use the webcam, select Start > All Programs > Communication and Chat > CyberLink YouCam. *The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions.
  • Page 16: Button, Speakers, And Subwoofer

    Button, speakers, and subwoofer Component Description ● Power button When the computer is off, press the button to turn on the computer. ● When the computer is on, press the button briefly to initiate Sleep. ● When the computer is in the Sleep state, press the button briefly to exit Sleep.
  • Page 17: Keys

    Component Description Speakers (2) Produce sound. HP Triple Bass Reflex Subwoofer Provides superior bass sound. Keys Component Description Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with the key, the spacebar, or the key.
  • Page 18: Lights

    Lights Component Description ● Power light White: The computer is on. ● Blinking white: The computer is in the Sleep state, which is an energy-saving mode. The computer shuts off power to the display and other unneeded components. ● Off: The computer is off or in Hibernation. Hibernation is an energy-saving mode that uses the least amount of power.
  • Page 19: Touchpad

    TouchPad Component Description TouchPad on/off button Turns the TouchPad on or off. ● TouchPad light On: The TouchPad is off. ● Off: The TouchPad is on. TouchPad zone Moves the on-screen pointer and selects or activates items on the screen. Left TouchPad button Functions like the left button on an external mouse.
  • Page 20: Left Side

    Left side Component Description RJ-45 (network) jack Connects a network cable. HDMI port Connects an optional video or audio device, such as a high- definition television, or any compatible digital or audio device. USB 3.0 ports (2) Connect optional USB 3.0 devices and provide enhanced USB power performance.
  • Page 21 Component Description ● Hard drive light Blinking white: The hard drive is being accessed. ● Amber: HP 3D DriveGuard has temporarily parked the hard drive. NOTE: For information about HP 3D DriveGuard, see the User Guide. ● Power light White: The computer is on.
  • Page 22: Right Side

    Right side Component Description Security cable slot Attaches an optional security cable to the computer. NOTE: The security cable is designed to act as a deterrent, but it may not prevent the computer from being mishandled or stolen. Audio-in (microphone) jack Connects an optional computer headset microphone, stereo array microphone, or monaural microphone.
  • Page 23: Bottom

    Bottom Component Description Vents (2) Enable airflow to cool internal components. NOTE: The computer fan starts up automatically to cool internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation. Bottom...
  • Page 24: Illustrated Parts Catalog

    Illustrated parts catalog Service tag When ordering parts or requesting information, provide the computer serial number and model description provided on the service tag, which is located on the bottom of the computer. Item Description Function Product name This is the product name affixed to the front of the computer.
  • Page 25: Computer Major Components

    Computer major components Item Component Spare part number 15.6-in, BrightView, display assembly (includes microphone, webcam, and 2 wireless antenna cables and transceivers): Computer major components...
  • Page 26 Item Component Spare part number Full high-definition (FHD) display assembly In midnight black finish for use only on computer models equipped with an Intel processor 712246-001 In midnight black and natural silver finish for use only on computer models equipped with 712247-001 an Intel processor High-definition (HD) display assembly...
  • Page 27 Item Component Spare part number For use only on computer models equipped with an Intel processor in Spain 698682-071 For use only on computer models equipped with an Intel processor in Switzerland 698682-BG1 For use only on computer models equipped with an Intel processor in Turkey 698682-141 For use only on computer models equipped with an Intel processor in the United States 698682-001...
  • Page 28 Item Component Spare part number For use only on computer models equipped with an Intel processor in Slovenia 698681-BA1 For use only on computer models equipped with an Intel processor in Taiwan 698681-AD1 For use only on computer models equipped with an Intel processor in South Korea 698681-AB1 For use only on computer models equipped with an Intel processor in Thailand 698681-281...
  • Page 29 Item Component Spare part number For use only on computer models equipped with an AMD A4-4355M 1.70-GHz (SC turbo up 694436-501 to 2.30-GHz) processor (1.0-MB L2 cache, 1333-MHz DDR3, dual core 17-W) and the Windows 8 Standard operating system For use only on computer models equipped with an Intel Dual Core i7-3537U 2.00-GHz (SC 713698-601 turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.00-MB L3 cache, 17 W), the 8750M chipset, a graphics subsystem with 2-GB of discrete memory, and the Windows 8 Professional...
  • Page 30 Item Component Spare part number For use only on computer models equipped with an Intel Dual Core i5-3317U 1.70-GHz (SC 708972-601 turbo up to 2.60-GHz) processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), the 7670M chipset, a graphics subsystem with 2-GB of discrete memory, and the Windows 8 Professional operating system For use only on computer models equipped with an Intel Dual Core i5-3317U 1.70-GHz (SC 708972-501...
  • Page 31 Item Component Spare part number For use only on computer models equipped with an Intel Dual Core i3-3217U 1.80-GHz 713701-601 processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), a graphics subsystem with UMA memory, and the Windows 8 Professional operating system For use only on computer models equipped with an Intel Dual Core i3-3217U 1.80-GHz 708970-601 processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), a graphics subsystem with UMA...
  • Page 32 Item Component Spare part number (13) Fan (includes cable) 686580-001 (14) Audio/USB board 686597-001 (15) 4-cell, 60-WHr, 4.1-AHr, Li-ion battery 681951-001 (16) Hard drive (7.0-mm [2.5-in], SATA): NOTE: The hard drive spare kit does not include the hard drive bracket, hard drive connector cable, or screws. These components are included in the Hard Drive Hardware Kit, spare part numbers 708268-001 (for use on all computer models) and 686594-001 (for use only on computer models equipped with an Intel processor).
  • Page 33: Mass Storage Devices

    Mass storage devices Item Component Spare part number Hard drive (7.0-mm [2.5-in], SATA) NOTE: The hard drive spare kit does not include the hard drive bracket, hard drive connector cable, or screws. These components are included in the Hard Drive Hardware Kit, spare part numbers 708268-001 (for use on all computer models) and 686594-001 (for use only on computer models equipped with an Intel processor).
  • Page 34: Miscellaneous Parts

    Item Component Spare part number Optical drive (includes bezel and bracket): Blu-ray ROM DVD±R/RW Super Multi Double-Layer Drive 659941-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 659940-001 Miscellaneous parts Component Spare part number AC adapter: 65-W, non-PFC, RC, V, 2-wire for use on all computer models 693715-001 65-W, non-PFC, EM, 2-wire for use only on computer models equipped with an Intel processor 707750-001...
  • Page 35: Sequential Part Number Listing

    Sequential part number listing Spare part number Description 490371-001 Power cord for use on all computer models in North America (3-pin, black, 1.83-m) 490371-011 Power cord for use only on computer models equipped with an Intel processor in Australia (3-pin, black, 1.83-m) 490371-021 Power cord for use on all computer models in Europe (3-pin, black, 1.83-m)
  • Page 36 Spare part number Description 655795-005 Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 657325-005 Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo Adapter 659940-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive (includes bezel and bracket) 659941-001 Blu-ray ROM DVD±R/RW Super Multi Double-Layer Drive (includes bezel and bracket) 670034-005...
  • Page 37 Spare part number Description 688003-001 Power button board (includes cable) 688004-001 Media Card Reader assembly 689855-001 Base enclosure in ruby red finish for use only on computer models equipped with an AMD processor 690019-005 Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter for use on all computer models 690020-005 Intel Centrino Wireless-N 1030 + Bluetooth Combo Adapter for use on all computer models...
  • Page 38 Spare part number Description 698679-041 Keyboard in midnight black finish for use only on computer models equipped with an Intel processor and the Windows 8 operating system in Germany (includes keyboard cable) 698679-051 Keyboard in midnight black finish for use only on computer models equipped with the Windows 8 operating system in France (includes keyboard cable) 698679-061 Keyboard in midnight black finish for use only on computer models equipped with an Intel processor...
  • Page 39 Spare part number Description 698680-251 Keyboard with backlight in midnight black finish for use only on computer models equipped with the Windows 8 operating system in Russia (includes keyboard cable and backlight cable) 698680-A41 Keyboard with backlight in midnight black finish for use only on computer models equipped with an Intel processor and the Windows 8 operating system in Belgium (includes keyboard cable and backlight cable) 698680-B31...
  • Page 40 Spare part number Description 698681-BA1 Keyboard in midnight black and natural silver finish for use only on computer models equipped with an Intel processor and the Windows 8 operating system in Slovena (includes keyboard cable) 698681-BB1 Keyboard in midnight black and natural silver finish for use only on computer models equipped with an Intel processor and the Windows 8 operating system in Israel (includes keyboard cable) 698681-D61 Keyboard in midnight black and natural silver finish for use only on computer models equipped with...
  • Page 41 Spare part number Description 707750-001 65-W, non-PFC, EM, 2-wire AC adapter for use only on computer models equipped with an Intel processor 708268-001 Hard Drive Hardware Kit (includes hard drive bracket, hard drive connector cable, and screws) 708970-501 System board for use only on computer models equipped with an Intel Dual Core i3-3217U 1.80- GHz processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), a graphics subsystem with UMA memory, and the Windows 8 Standard operating system (includes processor and replacement thermal material)
  • Page 42 Spare part number Description 708975-601 System board for use only on computer models equipped with an Intel Dual Core i3-3217U 1.80- GHz processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), the 7670M chipset, a graphics subsystem with 2-GB of discrete memory, and the Windows 8 Professional operating system (includes processor and replacement thermal material) 708976-501 System board for use only on computer models equipped with an Intel Dual Core i7-3517U 1.90-...
  • Page 43 Spare part number Description 713692-501 System board for use only on computer models equipped with an Intel Dual Core i5-3317U 1.70- GHz (SC turbo up to 2.60-GHz) processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), the 8750M chipset, a graphics subsystem with 2-GB of discrete memory, and the Windows 8 Standard operating system (includes processor and replacement thermal material) 713692-601 System board for use only on computer models equipped with an Intel Dual Core i5-3317U 1.70-...
  • Page 44 Spare part number Description 713703-501 System board for use only on computer models equipped with an Intel Dual Core i3-2377M 1.50- GHz processor (1333-MHz FSB, 3.00-MB L3 cache, 17 W), a graphics subsystem with UMA memory, and the Windows 8 Standard operating system (includes processor and replacement thermal material) 713703-601 System board for use only on computer models equipped with an Intel Dual Core i3-2377M 1.50-...
  • Page 45: Removal And Replacement Procedures

    Removal and replacement procedures CAUTION: This computer does not have user-replaceable parts. Only HP authorized service providers should perform the removal and replacement procedures described here. Accessing the internal part could damage the computer or void the warranty. Preliminary replacement requirements...
  • Page 46: Drive Handling

    Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be caught or snagged by parts being removed or replaced.
  • Page 47 CAUTION: To prevent damage to the computer when you are removing or installing internal components, observe these precautions: Keep components in their electrostatic-safe containers until you are ready to install them. Before touching an electronic component, discharge static electricity by using the guidelines described in this section.
  • Page 48: Packaging And Transporting Guidelines

    Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: ● To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
  • Page 49 Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. ● When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.
  • Page 50: Component Replacement Procedures

    Component replacement procedures This chapter provides removal and replacement procedures. There are as many as 77 screws that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw size and location during removal and replacement. Service label When ordering parts or requesting information, provide the computer serial number and model number provided on the service label, which is found on the bottom of the computer.
  • Page 51: Base Enclosure

    Base enclosure Description Spare part number In ruby red finish for use only on computer models equipped with an AMD processor 689855-001 In midnight black finish for use only on computer models equipped with an Intel processor and a 712249-001 full high-definition display assembly In ruby red finish for use only on computer models equipped with an Intel processor and a full 712248-001...
  • Page 52: Battery

    Remove the bottom enclosure. NOTE: To remove the bottom enclosure, use a thin, non-conductive tool such as the HP Tool Shroud separator, available on the HP website. Battery Description Spare part number 4-cell, 60WHr 4.1AH Li-ion battery 681951-001 Before removing the battery, follow these steps: Shut down the computer.
  • Page 53 Disconnect the battery cable. Move the battery cable to the side (1), and then remove the 6 Phillips PM 2.5×4.2 screws (2) that secure the battery to the computer. Remove the battery from the computer (3). Component replacement procedures...
  • Page 54: Hard Drive

    Reverse this procedure to install the battery. Hard drive Description Spare part number 500 GB, 5400 rpm 683802-005 320 GB, 7200 rpm 634862-005 320 GB, 5400 rpm 645193-005 128 GB mSATA solid-state drive 687101-001 32 GB mSATA solid-state drive 687100-001 Before removing the hard drive or SSD, follow these steps: Shut down the computer.
  • Page 55 Remove the hard drive (3). Remove the hard drive connector cable (1). Remove the 4 screws (2) securing the hard drive bracket to the hard drive, and then remove the hard drive bracket (3). Remove the hard drive (3). Remove the mSATA solid-state drive: Component replacement procedures...
  • Page 56 ▲ Remove the screw (1), and then remove the mSATA solid-state drive (2). Reverse these procedures to reassemble and install the hard drive. Chapter 4 Removal and replacement procedures...
  • Page 57: Rtc Battery

    RTC battery Description Spare part number RTC battery 686922-001 Before removing the RTC battery, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 58 Hold down the media card reader board (2), and remove the RTC battery (3). (The RTC battery is also attached to the system board by foam material rather than double-sided adhesive.) Reverse this procedure to install the RTC battery on computer models. When installing the RTC battery, make sure the “+”...
  • Page 59: Touchpad Module

    TouchPad module Description Spare part number In midnight black finish for use on all computer models (includes bracket and cable) 688001-001 In natural silver finish for use only on computer models equipped with an Intel processor (includes 691643-001 bracket and cable) Before removing the TouchPad button board, follow these steps: Shut down the computer.
  • Page 60 Lift up on the rear edge, slide backwards, and then remove the TouchPad button board and cable (4). Reverse this procedure to install the TouchPad button board and cable. Chapter 4 Removal and replacement procedures...
  • Page 61: Wlan Module

    WLAN module Description Spare part number Intel Centrino Wireless-N 1030 + Bluetooth Combo Adapter 670290-005 Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 655795-005 Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo Adapter 657325-005 Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 690019-001 Intel Centrino Wireless-N 1030 + Bluetooth Combo Adapter 690020-001...
  • Page 62: Memory Module

    Remove the WLAN module by pulling the module away from the slot at an angle (3). NOTE: If the WLAN antennas are not connected to the terminals on the WLAN module, the protective sleeves must be installed on the antenna connectors. Memory module Description Spare part number...
  • Page 63 Remove the top cover (see Top cover on page 76). Disconnect the battery cable (see Battery on page 44). Remove the memory module: Spread the retaining tabs (1) on each side of the memory module slot to release the memory module. (The memory module tilts up.) CAUTION: To prevent damage to the memory module, hold it by the edges only.
  • Page 64: Fan

    Description Spare part number 686580-001 Before removing the fan: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
  • Page 65: System Board

    System board NOTE: The system board spare part kit includes replacement thermal material. Description Spare part number For use only on computer models equipped with an AMD A10-4655M processor (2.00-GHz, SC 708978-601 turbo up to 2.80-GHz; 4.00-MB L2 cache, 1333-MHz FSB, DDR3, quad core, 25 W) and the Windows 8 Professional operating system For use only on computer models equipped with an AMD A10-4655M processor (2.00-GHz, SC 708978-501...
  • Page 66 Description Spare part number For use only on computer models equipped with an Intel Dual Core i7-3517U 1.90-GHz (SC 708976-601 turbo up to 3.00-GHz) processor (1600-MHz FSB, 4.00-MB L3 cache, 17 W), the 7670M chipset, a graphics subsystem with 2-GB of discrete memory, and the Windows 8 Professional operating system For use only on computer models equipped with an Intel Dual Core i7-3517U 1.90-GHz (SC 708976-501...
  • Page 67 Description Spare part number For use only on computer models equipped with an Intel Dual Core i5-3317U 1.70-GHz (SC 708971-501 turbo up to 2.60-GHz) processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), a graphics subsystem with UMA memory, and the Windows 8 Standard operating system For use only on computer models equipped with an Intel Dual Core i3-3227U 1.90-GHz 719596-601 processor (1600-MHz FSB, 3.00-MB L3 cache, 17 W), a graphics subsystem with 2-GB...
  • Page 68 Description Spare part number For use only on computer models equipped with an Intel Dual Core i3-2377M 1.50-GHz 708974-601 processor (1333-MHz FSB, 3.00-MB L3 cache, 17 W), the 7670M chipset, a graphics subsystem with 2-GB of discrete memory, and the Windows 8 Professional operating system For use only on computer models equipped with an Intel Dual Core i3-2377M 1.50-GHz 708974-501 processor (1333-MHz FSB, 3.00-MB L3 cache, 17 W), the 7670M chipset, a graphics subsystem...
  • Page 69 ● Fan (see Fan-Heat sink on page ● Heat sink (see Fan-Heat sink on page ● WLAN module see (WLAN module on page 53). ● Hard drive (see Hard drive on page 46). ● USB/Audio (see USB/Audio) Remove the system board: Remove the following cables: ●...
  • Page 70: Fan-Heat Sink

    Remove the system board (2) by sliding it up and to the right at an angle. Reverse this procedure to install the system board. Fan-Heat sink Description Spare part number For use only on computer models equipped with a 25-W AMD processor 691657-001 For use only on computer models equipped with a 17-W AMD processor 691656-001...
  • Page 71 Before removing the fan, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
  • Page 72: Media Card Reader Assembly (Smart Card Reader)

    Media card reader assembly (smart card reader) Description Spare part number Media card reader assembly (smart card reader) 688004-001 Before removing the media reader assembly, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 73: Subwoofer

    Subwoofer Description Spare part number Subwoofer 686599-001 Before removing the USB/Audio board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 74: Usb/Audio Board

    USB/Audio board Description Spare part number USB/Audio board 686597-001 Before removing the USB/Audio board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 75: Power Connector Cable

    Power connector cable Description Spare part number Power connector cable (includes bracket) 686593-001 Before removing the power connector cable, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 76 Remove the power connector cable (3). Reverse this procedure to install the power connector cable and bracket. Chapter 4 Removal and replacement procedures...
  • Page 77: Speakers

    Speakers Description Spare part number Speaker Kit (includes left and right speakers and cable) 686598-001 Before removing the speakers, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 78: Power Button Board

    Power button board Description Spare part number Power button board 688003-001 Before removing the Power button board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 79 Remove the Power button board (2). NOTE: The Power button board's cable is attached to the board. Component replacement procedures...
  • Page 80: Keyboard

    Keyboard NOTE: The keyboard spare part kit includes a keyboard cable. For use in country or region Spare part number For use in country or region Spare part number Keyboard with backlight in midnight black finish for use only For use on all computer models 698680-251 on computer models equipped with the Windows 8 in Russia...
  • Page 81 For use in country or region Spare part number For use in country or region Spare part number For use on all computer models 698679-051 For use only on computer models 698679-271 in France equipped with an Intel processor in Romania For use only on computer models 698679-041 For use only on computer models...
  • Page 82 For use in country or region Spare part number For use in country or region Spare part number For use only on computer models 698681-061 For use only on computer models 698681-031 equipped with an Intel processor equipped with an Intel processor in Italy in the United Kingdom and Singapore...
  • Page 83 Remove the single screw (1), and then release the keyboard and keyboard bracket from the top cover (2). Remove the 1 Phillips PM 2.5x3 screw securing the keyboard to the bracket (1), disconnect the keyboard cable (2) (pushing it through the bracket), and then remove the keyboard from the bracket (3).
  • Page 84: Top Cover

    Top cover Description Spare part number In midnight black finish for use on all computer models (includes power button board and cable 686097-001 and TouchPad and TouchPad cable) In natural silver finish for use only on computer models equipped with an Intel processor (includes 690198-001 power button board and cable and TouchPad and TouchPad cable) Before removing the top cover, follow these steps:...
  • Page 85: Setup Utility (Bios) And System Diagnostics

    Updating the BIOS Updated versions of the BIOS may be available on the HP website. Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs. Some download packages contain a file named Readme.txt, which contains information regarding installing and troubleshooting the file.
  • Page 86: Determining The Bios Version

    Do not insert, remove, connect, or disconnect any device, cable, or cord. From the Start screen, select the HP Support Assistant app. Click Updates and tune-ups, and then click Check for HP updates now. Follow the on-screen instructions. At the download area, follow these steps: Identify the most recent BIOS update and compare it to the BIOS version currently installed on your computer.
  • Page 87: Using System Diagnostics

    Using the hard drive path you recorded earlier, open the folder on your hard drive that contains the update. Double-click the file that has an .exe extension (for example, filename.exe). The BIOS installation begins. Complete the installation by following the on-screen instructions. NOTE: After a message on the screen reports a successful installation, you can delete the downloaded file from your hard drive.
  • Page 88: Ubuntu

    Ubuntu Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility includes settings for the types of peripherals installed, the startup sequence of the computer, and the amount of system and extended memory.
  • Page 89: Displaying System Information

    Updating the BIOS Updated versions of the BIOS may be available on the HP website. Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs. Some download packages contain a file named Readme.txt, which contains information regarding installing and troubleshooting the file.
  • Page 90: Determining The Bios Version

    Do not shut down the computer or initiate Suspend or Hibernation. Do not insert, remove, connect, or disconnect any device, cable, or cord. Access the page on the HP website that provides software for your computer. Follow the on-screen instructions to identify your computer and access the BIOS update you want to download.
  • Page 91: Using System Diagnostics

    NOTE: After a message on the screen reports a successful installation, you can delete the downloaded file from your hard drive. Using System Diagnostics System Diagnostics allows you to run diagnostic tests to determine if the computer hardware is functioning properly. To start System Diagnostics: Turn on or restart the computer.
  • Page 92: Specifications

    Specifications Computer specifications Metric U.S. Dimensions Width 29.16 cm 11.48 in Depth 2.15 cm 8.46 in Height (front to back) 2.11 to 3.19 cm 0.83 to 1.26 in Weight With 6-cell battery 1.60 kg 3.53 lb With 3-cell battery 1.46 kg 3.22 lb Input power Operating voltage and current...
  • Page 93: 15.6-Inch Display Specifications

    15.6-inch display specifications Metric U.S. Dimensions Height 16.50 cm 6.50 in Width 25.34 cm 11.60 in Diagonal 33.66 cm 13.30 in Number of colors 262,144 Contrast ratio 200:1 (typical) Brightness 200 nits (typical) Pixel resolution Pitch 0.197 mm × 0.197 mm Format 1366 ×...
  • Page 94: Backing Up, Restoring, And Recovering

    After you successfully set up the computer, create HP Recovery media. This step creates a backup of the HP Recovery partition on the computer. The backup can be used to reinstall the original operating system in cases where the hard drive is corrupted or has been replaced.
  • Page 95: Creating Hp Recovery Media

    Support. From the Start screen, type h, and then select Help and Support. Creating HP Recovery media HP Recovery Manager is a software program that offers a way to create recovery media after you successfully set up the computer. HP Recovery media can be used to perform system recovery if the hard drive becomes corrupted.
  • Page 96: Restore And Recovery

    “Remove everything and reinstall Windows” section. ● If you want to reset your computer using a minimized image, you can choose the HP Minimized Image Recovery option from the HP Recovery partition (select models only) or HP Recovery media. Chapter 7 Backing up, restoring, and recovering...
  • Page 97: Using Windows Refresh For Quick And Easy Recovery

    HP Recovery Manager” section. ● If you have replaced the hard drive, you can use the Factory Reset option of HP Recovery media to restore the factory image to the replacement drive. For more information, see the “Recovering using HP Recovery Manager” section.
  • Page 98: Remove Everything And Reinstall Windows

    Recovering using HP Recovery Manager HP Recovery Manager software allows you to recover the computer to its original factory state. Using the HP Recovery media you created, you can choose from one of the following recovery options: ●...
  • Page 99: What You Need To Know

    To use the Factory Reset or System Recovery options, you must use HP Recovery media. ● If the HP Recovery media do not work, you can obtain recovery media for your system from the HP website. For U.S. support, go to http://www.hp.com/go/contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.
  • Page 100: Using Hp Recovery Media To Recover

    Using HP Recovery media to recover You can use HP Recovery media to recover the original system. This method can be used if your system does not have an HP Recovery partition or if the hard drive is not working properly.
  • Page 101: Ubuntu

    Personal files must be restored from a backup. NOTE: NOTE: HP recommends that you create the image restore in the event of a system failure. Creating the restore DVDs The restore creation software creates a set of system restore discs using blank, writable DVDs (DVDR or DVD+R).
  • Page 102: Performing Recovery Using The Restore Dvd

    To create the restore image: Click the System menu icon at the far right of the top panel, and then click System Settings > Backup. Select Storage from the panel on the left side of the window, click the down-arrow next to Backup location, and select the USB device from the drop-down list.
  • Page 103 NOTE: Before you back up your information, be sure you have designated a location to save the backup files. Click the System menu icon at the far right of the top panel, and then click System Settings > Backup icon. Select Folders from the panel on the left side of the window, and beneath Folders to back up, select the folders to back up.
  • Page 104: Power Cord Set Requirements

    Power cord set requirements The wide-range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC, or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.
  • Page 105: Requirements For Specific Countries And Regions

    Requirements for specific countries and regions Country/region Accredited agency Applicable note number Argentina IRAM Australia Austria Belgium CEBEC Brazil ABNT Canada Chile Denmark DEMKO Finland FIMKO France Germany India Israel Italy Japan The Netherlands KEMA New Zealand SANZ Norway NEMKO The People's Republic of China Saudi Arabia SASO...
  • Page 106 Country/region Accredited agency Applicable note number The United States The flexible cord must be Type HO5VV-F, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.
  • Page 107: Recycling

    Follow the local laws and regulations in your area for battery disposal. HP encourages customers to recycle used electronic hardware, HP original print cartridges, and rechargeable batteries. For more information about recycling programs, see the HP website at...
  • Page 108: Index

    Index components AC adapter 14 bottom 15 AC adapter, spare part numbers display 6 removal 62 26, 29, 33 left side 12 spare part number 24, 28, 62 action keys right side 14 fn key, identifying 9 identifying 9 computer major components 17 antenna computer part number 42 graphics, product description 2...
