Konica Minolta FS-505 User Manual

Finisher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FS-505
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta FS-505

Summary of Contents for Konica Minolta FS-505

  • Page 1 FS-505 User Manual...

  • Page 3: Table Of Contents

    Contents Machine overview 750/600 Additional information – Finisher FS-505 ......1-3 Caution notations and labels............1-4 Space requirements ................. 1-5 Finisher FS-505 (+ Punch Kit PK-504/PK-505)......1-6 Options................... 1-8 Copy paper ..................1-10 Possible paper sizes ..............1-10 Special paper ................1-11 Paper settings .................
  • Page 4 Contents-2 Finisher FS-505...

  • Page 5: Machine Overview

    Machine overview...

  • Page 7: 750/600 Additional Information - Finisher Fs-505

    Machine overview Machine overview 750/600 Additional information – Finisher FS-505 Finisher FS-505 is an optional device newly added to the configuration of 750/600 options. Please refer to this manual for the operation and safety information on the finisher, and keep this manual inside the user manual of the main body, readily available for reference.

  • Page 8: Caution Notations And Labels

    To avoid injury, DO NOT put your hand on top of the printed sheets. Be sure to hold both sides of the printed sheets when removing them, and DO NOT leave your hand on the printed sheets while the primary (main) tray goes up. Finisher FS-505...

  • Page 9: Space Requirements

    Unit: mm (inch) 750/600 + FS-505 + PI-501 + ZU-602 Unit: mm (inch) 750/600 + FS-505 + PI-501 + ZU-602 + LU-402 Finisher FS-505...

  • Page 10: Finisher Fs-505 (+ Punch Kit Pk-504/Pk-505)

    Machine overview Finisher FS-505 (+ Punch Kit PK-504/PK-505) Finisher FS-505 Part name Description Finisher door Opened when clearing paper misfeeds or staple jams or when replacing the staple cartridge, or when emptying the punch dust box if punch kit PK-...
  • Page 11 Machine overview Finisher FS-505 + Punch Kit PK-504/PK-505 Part name Description Inlet lever Lowered when clearing paper misfeeds Punch kit (optional) Punches holes for filing printed pages when the punch kit is installed onto finisher Cover sheet conveyance lever Moved to the left when clearing paper misfeeds...

  • Page 12: Options

    Machine overview Options Finisher FS-505...
  • Page 13 Cover sheet feeder PI-501 Allows cover sheets to be inserted into copies if in- stalled onto finisher FS-505, and allows the func- tions of installed finishers to be used manually Punch kit PK-504/PK-505 Allows hole punching to be used if installed onto fin- isher FS-505 Referred to as the "punch kit"...

  • Page 14: Copy Paper

    Use paper that meets the following specifications. Possible paper sizes Paper source Paper size Finisher FS-505 Main tray: "Sort" and "Group" settings: A3 w to B6 w, A6 w "Offset" + "Sort" and "Offset" + "Group" settings: A3 w to B5 v...

  • Page 15: Special Paper

    Select this setting when user paper 3 is loaded. A paper tray with this setting is not automatically se- lected when the "Auto Paper Select" setting is spec- ified or when the paper trays are switched automatically. Finisher FS-505 1-11...
  • Page 16 Trace Select this setting when trace paper is loaded. A paper tray with this setting is not automatically se- lected when the "Auto Paper Select" setting is spec- ified or when the paper trays are switched automatically. 1-12 Finisher FS-505...

  • Page 17: Paper Settings

    "Auto Paper Select" setting or the automatic tray switching feature. In the Basic screen, touch [Paper]. The Paper screen appears. Touch the button for the bypass tray, and then touch [Change Tray Settings]. Finisher FS-505 1-13...
  • Page 18 % To specify "Letterhead", "Tab Paper", "Trace", "User 1", "User 2", "User 3", "Recycled", "Fine", "Labels", "Colored Paper", touch [Specialty Paper] in the Change Settings of Selected Tray screen. Touch [OK] twice. The Basic screen appears again. 1-14 Finisher FS-505...

  • Page 19: To Specify The Paper Type For A Paper Tray

    For details on displaying the Paper Tray Setting screen, refer to Copy Operations of the user manual. The Paper Type screen appears. Touch the button for the tray 1, and then touch [Paper Type]. The Paper Type screen appears. Finisher FS-505 1-15...
  • Page 20 Machine overview Select the type of paper to be loaded. – If weak recycled paper or thin paper is loaded into a paper tray, select "Special Paper" in the Paper Type screen. Touch [OK]. 1-16 Finisher FS-505...

  • Page 21: Replacing The Staples

    Machine overview Replacing the staples When finisher FS-505 is installed and is about to run out of staples, the message shown below appears. Display in enlarge display mode Finisher FS-505 1-17...

  • Page 22: To Replace The Staple Cartridge

    Remove the empty staple cartridge from the staple cartridge holder. – Hold the lever on the staple cartridge, and then pull the cartridge down to remove it. 1-18 Finisher FS-505...
  • Page 23 Machine overview Install the new staple cartridge. – Push up the staple cartridge, and then check that the cartridge is securely installed. Return the stacker unit to its original position. Close the finisher door. Finisher FS-505 1-19...

  • Page 24: Emptying The Dust Boxes

    Emptying the dust boxes To empty the dust box of the punch kit If the punch dust box in punch kit PK-504/PK-505 installed on finisher FS- 505 becomes full, the message shown below appears. Display in enlarge display mode 1-20 Finisher FS-505...
  • Page 25 Machine overview Open the finisher door. Pull out the punch dust box. Empty the punch dust box. Install the punch dust box into its original position. Finisher FS-505 1-21...

  • Page 26: Finisher Fs-505

    Machine overview Close the finisher door. 1-22 Finisher FS-505...
  • Page 27 Machine overview Specifications Finisher FS-505 Specifications Exit trays Main tray, sub tray Settings Non-stapled, Offset, Staple Paper types Main tray: "Sort" and "Group" settings : Normal paper (60 to 90 g/m thick paper (91 to 200 g/m ), thin paper (50 to 59 g/m...
  • Page 28 Machine overview 1-24 Finisher FS-505...

  • Page 29: Copy Operations

    Copy operations...

  • Page 31: Selecting Finishing Settings

    For details on specifying the position of the binding margin, refer to Copy Operations of the user manual. If cover sheet feeder PI-501 is installed onto finisher FS-505, the finisher can be operated manually. For details, refer to "Using finisher manually"...
  • Page 32 The copies are fed out and stacked on top of each other with each set shifted to separate it. (Refer to page 2-6.) Face Up Select this setting to feed out copies with the front side facing up. (Refer to page 2-8.) Finisher FS-505...
  • Page 33 (Refer to page 2-9.) Punch Select this setting to punch holes (2 or 4 holes) in the copies for filing them. (Refer to page 2-13.) The following procedures describe how to select finishing settings. Finisher FS-505...

  • Page 34: Separating Copies By Sets ("Sort" Setting)

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Sort]. – To separate each set of copies, touch [Offset]. To cancel the setting, touch [Offset] again to deselect it. Touch [OK]. The Basic screen appears again. Finisher FS-505...

  • Page 35: Separating Copies By Pages ("Group" Setting)

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Group]. – To separate each set of pages, touch [Offset]. To cancel the "Offset" setting, touch [Offset] again to deselect it. Touch [OK]. The Basic screen appears again. Finisher FS-505...

  • Page 36: Feeding Out Copies Face Up ("Face Up" Setting)

    Printed copies are fed out face down. – To cancel the setting, touch [Face Up] again to deselect it. – To cancel changes to the settings, touch [Cancel]. Touch [OK]. The Basic screen appears again. Finisher FS-505...

  • Page 37: Stapling Copies (Staple Settings)

    Stapling copies (Staple settings) Detail There are two types of staple cartridges for finisher FS-505. The 50-sheet staple cartridge can staple up to 50 sheets. The 100-sheet staple cartridge can staple up to 100 sheets. Specify the number of copies according to the paper size, stapling method and number of sheets stapled, and then adjust the number of sheets loaded in the main tray.
  • Page 38 Copy operations When Finisher FS-505 is installed Paper weight Paper size Loading capacity with a sta- ple setting 60g/m to 80g/ m A3 w, B4 w, A4 w, A4 v, B5 1,000 sheets w, B5 v, A5 v, Foolscap Original of mixed sizes cannot be stapled if all printed pages do not have the same width.

  • Page 39: To Bind Copies With Staples

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Under "Staple", touch either [Corner] or [2 Position]. – To cancel the Staple settings, touch [Corner] or [2 Position] again to deselect it. – To cancel changes to the settings, touch [Cancel]. Finisher FS-505 2-11...
  • Page 40 297 mm or less, the long side of the paper is stapled. If the original length(X) is more than 297 mm, the short side of the paper is stapled. Touch [OK] twice. The Basic screen appears again. 2-12 Finisher FS-505...

  • Page 41: Punching Holes In Copies (Punch Settings)

    For details, consult your technical representative. The number of holes that can be punched differs depending on the type of punch kit installed. If different hole punch settings are available, select the setting for the desired use. Finisher FS-505 2-13...

  • Page 42: To Punch Holes In Copies

    Copy operations The procedure for selecting two punched holes is described below. When Finisher FS-505 and Punch PK-504/PK-505 are installed When Finisher FS-505 and Z-folding unit ZU-601/ZU-602 are installed Paper weight Paper size 50g/m to 128g/ m A3 w, B4 w, A4 w, A4 v, B5 w, B5 v, A5 w, A5 v, Foolscap To punch holes in copies In the Basic screen, touch [Finishing].
  • Page 43 If the original length is more than 297 mm, the holes are punched along the short side of the paper. – To cancel changes to the punched hole position, touch [Cancel]. Touch [OK] twice. The Basic screen appears again. Finisher FS-505 2-15...

  • Page 44: Specifying Folding Settings

    Folding settings are available. Copies can be Z-folded only if Z-folding unit ZU-601/ZU-602 is installed on optional finisher FS-505. Select this setting to fold copies at the center, and then fold them in half again before feeding them out.

  • Page 45: To Fold Copies Fanned ("Z-Fold")

    In the Basic screen, touch [Folding]. The Folding screen appears. Touch [Z-Fold]. – To cancel changes to the settings, touch [Cancel]. – To cancel the "Z-Fold" setting, touch [Z-Fold] again to deselect it. Touch [OK]. The Basic screen appears again. Finisher FS-505 2-17...
  • Page 46 Copy operations When finisher FS-505 and Z-folding unit ZU-601/ZU-602 are installed Paper weight Paper size Number of folded sheets 60 g/m to 80 g/m A3 w, B4 w 1 sheet Number of folded sheets Maximum number of sets 1 sheet...

  • Page 47: Using Finisher Manually

    - Finisher FS-505 + Cover Sheet Feeder PI-501 – Staple (Corner staple / 2 position staples) - Finisher FS-505 + Cover Sheet Feeder PI-501 + Punch kit PK-504/505 – Staple (Corner staple / 2 position staples) – Punch Reminder The Z folding unit ZU-601/602 cannot be used for manual punch.

  • Page 48: To Use Finisher Manually

    – To select Punch, press Punch button to turn on the lamp. To use Staple in combination, turn on the desired Staple mode lamp. To select only the Punch mode, turn off all the other mode lamps. 2-20 Finisher FS-505...
  • Page 49 Copy operations Press Start/Stop button. Do you want to stop the output operation? % Press Start/Stop button on the operation panel of Cover Sheet Feeder. Finisher FS-505 2-21...
  • Page 50 Copy operations 2-22 Finisher FS-505...
