Simulation and Implementation

Simulation Models

SmartModels

SmartModels are encrypted versions of the actual HDL code. These models allow the user
to simulate the actual functionality of the design without having access to the code itself.
A simulator with SmartModel capability is required to use SmartModels.
The models must be extracted before they can be used. For information on how to extract
the SmartModels under ISE 5.1i, see

HSPICE

HSPICE is an analog design model that allows simulation of the RX and TX high-speed
transceiver. To obtain these HSPICE models, go to the Xilinx Download Center at:
http://www.xilinx.com/xlnx/xil_sw_updates_home.jsp.
Select HSPICE and Eldo Models and then Virtex-II Pro from the pull-down menus.
Online registration is required. Follow the instructions on the web page to register.

Implementation Tools

Par
For place and route, the transceiver has one restriction. This is required when channel
bonding is implemented. Because of the delay limitations on the CHBONDO to CHBONDI
ports, linking of the Master to a Slave_1_hop must run either in the X or Y direction, but not
both.
In
navigate to the other slave (a Slave_2_hops), both X and Y displacement is needed. This
slave needs one level of daisy-chaining, which is the basis of the Slave_2_hops setting.
Figure 4-2
contains more transceivers (16) per chip.
RocketIO™ Transceiver User Guide
UG024 (v3.0) February 22, 2007
Figure 4-1, the two Slave_1_hops are linked to the master in only one direction. To
shows the channel bonding mode and linking for a 2VP50, which (optionally)
www.xilinx.com
Solution Record 15501.
