Simulation and Implementation

Simulation Models

SmartModels

SmartModels are encrypted versions of the actual HDL code. These models allow the user
to simulate the actual functionality of the design without having access to the code itself.
A simulator with SmartModel capability is required to use SmartModels.
The models must be extracted before they can be used. For information on how to extract
the SmartModels under ISE 5.1i, see
see

HSPICE

HSPICE is an analog design model that allows simulation of the RX and TX high-speed
transceiver. To obtain these HSPICE models, go to the SPICE Suite Access web page at
http://support.xilinx.com/support/software/spice/spice-request.htm.

Implementation Tools

Synthesis

During synthesis, the transceiver is treated as a "black box." This requires that a wrapper be
used that describes the modules port.

Par

For place and route, the transceiver has one restriction. This is required when channel
bonding is implemented. Because of the delay limitations on the CHBONDO to CHBONDI
ports, linking of the Master to a Slave_1_hop must run either in the X or Y direction, but not
both.
In
navigate to the other slave (a Slave_2_hops), both X and Y displacement is needed. This
slave needs one level of daisy-chaining, which is the basis of the Slave_2_hops setting.
Figure 5-2
contains more transceivers (16) per chip. To ensure the timing is met on the link between
the CHBONDO and CHBONDI ports, a constraint must be added to check the time delay.
The UCF example below shows and describes this.
