Para obtener un ejemplar en Español de este
Manual del propietario, visite www.heatnglo.com.
Model:
Escape-42DV
Escape-42DVLP
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions
and the manufactured home construction and safety standard,
Title 24 CFR, Part 3280 or Standard for Installation in Mobile
Homes, CAN/CSA Z240MH, in Canada.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com.
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo Escape-42DV

  • Page 1 Technologies suggests NFI certifi ed or factory trained This appliance is only for use with the type(s) of gas indicated professionals, or technicians supervised by an NFI on the rating plate. certifi ed professional. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 2: Congratulations

    BTUH: 00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX XXXXXXXX XXXXXXXX (Serie): (Serie): Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 3: Table Of Contents

    E. Junction Box Installation......43 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 4 D. Contact Information ......64  = Contains updated information. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 5: Limited Lifetime Warranty

    3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645C 12-29-10 Page 1 of 2 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 6 B. Limited Lifetime Warranty (continued) WARRANTY CONDITIONS: WARRANTY EXCLUSIONS: This warranty is void if: LIMITATIONS OF LIABILITY: 4021-645C 12-29-10 Page 2 of 2 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 7: Listing And Code Approvals

    • A 110-120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 8: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 9: User Guide

    - A decorative fi rescreen. DECORATIVE DOORS (NOT SHOWN) SECTION 2.E. FIXED GLASS ASSEMBLY (NOT SHOWN) SECTION 14.G. GRATE SECTION 2.B. MANTEL HEARTH CLEAR SPACE SECTION 2.D. Figure 2.1 General Operating Parts Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 10: Clear Space

    Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative door or front. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 11: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 12: After Fireplace Is Lit

    Is it normal to see the pilot fl ame burn turned off. Some optional control systems available with IPI models may allow pilot fl ame to continually? remain lit. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 13: Maintenance And Service

    • Carefully set fi xed glass assembly in place on fi replace. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 14: Maintenance Tasks-Qualifi Ed Service Technician

    • Inspect for damaged or missing logs. Replace as neces- sary. Refer to Section 14 for log placement instructions. • Verify correct log placement and no fl ame impingement causing sooting. Correct as necessary. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 15 • Verify that there is not a short in fl ame sensing circuit by checking continuity between pilot hood and fl ame sense rod. Replace pilot as necessary. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 16: Installer Guide

    FRAMING HEADED OFF IN CEILING JOISTS (SECTION 8.C ) OPTIONAL WALL SWITCH MANTEL AND MANTEL LEG (SECTIONS 5.D and 13.B) SURROUND HEARTH EXTENSION GAS LINE (SECTION 11) Figure 4.1 Typical System Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 17: Design And Installation Considerations

    Plumb line Safety glasses Level Reciprocating saw Manometer Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 18: Framing And Clearances

    PERPENDICULAR SIDEWALL CAN OVERLAP TO 4 INCHES FROM OPENING ON BOTH SIDES Inches 57-1/2 91-1/2 64-3/4 45-3/4 Millimeters 1461 2325 1644 1162 Figure 5.1 Appliance Locations Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 19: Constructing The Appliance Chase

    Appliance Appliance Appliance (Vent Pipe) (Height) (Depth) (Width) Inches 52-1/2 57-1/2 1334 1461 1092 * Adjust framing dimensions for interior sheathing (such as sheetrock) Figure 5.2 Clearances to Combustibles Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 20: Mantel And Wall Projections

    (NON-COMBUSTIBLE OPENING BOARD) Height above mm 152 178 opening Horizontal 4-3/4 7-1/2 10-1/2 Mantel distance Figure 5.3 Minimum Vertical and Maximum Horizontal Dimensions of Combustibles Figure 5.5 Non-Combustible Zone Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 21: Hearth Extension

    MAY BE OF FIREPLACE COMBUSTIBLE COMBUSTIBLE 1 INCH THICK ALLOWED FLOOR OR PLATFORM UNDER THE OPENING MATERIAL Figure 5.7 Fireplace raised a minimum of 3 inches away from combustible surface Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 22: Termination Locations

    Over 16/12 to 18/12 ..........7.0 Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 23 Figure 6.3 Minimum Clearances for Termination requirements. CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS SUGGESTED THAT A VINYL PROTECTOR KIT BE INSTALLED. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 24: Vent Information And Diagrams

    76 to 152 DVP12A 3 to 12 76 to 305 DVP12MI 3 to 12 76 to 305 DVP24MI 3 to 24 76 to 610 Figure 7.2 DVP Pipe Effective Length Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 25: Vent Diagrams

    20 ft. 6.1 m After V = 6 ft. then H = 2 x V ft. Maximum = 60 ft. Maximum = 20 ft. Maximum Figure 7.4 INSTALLED HORIZONTALLY Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 26 30 ft. total of straight vertical. has no specifi c restrictions EXCEPT, = 2 x V and V cannot exceed 60 ft. Maximum t max total total Figure 7.5 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 27 *No specifi c restrictions on this value EXCEPT clude no elbows and exceed cannot exceed 60 ft. (18.3 m). 30 ft. total of straight vertical. After V = 6 ft., then H Max.= V Figure 7.7 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 28 30 ft. total of straight vertical. and H has no specifi c restrictions EXCEPT, after V = 6 ft., then H Max = 2 x V = 60 ft. Max. INSTALLED HORIZONTALLY Figure 7.8 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 29: Vent Clearances And Framing

    * Shows center of vent framing hole for top venting. The center of the hole is one (1) inch (25.4 mm) above the center of the horizontal vent pipe. Figure 8.2 Exterior Wall Hole Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 30: Install The Ceiling Firestop

    INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM 3 FASTENERS PER SIDE CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 8.4 Installing the Attic Shield Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 31: Install Attic Insulation Shield

    • Bend all tabs inward 90º around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 32: Appliance Preparation

    • Secure the appliance to the framing by using nails or screws through the nailing tabs. • Secure the appliance to the fl oor by inserting two screws through the pilot holes at the bottom of the appliance. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 33: Installing Non-Combustible Facing Material

    (9 IN. WIDE, SUPPLIED ATTACHED TO BACK OF APPLIANCE) 9 IN. NO FASTENERS 2 IN. IN THIS AREA 1 IN. APPLY FASTENERS FROM FASTENER PACKET IN THESE AREAS Figure 9.2 Attaching Non-combustible Facing Material Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 34: Installing Vent Pipe

    fl ue at the horizontal elbow joint to prevent the elbow from rotating. Use screws no longer than 1/2 in. (13 mm). If predrilling screw holes, DO NOT penetrate inner pipe. INCORRECT Figure 10.4 Seams Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 35: Assemble Slip Sections

    NOTICE: If slip section is too long, the inner and outer fl ues of the slip section can be cut to the desired length. Figure 10.8 Securing Horizontal Pipe Sections Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 36: Disassemble Vent Sections

    Figure 10.10. • Pull carefully to separate the pieces of pipe. Figure 10.9 Rotate Seams for Disassembly Figure 10.10 Align and Disassemble Vent Sections Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 37: Install Metal Roof Flashing

    • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Figure 10.14 Assembling the Storm Collar Around the Pipe Figure 10.14 Assembling the Storm Collar Around the Pipe Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 38: Install Vertical Termination Cap

    • Rest the small leg on the extended heat shield on top of the pipe section to properly space it from the pipe section. Important Notice: Heat shields may not be fi eld constructed. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 39: Install Horizontal Termination Cap

    DVP-TRAP1 can adjust 1-1/2 in. (3-1/8 to 4-5/8) DVP-TRAP2 can adjust 4 in. (5-3/8 to 9-3/8) DVP-HPC1 can adjust 2-1/8 in. (4-1/4 to 6-3/8) DVP-HPC2 can adjust 4-1/8 in. (6-3/8 to 10-1/2) Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 40: Gas Information

    fl exible gas connector are connected to the 1/2 in. (13 mm) control valve inlet. • If substituting for these components, please consult local codes for compliance. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 41: Electrical Information

    NOTICE: Do not use battery back up without removing refractory panels and mesh. Failure to do so may result in damage to components. Use battery back up to operate appliance only during power outage. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 42 GROUNDED. *MUST ORDER PLUG-ADP SEPARATELY IF GREEN USING THE HEAT-ZONE. NOTE: IGNITION MODULE, VALVE, PILOT AND WALL SWITCH OPERATE ON 3 VOLTS. Figure 12.1 IntelliFire Pilot Ignition (IPI) Wiring Diagram Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 43: Electrical Service And Repair

    Romex connector. See Figure 12.4. • Make all necessary wire connections to the junction box/receptacle and reattach the junction box/receptacle to the outer shell. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 44: Finishing

    See Figure 13.2. Figure 13.2 Step 3. Place the top side of splatter guard behind the left and right panel brackets and in front of the glass. See Figure 13.3. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 45: Mantel And Wall Projections

    Figure 13.4 Minimum Vertical and Maximum Horizontal all minimum clearances to combustibles as specifi ed in Dimensions of Combustibles this manual. Overlapping materials could ignite and will interfere with proper operation of doors and louvers. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 46: Finishing Materials Requirements

    See Figure 9.2, 9.3, 13.6 and 13.7. • The fi nishing material must NEVER pass the 1/2 inch metal edge around the opening and overhang into the glass opening. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 47: Appliance Setup

    NOTICE: Do NOT place Mystic Embers over lighted area of lens. Lens may melt if covered. • Save the remaining ember materials for use during fi replace servicing. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 48: Install The Log Assembly

    fi rebox fl oor covering the bulb as shown. The four tabs on the lens frame go into the square cut out to help locate the lens. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 49 fl oor (see Figure A). The log will be in front of the orange Kapton lens. Figure A Figure B Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 50 fi ts into the right vertical grate tine. The back of the log rests in the small fl at spot on top of Log #3. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 51 fl oor of the fi replace. Do NOT put Mystic em- bers on the burner surface around the ports. Place embers around the pilot wires to disguise the wires from view. 2052-945B Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 52: Fixed Glass Assembly

    UPPER GLASS CLIP Figure 14.1 Fixed Glass Assembly H. Install the Mesh The pull-type fi rescreen hangs on the three hanger brack- ets located above the glass. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 53: Troubleshooting

    Verify module is securely grounded to metal chassis of appliance. D. Module voltage output / Valve/Pilot Verify battery voltage is at least 2.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 2.7. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 54 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 55: Reference Materials

    FROM UNIT FACE Location Inches Millimeters Location Inches Millimeters 1219 11-5/8 28-3/8 3-5/8 41-3/8 1052 1068 56-7/8 1445 72-1/8 1831 1320 2-5/8 1-1/2 4-1/4 40-3/8 1062 Figure 16.1 Appliance Dimensions Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 56: Vent Components Diagrams

    (254 mm) 14 in. (356 mm) 5 in. 12 in. (127 mm) (305 mm) 6 in. (152 mm) DVP-HVS (Vent Support) DVP-WS (Wall Shield Firestop) Figure 16.2 DVP vent components Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 57 79 mm 117 mm Length DVP-TRAP 5-3/8 in. 9-3/8 in. Trap2 Horizontal Termination Cap 137 mm 238 mm DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 DVP-HPC1 DVP-HPC2 Figure 16.3 DVP vent components Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 58 Cap Shield 13-7/8 in. 9-1/2 in. 26 in. (352 mm) (241 mm) 660 mm 14 in. (356 mm) DVP-HSM-B Extended Heat Shield DRC-RADIUS Figure 16.4 DVP vent components Cap Shield Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 59 1 in. (25 mm) (222 mm) 7-3/4 to 10-3/8 in. (197 to 264 mm) 1-5/8 in. (41 mm) DVP-FBHT FireBrickTermination Cap DVP-HPC High Performance Cap Figure 16.5 DVP vent components Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 60 9-3/16 IN. (233 mm) 13-5/8 16-11/16 IN. 16-11/16 IN. (346 mm) 424 mm (424 mm) 12-1/2 IN. (318 mm) SLP-LPC SLP Low Profi le Cap Figure 16.6 Vent Components Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 61 2052-185 Burner Assembly 2052-006 Log Grate 2052-002 Kapton 2101-252 Kapton Bracket 2052-193 Ember Bulb 2088-136 Glass Assembly GLA-ESCAPE-42 Mesh Assembly 2146-031 Additional service part numbers appear on following page. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 62: Service Parts List

    Orifi ce Bracket Flex Tube 2012-008 17.6 Wire Assembly 593-590A 17.7 302-320A 12”” Flex Ball Valve Assembly 17.8 Control Module 593-592 Additional service part numbers appear on following page. Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 63: C. Service Parts List

    Pilot Orifi ce NG Post OCT 2005 593-528 Pre OCT 2005 446-517 Pilot Orifi ce LP Post OCT 2005 593-527 Regulator NG Regulators are no longer applicable, must replace valve Regulator LP Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
  • Page 64: Contact Information

    5647340, 5890485, 5941237, 5947112, 5996575, 6006743, 6019099, 6053165, 6145502, 6170481, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729 or other U.S. and foreign patents pending. 2000-945 Printed in U.S.A. - Copyright 2011 Heat & Glo • Escape-42DV • 2052-900 Rev. X • 3/11...
