Mac OS X (10.3/10.4/10.5)....................... 4-4 4.2.1 Installing the printer driver......................... 4-4 4.2.2 Selecting and connecting the printer (OS 10.4/10.5) ................ 4-4 4.2.3 Selecting and connecting the printer (OS 10.3) ................4-8 Test page print..........................4-11 VarioLink 9522 (Version 2) Contents-1...
Page 4
About properties window........................ 8-3 8.1.1 Properties window ..........................8-3 About button ............................ 8-4 Combination of the function ......................8-5 General tab ............................8-6 Sharing tab ............................8-7 Ports tab ............................8-8 Advanced tab ........................... 8-9 Contents-2 VarioLink 9522 (Version 2)
Page 5
UNIX Printing through TCP/IP....................12-24 12.4 ToneCurve Utility ......................... 12-30 Appendix 13.1 Setting the software switch......................13-3 13.2 Procedure for installation with Linux ..................13-5 13.3 Glossary ............................13-9 13.4 Software License List ......................... 13-13 Index VarioLink 9522 (Version 2) Contents-3...
Page 9
The VarioLink 9522 is a copier equipped with a image controller function which allows you to print directly from a Windows compliant computer. And using a PostScript driver provided as an option also allows you to print from Macintosh.
Agfa Microtype fonts. For a complete list, refer to "Font" on page 11-3. When equipping PostScript kit option, the image controller also includes support for Adobe PostScript 3 (PS3) and includes the 136 built-in Adobe fonts. For a complete list, refer to "Font" on page 11-3. VarioLink 9522 (Version 2)
Page 11
Océ Technologies B.V. Venlo. will have no liability for any influences caused by using the printing system and this User’s Guide. Information written in this User's Guide is subject to change without notice. Océ Technologies B.V. Venlo. maintains the copyright of this printer driver. VarioLink 9522 (Version 2)
Please refer to this guide for how to use Plug-in driver in user mode. To operate safely, be sure to read "Section 2: Precautions for Installation and Use" in User’s Guide [Copier] before using the machine. VarioLink 9522 (Version 2)
Introduction About this manual This document describes how to operate VarioLink 9522 as a printer from various computers and networks. This manual assumes you are familiar with the basic operation of your operating system and the Océ copier. The Océ copier comes is with User’s Guide. Refer to these manuals as needed.
Above OSs Windows 2000/XP/Vista Windows 2000/XP/Vista/Server 2003/ Server 2008 Mac OS X Detail For Windows XP/Vista/Server 2003/Server 2008, the following are included; that is, Windows XP Professional, Windows Vista, Server 2003/Server 2008 that are 64bit OS. VarioLink 9522 (Version 2)
Text highlighted in this manner contains useful information and tips to ensure safe use of the machine. Reminder Text highlighted in this manner contains information that should be reminded. Detail Text highlighted in this manner contains references for more detailed information. VarioLink 9522 (Version 2)
Page 16
The names of keys on the control panel are written as shown above. MACHINE SETTING Display texts are written as shown above. Note The machine illustrations shown in this manual can vary and depend on the machine configuration. 1-10 VarioLink 9522 (Version 2)
C.F.R. 227.7202-1 through 227.7202-4, all U.S. Government End Users acquire the Software with only those rights set forth herein. You agree that you will not export the Software in any form in violation of any applicable laws and regulations regarding export control of any countries. VarioLink 9522 (Version 2) 1-11...
Page 18
License Agreement to the extent that this agreement contains provisions which relate to your use of the Software, Font Programs and Typefaces. Such provisions are made expressly for the benefit of Adobe and are enforceable by Adobe in addition to Océ-Technologies B.V. Venlo. 1-12 VarioLink 9522 (Version 2)
Page 21
Overview Overview The image controller feature enables the copier to connect to computers and networks to use as a printer. Copier VarioLink 9522 (Version 2)
Refer to "Installation of the printer driver (Windows) (Manual installation using the Add Printer wizard)" on page 3-3 and "Installation of the printer driver (Macintosh)" on page 4-3 for more information about installation of printer driver. Refer to the "User’s Guide (PostScript3 Plug-in Driver)" for more information about Plug-in Driver. VarioLink 9522 (Version 2)
Trimmer Unit option (TU-502) enables to select "Center Staple and Fold + Trim" function. Note Installing various options built in the copier properly on the printer driver allows you to use a variety of printing functions shared by the copier. VarioLink 9522 (Version 2)
Printing in which AppleTalk, Bonjour from Macintosh is used. (An optional PS expansion kit will be required.) IPP (Internet Printing Protocol) printing Printing in which Novell NetWare is used. 2.3.2 USB connection The USB interface can be connected to a computer. VarioLink 9522 (Version 2)
Same as the copier Pentium M 2.0GHz (Memory Access Speed 533MHz) System Memory Power Obtain from main body printer Network Interface Ethernet (1000BASE-T / 100Base-TX / 10Base-T) Temperature Same as the copier Humidity Same as the copier VarioLink 9522 (Version 2)
Although the Weekly Timer function of the main body printer is available in the Printer mode, the power is not turned off until the data output is finished when print data remains in the Image memory. Note Specifications are subject to change without notice. VarioLink 9522 (Version 2)
Windows XP/Server 2003 • "Windows XP/Server 2003" on page 3-11 Windows 2000 • "Windows 2000" on page 3-16 The Driver CD contains the PCL printer driver, and the PS Driver CD contains the PostScript PPD printer driver. VarioLink 9522 (Version 2)
Select printer driver (PCL, PostScript PPD) to be used. Click [OK]. Printers list window appears. Click [Next]. Follow the on-screen instructions. – If the Windows Logo Testing or Digital Signature dialog box appears, click the [Continue] or [Yes]. VarioLink 9522 (Version 2)
Page 31
The Install the printer driver dialog box appears. Click the [Have Disk]. Click the [Browse]. Specify the desired folder on the CD-ROM that contains the printer driver, and then click the [Open]. – Select printer driver (PCL, PostScript PPD) to be used. VarioLink 9522 (Version 2)
<IP_address_of_machine>/ipp Example: If the IP address of the copier is 192.168.1.20, enter http://192.168.1.20/ipp. – When specifying to use IPP printing, enter "https:// <host name>.<domain name>/ipp". The window for confirming the user name and password may appear in the course of installation. VarioLink 9522 (Version 2)
Select the device name of the copier, and then click "Install" from the toolbar. The selected Web Service print-supporting printer is found, and then the Found New Hardware Wizard dialog box appears. Click [Locate and install driver software (recommended)]. A screen for confirming the search method appears. VarioLink 9522 (Version 2)
Page 34
– A printer is searched that is compatible with the Web service print of an IP address entered, and then a the Found New Hardware Wizard dialog box appears. Click [Locate and install driver software (recommended)]. VarioLink 9522 (Version 2)
Page 35
If the "User Account Control" window appears, click the [Continue]. Click the [Finish]. When the installation is completed, make sure that the icon of the installed printer appears in the Printers window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. VarioLink 9522 (Version 2)
Click the [Finish]. When the installation is completed, make sure that the icon of the installed printer appears in the Printers window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. 3-10 VarioLink 9522 (Version 2)
For an LPR connection, select "LPR", and then enter "Print" in the "Queue name" box. – For a Port9100 connection, select "RAW", and then enter the RAW port number (9100 at default) in the "Port Number" box. – The information entered here is case-sensitive. Click the [Next]. VarioLink 9522 (Version 2) 3-11...
For Windows Server 2003, double-click the "Add Printer" icon. The Add Printer Wizard starts. Click the [Next]. Select "Local printer attached to this computer", and then click the [Next]. – Clear the "Automatically detect and install my Plug and Play printer" check box. 3-12 VarioLink 9522 (Version 2)
"Printers and Other Hardware", and then click "Printers and Faxes". For Windows XP, click "Add a printer" on the "Printer Tasks" menu. – For Windows Server 2003, double-click the "Add Printer" icon. The Add Printer Wizard starts. Click the [Next]. VarioLink 9522 (Version 2) 3-13...
Page 40
Click the [Finish]. When the installation is completed, make sure that the icon of the installed printer appears in the Printers and Faxes window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. 3-14 VarioLink 9522 (Version 2)
Click the [Finish]. When the installation is completed, make sure that the icon of the installed printer appears in the Printers and Faxes window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. VarioLink 9522 (Version 2) 3-15...
"Port Number" box. – For an LPR connection, select "LPR", and then enter "Print" in the "Queue name" box. – The information entered here is case-sensitive. Click the [Next]. Click the [Finish]. The Add Printer Wizard appears. 3-16 VarioLink 9522 (Version 2)
Clear the "Automatically detect and install my Plug and Play printer" check box. The Select a Printer Port dialog box appears. Click "Create a new port", and select "Standard TCP/IP Port" for "Type of port:". Click the [Next]. – The Add Standard TCP/IP Printer Port Wizard starts. VarioLink 9522 (Version 2) 3-17...
In the Local or Network Printer dialog box, select "Network printer", and then click the [Next]. In the Locate Your Printer dialog box, select "Connect to a printer on the Internet or on your intranet". 3-18 VarioLink 9522 (Version 2)
Page 45
Click the [Finish]. When the installation is completed, make sure that the icon of the installed printer appears in the Printers window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. VarioLink 9522 (Version 2) 3-19...
Click the [Finish]. When the installation is completed, make sure that the icon of the installed printer appears in the Printers window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. 3-20 VarioLink 9522 (Version 2)
The test page is printed and the confirmation window appears. Verify that it is printed properly. Then, click [Yes]. The test print is completed. Note If it is not printed properly, verify the current status of this printing system. VarioLink 9522 (Version 2) 3-21...
Page 48
Installation of the printer driver (Windows) (Manual installation using the Add Printer wizard) 3-22 VarioLink 9522 (Version 2)
Compliant OS The printer driver is can be used on the following OS: Windows Printer Driver Mac OS X • "Mac OS X (10.3/10.4/10.5)" on page 4-4 The PS Driver CD contains the PostScript PPD printer driver. VarioLink 9522 (Version 2)
In OS 10.4, select "GENERIC" in "Print Using", select the desired model from the list of models, and then click the [Add]. – In OS 10.5, entering [GENERIC] in the text box for search allows you to find a driver with ease. VarioLink 9522 (Version 2)
Page 53
An option can also be set in the same manner as with [Options and Supplies] - [Driver] tabs in OS 10.5 ([Printer Setup] - [Installable Options] in OS 10.4), by selecting a relevant printer name in the [Print & Fax] window. The setting is completed when being registered with [Print & Fax]. VarioLink 9522 (Version 2)
Page 54
IPP setting for the copier: Enable IPP print in the IPP Setting screen of the copier. For details on IP Address and the IPP settings of this machine, refer to the User’s Guide [POD Administrator’s Reference]. VarioLink 9522 (Version 2)
Page 55
An option can also be set in the same manner as with [Options and Supplies] - [Driver] tabs in OS 10.5 ([Printer Setup] - [Installable Options] in OS 10.4), by selecting a relevant printer name in the [Print & Fax] window. The setting is completed when being registered with [Print & Fax]. VarioLink 9522 (Version 2)
Select "GENERIC" in "Printer Model", select the desired model from the list of models, and then click the [Add]. – If the selected printer is registered in the printer list, the setting procedure is completed. VarioLink 9522 (Version 2)
Page 57
For details on IP Address and the IPP settings of this machine, refer to the User’s Guide [POD Administrator’s Reference]. Specifying the TCP/IP setting for the computer On the "Apple" menu, select "System Preferences". Click the "Network" icon. From "Show", select "Built-in Ethernet". Click the TCP/IP tab. VarioLink 9522 (Version 2)
Page 58
Select "GENERIC" in "Printer Model", select the desired model from the list of models, and then click the [Add]. – If the selected printer is registered in the printer list, the setting procedure is completed. 4-10 VarioLink 9522 (Version 2)
Installation of the printer driver (Macintosh) Test page print Macintosh Macintosh has no standard test print function. Double-click [ReadMe.txt] in the Driver CD. Then, select [Print...] from [File] menu and make sure it is printed properly. VarioLink 9522 (Version 2) 4-11...
Page 60
Installation of the printer driver (Macintosh) 4-12 VarioLink 9522 (Version 2)
For Windows Vista/Server 2008, when the deletion confirmation screen is additionally displayed, click the [Delete]. Close the opened screen and restart the computer. – Be sure to restart the computer. – This completes the printer driver uninstallation. VarioLink 9522 (Version 2)
Page 64
The PNF file is the same number as the INF file. In Windows Vista/Server 2008, when you have deleted a file using "Remove driver and driver package", this operation is not required. VarioLink 9522 (Version 2)
Drag the "95BW-1" folder, which is located in "Library" - "Printers" - "GENERIC", to the "Trash" icon. Drag the following file, which is located in "Library" - "Receipts", to the Trash icon. – GENERIC_95BW-1_103.pkg Restart the computer. – This completes the printer driver uninstallation. VarioLink 9522 (Version 2)
Page 66
Uninstallation of the printer driver VarioLink 9522 (Version 2)
Command name may be different depending on the application. The [Print] dialog appears. Select printer in pull down menu besides the [Name]. Click [Preferences] to set detail if necessary. Click [OK] if a required setup is finished. The display returns to the [Print] dialog. VarioLink 9522 (Version 2)
Page 70
Make sure that compliant printer name is selected in the [Printer]. – Refer to "PostScript PPD printer driver setting (Mac OS X)" on page 9-3 for more information about print setup. Click [Print]. The image controller receives and processes a print job sent from your computer. VarioLink 9522 (Version 2)
You can make a print with a color paper by specifying a desired color paper from the printer driver. Operating System Printer Driver Refer to Windows "Basic tab" on page 7-15 PostScript PPD "Advanced Options windows" on page 8-18 Mac OS X PostScript PPD "Setup (Print window)" on page 9-12 VarioLink 9522 (Version 2)
Page 72
Enlargement Document Reduction To set the margins You can set the margins of output paper. Operating System Printer Driver Refer to Mac OS X PostScript PPD "Custom Paper Size (Page Setup window)" on page 9-8 Margin VarioLink 9522 (Version 2)
You can select and set a paper feed tray to be used from the list. Operating System Printer Driver Refer to Windows "Basic tab" on page 7-15 PostScript PPD "Device Settings tab" on page 8-12 Mac OS X PostScript PPD "Paper Feed (Print window)" on page 9-11 Paper feed tray VarioLink 9522 (Version 2)
Page 74
"Finish tab" on page 7-35 PostScript PPD "Advanced Options windows" on page 8-18 Mac OS X PostScript PPD "Finishing (Print window)" on page 9-18 Output tray Note The position of the output tray varies depending on the optional unit. VarioLink 9522 (Version 2)
In this printing system, you can print using two sets of copy machines. Operating System Printer Driver Refer to Windows "Finish tab" on page 7-35 PostScript PPD "Advanced Options windows" on page 8-18 Mac OS X PostScript PPD "Finishing (Print window)" on page 9-18 Sub copier Master copier VarioLink 9522 (Version 2)
Page 76
Selects to shift the exit position of each set of printout back and forth when printing multi set of copies. Operating System Printer Driver Refer to Windows "Basic tab" on page 7-15 PostScript PPD "Advanced Options windows" on page 8-18 Mac OS X PostScript PPD "Finishing (Print window)" on page 9-18 Offset Copies 6-10 VarioLink 9522 (Version 2)
"Layout tab" on page 7-27 PostScript PPD "Layout tab" on page 8-15 Mac OS X PostScript PPD "Layout (Print window)" on page 9-10 2 in 1 4 in 1 6 in 1 9 in 1 16 in 1 VarioLink 9522 (Version 2) 6-11...
Page 78
Prints a specific page so that it comes on the front, especially when printing on both sides of the paper. Operating System Printer Driver Refer to Windows "Layout tab" on page 7-27 1'st page of a chapter 6-12 VarioLink 9522 (Version 2)
Page 79
"Finishing (Print window)" on page 9-18 Face down Face up Not to print blank page Selects not to print out blank pages in the document. Operating System Printer Driver Refer to Windows "Layout tab" on page 7-27 VarioLink 9522 (Version 2) 6-13...
Sets to insert a blank or printer paper which uses a different paper from that for the body pages. Operating System Printer Driver Refer to Windows "Cover Mode tab" on page 7-40 Insertion Insertion sheet - Blank sheet - Printed 6-14 VarioLink 9522 (Version 2)
Page 81
Cover Sheet Feeder To set a tab paper Sets to print tab paper. You can set the text, tab position, and number of tabs. Operating System Printer Driver Refer to Windows "Cover Mode tab" on page 7-40 VarioLink 9522 (Version 2) 6-15...
Refer to Windows "Configure tab" on page 7-11 PostScript PPD "Device Settings tab" on page 8-12 Mac OS X PostScript PPD "The method to open the [Printer Info] window (v10.4/v10.5)" on page 9-3 Punch Unit 6-16 VarioLink 9522 (Version 2)
Page 83
Sets to fold an output paper at the center, bind it at the center, fold it in a Z-shape or fold it into three, cut it. Operating System Printer Driver Refer to Windows "Finish tab" on page 7-35 PostScript PPD "Advanced Options windows" on page 8-18 Mac OS X PostScript PPD "Finishing (Print window)" on page 9-18 VarioLink 9522 (Version 2) 6-17...
Printer Driver Refer to Windows "Stamp/Composition tab" on page 7-46 To create a new watermark Creates a new Watermark printed on the output paper. Operating System Printer Driver Refer to Windows "Stamp/Composition tab" on page 7-46 6-18 VarioLink 9522 (Version 2)
Page 85
Operating System Printer Driver Refer to Windows "Stamp/Composition tab" on page 7-46 To set numbering Prints the copy number to the printed page. Operating System Printer Driver Refer to Windows "Stamp/Composition tab" on page 7-46 VarioLink 9522 (Version 2) 6-19...
Operating System Printer Driver Refer to Windows "Quality tab" on page 7-52 PostScript PPD "Advanced Options windows" on page 8-18 Mac OS X PostScript PPD "Image/Layout (Print window)" on page 9-15 Normal Toner Save Draft 6-20 VarioLink 9522 (Version 2)
To set the format of the font that is to be downloaded (download font format) Selects the font format to be downloaded to the printer (Outline or BMP). Operating System Printer Driver Refer to Windows "Quality tab" on page 7-52 VarioLink 9522 (Version 2) 6-21...
Protects a print job with a password when printing a confidential document. Operating System Printer Driver Refer to Windows "Basic tab" on page 7-15 Mac OS X PostScript PPD "Security (Print window)" on page 9-23 6-22 VarioLink 9522 (Version 2)
Note This chapter is described by using the printer window of Windows Vista. The properties window may differ from the window displayed by the printing command of applications. VarioLink 9522 (Version 2)
Help When the [Help] is clicked, Help information appears. As well, when you click [Help] which ap- pears when right-clicking a desired item, pop-up help for the item appears. VarioLink 9522 (Version 2)
When you select a function which causes a confliction with the settings already configured, the message will be displayed This is a confirmation message to decide which setting will be turned off. When this message is displayed, click [OK]. VarioLink 9522 (Version 2)
Displays the property window of the selected printer. You can change the setting of the printer driver with the property window. Print test page Prints a test page of Windows. You can print a test page without using any application. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
The method to open the Properties window depends on OS. Refer to "About properties window" on page 7-3 about how to open the Property window. By using this [Sharing] tab, you can make the printer available to network users. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
Using this button enables you to configure the selected port from above list. Enable printer pooling Enables printing to two or more identical print devices by using one logical printer. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
Sets to print the spooled document irrespective of a priority settings. Keep printed documents Sets to hold the spooled data of the documents after printing. Enable advanced printing features Enables the advanced printing features. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
The method to open the Properties window depends on OS. Refer to "About properties window" on page 7-3 about how to open the Property window. For more information, refer to the manual of the Windows. 7-10 VarioLink 9522 (Version 2)
Be sure to select the options from the "Device Option". Paper Type settings Indicates the paper type specified for each tray. Click the [Paper Tray Settings] button to specify the settings for each paper tray. VarioLink 9522 (Version 2) 7-11...
Page 100
The [Acquire Device Information] function cannot be used unless you are connected and able to communicate with the copier. Acquire settings Specifies the conditions of the connection destination to execute Acquire Device Information. Software tools Starts up software tools such as Web Connection. 7-12 VarioLink 9522 (Version 2)
Turn on the checkbox when the output method of Basic tab is fixed to the Secure Print. Popup the user settings dialog at secure print Displays the User Settings dialog box when a secure print is specified. VarioLink 9522 (Version 2) 7-13...
Page 102
PCL printer driver setting (Windows) Save Custom Size Saves the custom paper sizes. Acquire Device Information Communicate with the copier to read the Custom size that has been registered and display it in the list. 7-14 VarioLink 9522 (Version 2)
The method to open the Printing Preference window depends on OS. Refer to "About properties window" on page 7-3 about how to open the Printing Preference window. Paper - Orientation Sets the orientation to output paper in [Portrait] or [Landscape]. The default is [Portrait]. VarioLink 9522 (Version 2) 7-15...
Page 104
8 1/2 x 11 W 5 1/2 x 8 1/2 W A4 Tab 8 1/2 x 11 Tab Custom Size Note When [Custom Size] is selected, it is possible to set and register the original size. 7-16 VarioLink 9522 (Version 2)
Page 105
ISO-B4 W ISO-B5 W 11 x 17 W 8 1/2 x 11 W 5 1/2 x 8 1/2 W A4 Tab 8 1/2 x 11 Tab Custom Size The default is the Same as original size. VarioLink 9522 (Version 2) 7-17...
Page 106
8 1/2 e 11W/5 1/2 e 8 1/2W/A4 Tab/8 1/2 e 11 Tab/Custom Size Paper Type (Paper Name) Make a selection to decide if complying with the Default Setting or using the name registered in the information of the Paper Name. 7-18 VarioLink 9522 (Version 2)
Page 107
This is set when printing the user specified paper set on the copier. Embossed This is set when printing the embossed paper. Blank Insert This is set when printing blank paper such as cover sheet. VarioLink 9522 (Version 2) 7-19...
Page 108
Update Paper Name - Acquire Device Information Communicate with the copier to read the information of the Paper Name that has been registered and display it in the list. Output Method - Print Sets the normal printing. 7-20 VarioLink 9522 (Version 2)
Page 109
Click [Preferences] to open the [Printing Preferences] window. Select [Secure Print] in the [Output Method]. [Secure Print Settings] window appears. Enter [Secure Print ID] and [Password]. – Secure Print ID: Enter the confidential box name. – Password: Enter the password. VarioLink 9522 (Version 2) 7-21...
Page 110
Select the file to print and press [>>>]. Select [Auto] and press the [OK]. Confidential file is printed. Detail To confirm the settings for Confidential Output, select [Wait] or [Proof], and press [OK]. For more information, refer to "User’s Guide (Network Scanner)". 7-22 VarioLink 9522 (Version 2)
Page 111
The print jobs will be saved in the built-in hard disc (HDD-A) of the copier. Detail For details of the method for outputting the print jobs saved (Output from the HDD-A), refer to the User’s Guide (Network Scanner). VarioLink 9522 (Version 2) 7-23...
Page 112
If you do not change any setting, proceed to the step 10. If necessary, select the item and press the [ChangeSatting] to change settings. Press the [OK]. The Mode Check screen will be restored. Press [START] to resume the rest of the print job. 7-24 VarioLink 9522 (Version 2)
Page 113
File Name: Enter a file name when a file is saved in the box. User Box Number: Enter a box number of a box into which a job is saved. Authentication/Account Track Sets the User Authentication mode/Account Track. Detail Contact your administrator about User Authentication/Account Track. VarioLink 9522 (Version 2) 7-25...
Page 114
Offset Only when the finisher unit has been setup, select to shift the next position of each set of print out back and forth when printing multi set of copies. 7-26 VarioLink 9522 (Version 2)
Prints multiple pages onto a single sheet of the paper. The page that has been allocated is reduced for "N in 1" and enraged for "N x N" against the document. 2 in 1 4 in 1 6 in 1 9 in 1 16 in 1 2 x 2 3 x 3 4 x 4 VarioLink 9522 (Version 2) 7-27...
Page 116
Selects the number of pages to be printed onto a single sheet. Layout Order Selects the printing order of pages. Border Selects whether draw a frame or line as the border between pages. Overlap width line Selecting "N x N" sets "Overlap width line". 7-28 VarioLink 9522 (Version 2)
Page 117
Blank pages might be printed out even if this is set, depending on the data in the document. The [Skip Blank Page] cannot be set in the following cases: [Combination] is available in [Layout] tab. VarioLink 9522 (Version 2) 7-29...
Page 118
This is the front side A specified page The [Chapter] cannot be set in the following cases: The [1-Sided] is selected in the [Layout] tab - [Print Type]. When the [Fold] check box is ON in [Finish] tab. 7-30 VarioLink 9522 (Version 2)
Page 119
When an item other than [2-Sided] is selected in the [Layout] tab - [Print Type]. Binding Position Sets the binding position for the document to be printed. The position selected here will be the position of stapling, punching and base position of the image shift. VarioLink 9522 (Version 2) 7-31...
Page 120
Adjusts the details of the printing position to the output paper. Example: When the settings are shifted to the right by 100 and down by 300. (Unit: 0,1 mm) Shifted down by 30 mm Shifted to the right by 10 mm 7-32 VarioLink 9522 (Version 2)
Page 121
7-41, the relevant page is shifted to the right by the specified shift amount. However, since there is no function provided to specify the position of the tab, it is necessary to set up in advance the correct print information at the tab position. VarioLink 9522 (Version 2) 7-33...
Page 122
(When this function is turned on, the setting of [Image Shift] is applicable only to those other than the Tab Paper.) The movement of 10 -15 mm to the right is available. Moving allows printing on the Tab section. 7-34 VarioLink 9522 (Version 2)
Configures the special functions of the image controller. Detail The method to open the Printing Preference window depends on OS. Refer to "About properties window" on page 7-3 about how to open the Printing Preference window. VarioLink 9522 (Version 2) 7-35...
Page 124
Center Staple and Fold Staples at the center of the output paper and folds it into half. The [Center Staple and Fold] cannot be set in the following cases: When [FS-611] is not available in [Configure] tab. 7-36 VarioLink 9522 (Version 2)
Page 125
(Landscape) The [Punch] cannot be set in the following cases: When [Punch Unit], [Punch Z-Fold Unit] or [Stream Punch] is not available in [Configure] tab. When [Booklet] is selected in [Setup] tab - [Print Type]. VarioLink 9522 (Version 2) 7-37...
Page 126
[Face Down] outputs paper with the printed side facing down. [Face Up] outputs paper with the printed side facing up. "(1 to N)" means to output paper starting with the first page. "(N to 1)" means to output paper starting with the last page. 7-38 VarioLink 9522 (Version 2)
Page 127
Refer to the "User’s Guide (POD Administrator’s Reference)" for more information about Tandem Mode. Sub copier Master copier Tandem Mode cannot be set in the following cases: When [Transparency Interleave] is selected. When [Enhanced Security] is set to ON. VarioLink 9522 (Version 2) 7-39...
Specifies the paper tray for the front cover. Paper Type (Paper Name) Make a selection to decide if complying with the Default Setting or using the name registered in the information of the Paper Name. 7-40 VarioLink 9522 (Version 2)
Page 129
Selects the list name from the list. Per Page Setting - Edit List Edits Per Page Setting. When select the Per Page Setting from the list and click this button, the [Per Page Setting] dialog mentioned above appears. VarioLink 9522 (Version 2) 7-41...
Page 130
Changes the list name. When click this button, the [Edit List Name] dialog appears. Per Page Setting - Staple Settings Sets to use staple in the Per Page Settings. When click this button, the [Staple Settings] dialog appears. 7-42 VarioLink 9522 (Version 2)
Page 131
When this button is clicked, the [Tab Text Details] dialog appears. You can configure the orientation, position, font name, font type, and font size. Tab Text Set the orientation and position of the tab text. Font Settings Set the font, font style and size of the tab text. VarioLink 9522 (Version 2) 7-43...
Page 132
And also, the continuous insertion of up to 20 sheets is available for each of the Font cover/Back cover. The [Back Cover from Post Inserter] cannot be set in the following cases: When the [Cover Sheet Feeder] is not selected in the [Configure] tab. 7-44 VarioLink 9522 (Version 2)
Page 133
Printed This is set when inserting the printed interleaf for the transparent sheet. Interleave Tray Uses to select the paper tray for Transparency Interleave. Note You can select when Transparency is set for Bypass Tray. VarioLink 9522 (Version 2) 7-45...
Input the watermark name in the [Watermark Name] and the new watermark text in the [Watermark Text], new watermark text appears in the [Current Watermark]. Delete Clicks this to delete the current watermark. Watermark Name Enter the Watermark Name. 7-46 VarioLink 9522 (Version 2)
Page 135
Controls the "lean" angle of the watermark by clicking the [,] or by typing a number in the text value box from -90 degrees to 90 degrees. Sharing The settings of the watermark are shared with other computers. VarioLink 9522 (Version 2) 7-47...
Page 136
Click [OK]. The [Printing Preferences] window closes. Click [Print]. Specify a location into which an overlay file is saved. Input the file name in the [File Name]. and click [Save]. – Use ".KFO" as the extension. 7-48 VarioLink 9522 (Version 2)
Page 137
Click [Print]. – Turn the [Print in Overlay] check box to OFF after printing has been completed. Along with the overlay data the document to be printed is printed on top of the overlay data. VarioLink 9522 (Version 2) 7-49...
Page 138
Not Front-Back Cover Page number is printed except front/back cover. Page Number - Starting Page Specifies the first page to print the page numbers. Page Number - Starting Page Number Specifies the initial page number to print. 7-50 VarioLink 9522 (Version 2)
Page 139
Distribution Number Stamping - Pages to Print Specifies the pages to print the copy number. You can choose either from [All Pages] or [1st Page Only]. Distribution Number Stamping - Starting Number Specifies the initial copy number to print. VarioLink 9522 (Version 2) 7-51...
[Type 3] is suitable for printing the curved sections of ornamental writings and fine characters. When check box is OFF, no smoothing operation is made. Toner Save Saves the consumption of toner by controlling printing density. Draft Print Prints lightly, which is suitable for draft documents. 7-52 VarioLink 9522 (Version 2)
Page 141
Checking on the [Text and Graphics] allows you to print colored characters and lines, and graphics clearly in black. Print with Black - All Checking on the [All] allows you to print all objects including image data such as picture image excepting white areas clearly in black. VarioLink 9522 (Version 2) 7-53...
Page 142
Displays the substitution settings of the True Type Font which is substituted with the built-in printer fonts. Use Printer Font - Font Substitution Settings Selects the printer fonts which substitutes for the highlighted True Type Font. 7-54 VarioLink 9522 (Version 2)
"Remove White Background" and "Thin Line Support" function are only for the PCL driver. Thin Line Support Print the extra-fine lines of the document. Check Driver Version Displays the version of the current printer driver. VarioLink 9522 (Version 2) 7-55...
Setting is saved and the name entered is displayed on the Favorite Setting list. To restore the setting in storage Setting in storage can be restored when required. Click [Favorite Setting] menu. Select the setting to be restored from the list. 7-56 VarioLink 9522 (Version 2)
Page 145
[Save] (extension: KFS). To delete the setting file Setting file can be deleted by the following method: Click [Edit] of the Favorite Setting. Select the file to delete from the list, click [Delete]. Click [Yes]. VarioLink 9522 (Version 2) 7-57...
Setting of the printer driver and status of the optional unit can be checked. To check the status of the optional unit Status of the optional unit can be checked by the image. Click [Printer View]. 7-58 VarioLink 9522 (Version 2)
Page 147
Paper Sources • Output Tray Icon view • Cover/Front Cover Page/Back Cover Page/ Per Page Setting • Watermark • Secure Print • Image Shift Detail Refer to the HELP for more information about Icon view. VarioLink 9522 (Version 2) 7-59...
Note This chapter is described by using the printer window of Windows Vista. The properties window may differ from the window displayed by the printing command of applications. VarioLink 9522 (Version 2)
Apply When the [Apply] is clicked, the present tab settings are saved. This button is useful when you want conduct other settings in other tabs, and the present tab settings are registered before using other tabs. VarioLink 9522 (Version 2)
This is a confirmation message to decide whether to restore the previous settings or keep the settings. When this message is displayed, select [Resolve all conflicts for me automatically] or [I will resolve the conflict myself]. When selecting [Resolve all conflicts for me automatically], the previous setting will be turned OFF. VarioLink 9522 (Version 2)
Displays the property window of the selected printer. You can change the setting of the printer driver with the property window. Print Test Page Prints a test page of Windows. You can print a test page without using any application. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
The method to open the Properties window depends on OS. Refer to "About properties window" on page 8-3 about how to open the Property window. By using this [Sharing] tab, you can make the printer available to network users. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
Gets the status information from the print device. Enable printer pooling Enables printing to two or more identical print devices by using one logical printer. Note For more information, refer to the manual of the Windows. VarioLink 9522 (Version 2)
Sets to print without spooling. Hold mismatched documents Sets to hold the document which does not match to the printer setup. Print spooled documents first Sets to print the spooled document irrespective of a priority settings. VarioLink 9522 (Version 2)
Page 158
PostScript PPD printer driver setting (Windows) Keep printed documents Sets to hold the spooled data of the documents after printing. Enable advanced printing features Enables the advanced printing features. Note For more information, refer to the manual of the Windows. 8-10 VarioLink 9522 (Version 2)
The method to open the Properties window depends on OS. Refer to "About properties window" on page 8-3 about how to open the Property window. Note For more information about Security tab, refer to the manual of the Windows. VarioLink 9522 (Version 2) 8-11...
Performs settings of PostScript and the options of the printer. Detail The method to open the Properties window depends on OS. Refer to "About properties window" on page 8-3 about how to open the Property window. 8-12 VarioLink 9522 (Version 2)
Page 161
Font Substitution Table Selects to substitute with printer fonts for the True Type Font or "Don’t Substitute". Available PostScript Memory Displays the available PostScript memory. For more information, refer to the Adobe PS User’s Guide. VarioLink 9522 (Version 2) 8-13...
Page 162
In this printing system, the following options are installable. Item Available settings Paper Source Unit None/LU-407/LU-408 Finisher None / FS-528/FS-611 Cover Sheet Feeder None/PI-506 Punch Z-Fold Unit None/PK-503/PK-504/PK-505(2/3 Hole)/PK-505(2/4 Hole)/ZU-607(2-Hole)/ ZU-607(2/3 Hole)/ZU-607(2/4Hole) Trimmer None/TU-502 Multi Hole Punch Unit None/GP-501 8-14 VarioLink 9522 (Version 2)
Sets the orientation to output paper in [Portrait], [Landscape] or [Rotated Landscape]. Page Order Selects the output order. [Front to Back] outputs paper starting with the first page. [Back to Front] outputs paper starting with the last page. VarioLink 9522 (Version 2) 8-15...
Page 164
2 in 1 4 in 1 6 in 1 9 in 1 16 in 1 Advanced Opens the [GENERIC 95BW-1 PS(P) Advanced Options] window. For more information, refer to "Advanced Options windows" on page 8-18. 8-16 VarioLink 9522 (Version 2)
This is set when printing blank paper such as cover sheet. User This is set when printing the user specified paper set on the copier. Advanced Opens the [GENERIC 95BW-1 PS(P) Advanced Options] window. For more information, refer to "Advanced Options windows" on page 8-18. VarioLink 9522 (Version 2) 8-17...
Advanced Options windows Performs advanced settings of the printer. Detail The method to open the Printing Preference window depends on OS. Refer to "About properties window" on page 8-3 about how to open the Printing Preference window. 8-18 VarioLink 9522 (Version 2)
Page 167
Tabloid Wide Note The paper with "Wide" at the end of the document size represents "Wide paper". Graphic - Scaling Prints by specifying the enlargement or reduction ratio in the range from 1% to 1000%. VarioLink 9522 (Version 2) 8-19...
Page 168
The [Output Tray] cannot be set in the following cases: Available option which is not selected in the [Device Settings] tab. When [Staple] is available, any item other than [Default] and [Main Tray] can not be set. 8-20 VarioLink 9522 (Version 2)
Page 169
Prints a document of 2 pages onto a single paper twice as big as a paper selected in the output paper. Example: 2 A4 size papers are aggregated on 1 A3 size paper. 2 in 1 Booklet 2 Repeat 2 Repeat Reversal (L) 2 Repeat Reversal (R) VarioLink 9522 (Version 2) 8-21...
Page 170
When the [Finisher] is not available in the [Device Settings] tab - [Installable Options] When the [Default] or [Main Tray] is not selected in the [Output Tray]. When any item other than [Z-fold] is selected in the [Fold]. 8-22 VarioLink 9522 (Version 2)
Page 171
When the [Punch Z-Fold Unit] or [Multi Hole Punch Unit] (When the multi holes punch function is used) is not available in the [Device Settings] tab - [Installable Options] When the other than [Z-fold] is selected in the [Fold]. VarioLink 9522 (Version 2) 8-23...
Page 172
Adjusts the details of the printing position to the output paper. Example: When the settings are shifted to the right by 100 and down by 300. (Unit: 0,1 mm) Shifted down by 30 mm Shifted to the right by 10 mm 8-24 VarioLink 9522 (Version 2)
Page 173
The [Back Cover Page] cannot be set in the following cases: When any item other than [Off] or [Z-Fold] is selected for the [Fold]. Back Cover Tray Specifies the paper tray for the back cover. VarioLink 9522 (Version 2) 8-25...
Page 174
Select [Wait Mode] to wait before printing the document to check the current setting from the control panel of copier. – Select [Proof and Print] to print the one copy as a test to check the output and the current setting from the control panel of copier. 8-26 VarioLink 9522 (Version 2)
Page 175
[Type1] is suitable for printing the diagonal lines of normal characters and graphics. [Type2] is suitable for printing the curved sections of normal characters. [Type3] is suitable for printing the curved sections of ornamental writings and fine characters. When [Off] is selected, no smoothing operation is made. VarioLink 9522 (Version 2) 8-27...
Page 176
A rule of thumb is used for the value of print density. Date/Time Specify the pages to print the date and time. Item Function All pages Date/Time is printed in the all pages. 1st Page Only Date/Time is printed in the 1st only. 8-28 VarioLink 9522 (Version 2)
Page 177
Tandem printing should only be set up by your authorized service representative. Refer to the "User’s Guide (POD Administrator’s Reference)" for more information about Tandem Mode. Sub copier Master copier Tandem Mode cannot be set in the following cases: When [Transparency Interleave] is selected. VarioLink 9522 (Version 2) 8-29...
The method to open the [Printer Info] window (v10.4/v10.5) On the "Apple" menu, select "System Preferences". Select [Print & Fax]. Select the printer and click [Options & Supplies] ([Printer Setup]). Select [Driver] ([Installable Options]). – [Printer Info] window appears. VarioLink 9522 (Version 2)
Page 182
Selects an installed Finisher. Cover Sheet Feeder Selects an installed Cover Sheet Feeder. Punch Z-Fold Unit Selects an installed Punch Z-Fold Unit. Trimmer Selects an installed Trimmer Unit. Multi Hole Punch Unit Selects an installed Multi Hole Punch Unit. VarioLink 9522 (Version 2)
Page 183
Select [Print] from File menu. – The [Print] window appears. Detail To perform printing, click [Print]. Selecting [Save As] on the [Presets] pop-up menu enables you to save the settings you configured in the [Print] window. VarioLink 9522 (Version 2)
Selects [Page Attributes] on the [Settings] pop-up menu in the [Page Setup] window. Detail Refer to the "The method to open the [Page Setup] window" on page 9-5. Format for Selects the printer you want to use. VarioLink 9522 (Version 2)
Page 185
Prints by specifying the enlargement or reduction ratio in the range from 25% to 400%. The [Scale] cannot be set in the following cases: When the [Pages per Sheet] is set to any item other than [1]. VarioLink 9522 (Version 2)
You can register a new Custom Paper Size. In case of OS v10.4/v10.5, click [+] to create the custom page size. Paper Size Sets the height and width of the output paper. Printer Margins Sets the margins of the output paper. VarioLink 9522 (Version 2)
Prints all pages of the document. From [ ] To [ ] Enters the initial page number and the ending page number. If you want to print one page, enter the page number to the both boxes. VarioLink 9522 (Version 2)
6 in 1 9 in 1 16 in 1 Layout Direction Selects the layout direction the pages allocated onto a single paper. Border Selects whether draw a frame or line as the border between pages. 9-10 VarioLink 9522 (Version 2)
Prints the first page from the specified tray in upper box and remaining pages from the specified tray in lower box. Detail If you use [Auto Select], a paper feed tray is automatically selected. The paper specified in [Page Attributes] of this printing system is set on the tray. VarioLink 9522 (Version 2) 9-11...
When [Paper Source] is not available in the [Printer Info] dialog box. Paper Color Selects the colors of paper as the output paper as shown below. No Setting White Clear Yellow Pink Blue Green 9-12 VarioLink 9522 (Version 2)
Page 191
The [Back Cover] cannot be set in the following cases: When the [Collated] is not available in the [Print] - [Copies & Pages] When the [Pages per Sheets] is selected in the [Print] - [Layout] VarioLink 9522 (Version 2) 9-13...
Page 192
Sets this when you want to use [Transparency Interleave] as paper. Select either [Blank] or [Printed]. Interleave Tray Sets this when you want to use the paper feed tray for [Transparency Interleave]. [Interleave Tray] cannot be set in the following cases: [Transparency Interleave] is not set in the [Setup] window. 9-14 VarioLink 9522 (Version 2)
The [2in1] and [2 repeat] cannot be set in the following cases: When any item other than [Off] is selected for [Front Cover], [Back Cover], [PI Front Cove Tray] or [PI Back Cover Tray] in the [Print] - [Setup]. VarioLink 9522 (Version 2) 9-15...
Page 194
Displays the resolution of the printer (600 dpi). Print Density Selects the printing density. Item Print density Normal 100% 102% Toner Save Draft Print Note A rule of thumb is used for the value of print density. 9-16 VarioLink 9522 (Version 2)
Page 195
[Type 2] is suitable for printing the curved sections of normal characters. [Type 3] is suitable for printing the curved sections of ornamental writings and fine characters. When [Off] is selected, no smoothing operation is made. VarioLink 9522 (Version 2) 9-17...
Selects to shift the exit position of each set of print out back and forth when printing multi set of copies. The [Offset] cannot be set in the following cases: When the [Japanese Post Card], or [Custom] is selected for [Page Setup] - [Paper Size]. When the Finisher is not available. 9-18 VarioLink 9522 (Version 2)
Page 197
The [N to 1] outputs paper starting with the last page. Binding Position Sets the binding position for the document to be printed. The position selected here will be the position of stapling, punching and base position of the image shift. VarioLink 9522 (Version 2) 9-19...
Page 198
2 Staples/Top Binding (Portrait) (Portrait) The [Staple] cannot be set in the following cases: When the [Finisher] is not available in the [Printer Info] - [Installable Options]. When any item other than [Z-Fold] is selected for [Fold]. 9-20 VarioLink 9522 (Version 2)
Page 199
[Device Settings] tab - [Installable Options] When the [Post Card], [Wide paper (W)] or [Custom] is selected for [Page Setup] - [Paper Size]. When any item other than [Z-Fold] is selected for [Fold]. VarioLink 9522 (Version 2) 9-21...
Page 200
When any item other than [Off] is selected for the [Front Cover], [Back Cover], [PI Front Cover Tray] and [PI Back Cover Tray]. The setting of [Fold] is available when the following unit is installed. Item Punch Z-Fold Unit Finisher (FS-611) Z-Fold Multi-Letter Fold (In/Out) Multi-Half Fold 9-22 VarioLink 9522 (Version 2)
Enter [Secure Print ID] and [Password]. – Secure Print ID: Enter the confidential box name. – Password: Enter the password. Click [Print] to perform printing from the application. Press [RECALL] on the touch panel of copier. VarioLink 9522 (Version 2) 9-23...
Page 202
The [Save in User Box Settings] field becomes active. Enter [File Name] and [User Box Number] and click [Print] to perform printing from the application. The print jobs will be saved in the built-in hard disc (HDD-A) of the copier. 9-24 VarioLink 9522 (Version 2)
Page 203
The Mode Check screen will be restored. Press [START] to resume the rest of the print job. User Authentication/Account Track Sets the User Authentication mode/Account Track mode. Detail Contact your administrator about User Authentication/Account Track. VarioLink 9522 (Version 2) 9-25...
Page 204
User Authentication/Account Track (page 9-25) To print using these functions, you should enter the password on the control panel of the copier after transmitting the print data. Refer to "User’s Guide (Security)" for more information. 9-26 VarioLink 9522 (Version 2)
The current status is displayed on the dialog shown by double-clicking [Start] - [Printers and Faxes] - printing system currently used. Macintosh: The current status is displayed on the dialog shown by double-clicking the currently-used printer icon on the desktop. VarioLink 9522 (Version 2) 10-3...
Contact your Océ service representative if you cannot print the test page after performing the above procedures. The print setting of a job does not correspond to the result of printing Check that the printer setting was not changed. 10-4 VarioLink 9522 (Version 2)
Page 209
Check that any item other than [Custom Size] or [Japanese Post Card] is selected in [Output Tray] Check that [Plain Paper] is selected in the [Paper Type]. In the case of the PCL printer driver, check that the [Print type] setting is not [Booklet]. VarioLink 9522 (Version 2) 10-5...
The direction in which non fixed size paper is loaded in the copier may be in- printed correctly (Macintosh). correct. Rotate the paper direction 90 degrees and then try printing after changing the settings of the driver and copier accordingly. 10-6 VarioLink 9522 (Version 2)
If print jobs are not printed, you can check them on the Non complete Job List screen. To get the non complete job list screen to appear Press [JOB LIST] on the LCD panel. Press [Incomplete]. Check the Incomplete job. Detail For more information about job list, consult your system administrator. VarioLink 9522 (Version 2) 10-7...
For a list of the types of fonts available, refer to "Font list (PostScript)" on page 11-6. For details on the installation of screen fonts, refer to the ReadMe file in the Mac or Windows folder on the "PS Driver CD". 11-10 VarioLink 9522 (Version 2)
Page 223
In case of Windows 2000/XP/Server 2003, select [Install New Font] from the [File] menu. In the [folders] pane at the lower left, navigate to the location "\Screen fonts\Type 1 Fonts" folder on the "PS Driver CD". Click on [Select all]. Click on [OK]. VarioLink 9522 (Version 2) 11-11...
You can use "Font Management Utility" to add the PCL font and the PostScript font to the image controller or delete them from it. For details, refer to the User's Guide contained in UTILITIES CD-ROM [Font Management Utility]. 11-12 VarioLink 9522 (Version 2)
When the [Enhanced Security] is ON, the Web Connection function cannot be used. When the [Enhanced Security] is turned from ON to OFF, the Web Connection function is kept at [OFF]. To enable the Web Connection function, contact your administrator. VarioLink 9522 (Version 2) 12-3...
You can print the report as follows; PS Font List PS Demo Page PCL Font List PCL Demo Page Configuration page Make a direct Print Using the Web Connection allows you to make a Direct Print. 12-4 VarioLink 9522 (Version 2)
Device Information - Configuration Summary Click [Information] from the top navigation. The [Information] page appears. Click [Device Information] from the left navigation. The [Device Information] page appears. Click [Configuration Summary] from the sub navigation. The [Configuration Summary] page appears. VarioLink 9522 (Version 2) 12-5...
Page 230
Device Information - Option Click [Information] from the top navigation. The [Information] page appears. Click [Device Information] from the left navigation. The [Device Information] page appears. Click [Option] from the sub navigation. The [Option] page appears. 12-6 VarioLink 9522 (Version 2)
Page 231
Device Information - Consumables Click [Information] from the top navigation. The [Information] page appears. Click [Device Information] from the left navigation. The [Device Information] page appears. Click [Consumables] from the sub navigation. The [Consumables] page appears. VarioLink 9522 (Version 2) 12-7...
Page 232
Device Information - Meter Count Click [Information] from the top navigation. The [Information] page appears. Click [Device Information] from the left navigation. The [Device Information] page appears. Click [Meter Count] from the sub navigation. The [Meter Count] page appears. 12-8 VarioLink 9522 (Version 2)
Page 233
Utility Tool Device Information - Online Assistance Click [Information] from the top navigation. The [Information] page appears. Click [Online Assistance] from the left navigation. The [Online Assistance] page appears. VarioLink 9522 (Version 2) 12-9...
Page 234
Utility Tool Device Information - Network Setting Information Click [Information] from the top navigation. The [Information] page appears. Click [Network Setting Information] from the left navigation. The [Network Setting Information] page appears. 12-10 VarioLink 9522 (Version 2)
Page 235
Click [Information] from the top navigation. The [Information] page appears. Click [Print Setting Information] from the left navigation. The [Print Setting Information] page appears. Click [Default Setting] from the sub navigation. The [Default Setting] page appears. VarioLink 9522 (Version 2) 12-11...
Page 236
Click [Information] from the top navigation. The [Information] page appears. Click [Print Setting Information] from the left navigation. The [Print Setting Information] page appears. Click [Font Information] from the sub navigation. The [Font Information] page appears. 12-12 VarioLink 9522 (Version 2)
Page 237
Click [Information] from the top navigation. The [Information] page appears. Click [Print Setting Information] from the left navigation. The [Print Setting Information] page appears. Click [Macro List] from the sub navigation. The [Macro List] page appears. VarioLink 9522 (Version 2) 12-13...
Page 238
Click [Information] from the top navigation. The [Information] page appears. Click [Print Setting Information] from the left navigation. The [Print Setting Information] page appears. Click [PCL Setting] from the sub navigation. The [PCL Setting] page appears. 12-14 VarioLink 9522 (Version 2)
Page 239
Click [Information] from the top navigation. The [Information] page appears. Click [Print Setting Information] from the left navigation. The [Print Setting Information] page appears. Click [PS Setting] from the sub navigation. The [PS Setting] page appears. VarioLink 9522 (Version 2) 12-15...
Page 240
Click [Information] from the top navigation. The [Information] page appears. Click [Print Setting Information] from the left navigation. The [Print Setting Information] page appears. Click [TIFF Setting] from the sub navigation. The [TIFF Setting] page appears. 12-16 VarioLink 9522 (Version 2)
Page 241
Click [Current Jobs] from the left navigation. The [Current Jobs] page appears. After selecting [Print] or [Scanner Transmission] from the pull-down menu provided at the upper left of the list, click [Go] to change the contents of the list. VarioLink 9522 (Version 2) 12-17...
Page 242
Click [Job History] from the left navigation. The [Job History] page appears. After selecting [Print] or [Scanner Transmission] from the pull-down menu provided at the upper left of the list, click [Go] to change the contents of the list. 12-18 VarioLink 9522 (Version 2)
Click [Print Information] from the left navigation. The [Print Information] page appears. Select the report type to be printed. Click [Print]. The report is printed. Note About the report type, refer to "Report to be printed" on page 12-4. VarioLink 9522 (Version 2) 12-19...
Click [Direct Print] from the top navigation. The [Direct Print] page appears. Click [Browse], select file to be printed and click [OK]. The [Direct Print] page will be restored. Click [Print]. The direct print of a specified file is made. 12-20 VarioLink 9522 (Version 2)
If NDS is not set up properly for the print server and Bindery Service mode is not operating, the print server cannot find the file server and Novell NetWare protocol will be indicated as inactive in the Status Page. VarioLink 9522 (Version 2) 12-21...
Page 246
NetWare allows the use of PCONSOLE as an alternative of NWADMIN. PCONSOLE is used to set up static information of print servers regarding which queues to service and to whom information is given in case of trouble. Detail Refer to the Novell NetWare manual for details of setup with PCONSOLE of NDS. 12-22 VarioLink 9522 (Version 2)
Page 247
If you are sure that the bindery context exists in the file server, you can set up the print server with PCONSOLE. Detail Refer to the Novell NetWare manual for details of setup with PCONSOLE. In Bindery mode, only upper-case letters are valid for the printer server password. VarioLink 9522 (Version 2) 12-23...
If the systems you are using do not run lpd, refer to "Installing UNIX TCP/IP programs". The UNIX-TCP/IP Programs on accompanying CD-ROM also include source code so that you can recompose host-based code for configuring on other System V platforms. 12-24 VarioLink 9522 (Version 2)
Page 249
You can indicate to the network interface card lpd what type of image controller it is attached to by either: Accepting the default port setting (PCL, PostScript and other), or Changing the listed emulations via a standard IP based Web Browser. The sections that follow give specific lpd setup instructions for various systems. VarioLink 9522 (Version 2) 12-25...
Page 250
NIC IP hostname Short Form Filter /usr/lpd/bsdshort Required value Long Form Filter /usr/lpd/bsdlong Required value Name of remote printer queue PRINT Network interface card Name of device to add print1 Name of local queue 12-26 VarioLink 9522 (Version 2)
Page 251
<IP address of the network interface card> Ping should confirm your IP address with the message: – <IP address of the network interface card> is alive If the connection is confirmed, you can now print. VarioLink 9522 (Version 2) 12-27...
Page 252
Y – Enter another printer name or quit setup: Q If necessary, stop and restart your remote daemon. Using a line editor of your choice, edit the /etc/printcap file and change the: rp=entry to PRINT. 12-28 VarioLink 9522 (Version 2)
Page 253
-p <local printername> -s <remote host name or IP address> – !PRINT – Your system may want its IP address instead of the remote host name. Enable <local printername> Accept <local printername> Printing on Linux VarioLink 9522 (Version 2) 12-29...
[Keep 100% Density for Text] gets active only when the output value of the tone curve is set below 100%. When [Keep 100% Density for Text] is not checked, take note of the density of characters. 12-30 VarioLink 9522 (Version 2)
Page 255
Since putting a check on [Use CIE Color] causes a color conversion process to be conducted through the XYZ color space, the level of gradient can be raised, in which case, however, a longer time may be required for output. VarioLink 9522 (Version 2) 12-31...
(3) No.8: [0], No.9: [1] --> +0.9mm - -0.9mm The permissible range gets narrower in the or- der of (1) --> (2) --> (3) and is more liable to be recognized as an irregular size. VarioLink 9522 (Version 2) 13-3...
Page 260
IPSec. operation is made with ICMPv6 not eliminated After switching over, the main power is re- from IPSec. (Normally, the operation is made quired to be turned OFF and ON. with ICMPv6 eliminated from IPSec.) 13-4 VarioLink 9522 (Version 2)
Get the PPD file that has been copied read into the CUPS. And then restart the CUPS. – For example: Enter "/etc/init.d/cups restart". – The following command may be available depending on the method by which the installation is made. – /etc/re.d/init.d/cups restart – /sbin/init.d/cups restart – "killall-HUP cupsd" VarioLink 9522 (Version 2) 13-5...
Page 262
Specifying printer driver settings Displaying the settings page Start up the Web browser. Enter the URL "http://localhost:631", and then click [Manage Printers]. Printer on localhost.localdomain window appears. Click [Configure Printer]. The printer driver settings page appears. 13-6 VarioLink 9522 (Version 2)
Page 263
Example using OpenOffice or using Star Suite Paper sizes supported by the VarioLink 9522 may not be displayed when the OpenOffice is being used. In such a case, follow the procedure given below. However, the procedure described here is applicable when the OpenOffice 1.0.2 is used on the RedHat9 and the procedure and operation given below may...
Page 264
A list of the currently active print jobs appear. Detail To check the status of completed print jobs, click [Show Complete Jobs]. Refer to "Advanced Options windows" on page 8-18 for more information about "Finishing Options". 13-8 VarioLink 9522 (Version 2)
Gateway Hardware or software serving as a point connecting networks. Not only connecting, it converts the format, address, protocol, etc. of the data according to the network to be connected. VarioLink 9522 (Version 2) 13-9...
Page 266
Indicates IEEE1284 for connecting the printer in many cases. Abbreviation of Portable Document Format. One of electronic documents (extension; .pdf) in the format based on PostScript which can be accessed using Adobe Acrobat Reader, software free of charge. 13-10 VarioLink 9522 (Version 2)
Page 267
Used to identify how many high-order bits of an IP address are the network address. TCP/IP Abbreviation of Transmission Control Protocol/Internet Protocol. Substantially the standard protocol used for the Internet. Uses IP address to identify each network device. VarioLink 9522 (Version 2) 13-11...
Page 268
To delete installed software. Abbreviation of Universal Serial Bus. General-use interface standard for connecting a computer and a mouse, printer, etc. Web browser Software to access web pages. Internet Explorer, Netscape Navigator, etc. are exam- ples. 13-12 VarioLink 9522 (Version 2)
You must make sure that they, too, receive or can get the source code. And you must tell them their rights. We protect your rights with two steps: (1) copyright the software, and VarioLink 9522 (Version 2) 13-13...
Page 270
General Public License. Any attempt otherwise to copy, modify, sublicense, distribute or transfer the Program is void, and will automatically terminate your rights to use the Program under this License. However, parties who have 13-14 VarioLink 9522 (Version 2)
Page 271
Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston MA 02110-1301 USA Also add information on how to contact you by electronic and paper mail. If the program is interactive, make it output a short notice like this when it starts in an interactive mode: VarioLink 9522 (Version 2) 13-15...
Page 272
To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all. The precise terms and conditions for copying, distribution and modification follow. 13-16 VarioLink 9522 (Version 2)
Page 273
Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.) VarioLink 9522 (Version 2) 13-17...
Page 274
Free Software Foundation. If the Program does not specify a version number of this License, you may choose any version ever published by the Free Software Foundation. 13-18 VarioLink 9522 (Version 2)
Page 275
Here is a sample; alter the names: Yoyodyne, Inc., hereby disclaims all copyright interest in the program `Gnomovision' (which makes passes at compilers) written by James Hacker. <signature of Ty Coon>, 1 April 1989 Ty Coon, President of Vice VarioLink 9522 (Version 2) 13-19...
Page 276
Because of this blurred distinction, using the ordinary General Public License for libraries did not effectively promote software sharing, because most developers did not use the libraries. We concluded that weaker conditions might promote sharing better. 13-20 VarioLink 9522 (Version 2)
Page 277
License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the Library, the distribution of VarioLink 9522 (Version 2) 13-21...
Page 278
Library among them, as well as a reference directing the user to the copy of this License. Also, you must do one of these things: 13-22 VarioLink 9522 (Version 2)
Page 279
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License. VarioLink 9522 (Version 2) 13-23...
Page 280
Also add information on how to contact you by electronic and paper mail. You should also get your employer (if you work as a programmer) or your school, if any, to sign a "copyright disclaimer" for the library, if necessary. Here is a sample; alter the names: 13-24 VarioLink 9522 (Version 2)
Page 281
General Public License. It also provides other free software developers Less of an advantage over competing non-free programs. These disadvantages are the reason we use the ordinary General Public License for many libraries. However, the Lesser license provides advantages in certain special circumstances. VarioLink 9522 (Version 2) 13-25...
Page 283
License. If the work during execution displays copyright notices, you must include the copyright notice for the Library among them, as well as a reference directing the user to the copy of this License. Also, you must do one of these things: VarioLink 9522 (Version 2) 13-27...
Page 284
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply, and the section as a whole is intended to apply in other circumstances. 13-28 VarioLink 9522 (Version 2)
Page 285
This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version 2.1 of the License, or (at your option) any later version. VarioLink 9522 (Version 2) 13-29...
Page 286
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. 2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. 13-30 VarioLink 9522 (Version 2)
Page 287
The word 'cryptographic' can be left out if the rouines from the library being used are not cryptographic related :-). 4. If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement: "This product includes software written by Tim Hudson (tjh@cryptsoft.com)" VarioLink 9522 (Version 2) 13-31...
Page 288
NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE. Part 2: Networks Associates Technology, Inc copyright notice (BSD) Copyright (c) 2001-2003, Networks Associates Technology, Inc All rights reserved. 13-32 VarioLink 9522 (Version 2)
Page 289
Neither the name of the Sun Microsystems, Inc. nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. VarioLink 9522 (Version 2) 13-33...
Page 290
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. krb5-Libs License Copyright (C) 1985-2005 by the Massachusetts Institute of Technology. All rights reserved. permission notice 13-34 VarioLink 9522 (Version 2)
Page 291
6. No license is granted to "mirror" the Unicode website where a fee is charged for access to the "mirror" site. 7. Modification is not permitted with respect to this document. All copies of this document must be verbatim. VarioLink 9522 (Version 2) 13-35...
Page 292
UNICODE, INC. LICENSE AGREEMENT - DATA FILES AND SOFTWARE Unicode Data Files include all data files under the directories http://www.unicode.org/Public/, http://www.unicode.org/reports/, and http://www.unicode.org/cldr/data/ . Unicode Software includes any source code published in the Unicode Standard or under the directories http://www.unicode.org/Public/, http://www.unicode.org/reports/, and http://www.unicode.org/cldr/data/. 13-36 VarioLink 9522 (Version 2)
Page 293
(ii) the names of Sam Leffler and Silicon Graphics may not be used in any advertising or publicity relating to the software without the specific, prior written permission of Sam Leffler and Silicon Graphics. VarioLink 9522 (Version 2) 13-37...
Page 294
Sun or its licensors is granted under this Agreement. Additional restrictions for developers and/or publishers licenses are set forth in the Supplemental License Terms. 13-38 VarioLink 9522 (Version 2)
Page 295
Binary Code License Agreement. These Supplemental Terms shall supersede any inconsistent or conflicting terms in the Binary Code License Agreement, or in any license contained within the Software. VarioLink 9522 (Version 2) 13-39...
Page 296
Deploying Applications with the J2SE Runtime Environment ======================================================== When you deploy an application written in the Java programming language, your software bundle will probably consist of the following parts: Your own class, resource, and data files. A runtime environment. 13-40 VarioLink 9522 (Version 2)
Page 297
The following section contains a list of the files and directories that may optionally be omitted from redistributions with the J2SE Runtime Environment. All files not in these lists of optional files must be included in redistributions of the runtime environment. ----------------------------------------------------------------------- Optional Files and Directories ----------------------------------------------------------------------- VarioLink 9522 (Version 2) 13-41...
Page 298
Java support in Internet Explorer and Mozilla family browsers; these files are not needed in a private JRE redistribution. bin/java.exe bin/javaw.exe bin/javaws.exe bin/javacpl.exe bin/jucheck.exe bin/jusched.exe bin/JavaWebStart.dll bin/NPJPI*.dll (The filename changes in every release) bin/NPJava11.dll bin/NPJava12.dll bin/NPJava13.dll 13-42 VarioLink 9522 (Version 2)
Page 299
These alternative soundbanks may be included in redistributions of the J2SE Runtime Environment. - The javac bytecode compiler, consisting of the following files: bin/javac [Solaris(TM) Operating System and Linux] bin/sparcv9/javac [Solaris Operating System (SPARC(R) Platform Edition)] VarioLink 9522 (Version 2) 13-43...
Page 300
Redistributors may also override classes in the org.w3c.dom.*packages, or other classes whose sole purpose is to implement these APIs. ----------------------------------------------------------------------- The cacerts Certificates File ----------------------------------------------------------------------- Root CA certificates may be added to or removed from the J2SE certificate file located at <java- home>/lib/security/cacerts. 13-44 VarioLink 9522 (Version 2)
Page 301
For written permission, please contact apache@apache.org. 5. Products derived from this software may not be called "Apache", nor may "Apache" appear in their name, without prior written permission of the Apache Software Foundation. VarioLink 9522 (Version 2) 13-45...
Page 302
"Not a Contribution." "Contributor" shall mean Licensor and any individual or Legal Entity on behalf of whom a Contribution has been received by Licensor and subsequently incorporated within the Work. 13-46 VarioLink 9522 (Version 2)
Page 303
Your own behalf and on Your sole responsibility, not on behalf of any other Contributor, and only if You agree to indemnify, defend, and hold each Contributor harmless for any liability incurred by, or claims asserted against, such Contributor by reason of your accepting any such warranty or additional liability. VarioLink 9522 (Version 2) 13-47...
Page 304
5. Products derived from this software may not be called "IAIK PKCS Wrapper", nor may "IAIK" appear in their name, without prior written permission of Graz University of Technology. 13-48 VarioLink 9522 (Version 2)
Page 305
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. VarioLink 9522 (Version 2) 13-49...
Page 306
OF THE SOFTWARE OR DOCUMENTATION WILL NOT INFRINGE ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADEMARKS OR OTHER RIGHTS.COPYRIGHT HOLDERS WILL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF ANY USE OF THE SOFTWARE OR DOCUMENTATION. 13-50 VarioLink 9522 (Version 2)
Page 307
Copyright FAQ for common questions about using materials from our site, including specific terms and conditions for packages like libwww, Amaya, and Jigsaw. Other questions about this notice can be directed to site-policy@w3.org. VarioLink 9522 (Version 2) 13-51...
Page 308
4. The names "Apache" and "Apache Software Foundation" and "Apache Turbine" must not be used to endorse or promote products derived from this software without prior written permission. For written permission, please contact apache@apache.org. 13-52 VarioLink 9522 (Version 2)
Page 309
Use of any of this software is governed by the terms of the license below: Copyright Status SAX is free! In fact, it's not possible to own a license to SAX, since it's been placed in the public domain. No Warranty VarioLink 9522 (Version 2) 13-53...
Page 310
The licenses which follow do not apply to binary distributions of the software. They are applicable only to source distributions. The following software may be included in this product: Common Unix Printing System API Libraries (CUPS API library); 13-54 VarioLink 9522 (Version 2)
Page 311
Do not make any other change in these notices. Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License applies to all subsequent copies and derivative works made from that copy. VarioLink 9522 (Version 2) 13-55...
Page 312
It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally accompany the operating system. Such a contradiction means you cannot use both them and the Library together in an executable that you distribute. 13-56 VarioLink 9522 (Version 2)
Page 313
Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally. VarioLink 9522 (Version 2) 13-57...
Page 314
Original Code, SGI hereby grants Recipient a worldwide, royalty-free, non-exclusive license, to do the following: (i) under copyrights Licensable by SGI, to reproduce, distribute, create derivative Apache License 13-58 VarioLink 9522 (Version 2)
Page 315
(c) You must retain, in the Source form of any Derivative Works that You distribute, all copyright, patent, trademark, and attribution notices from the Source form of the Work, excluding those notices that do not pertain to any part of the Derivative Works; and VarioLink 9522 (Version 2) 13-59...
Page 316
"AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License. jaxen.codehaus.org, Apache ’style’ license $Id: LICENSE,v 1.3 2002/04/22 11:38:45 jstrachan Exp $ Copyright (C) 2000-2002 bob mcwhirter & James Strachan. 13-60 VarioLink 9522 (Version 2)
Page 317
In addition, we request (but do not require) that you include in the end-user documentation provided with the redistribution and/or in the software itself an acknowledgement equivalent to the following: "This product includes software developed by the JDOM Project (http://www.jdom.org/)." Alternatively, the acknowledgment may be graphical using the logos available at http://www.jdom.org/images/logos. VarioLink 9522 (Version 2) 13-61...
Page 318
JDF Schema, JDF Editor, Online Documentation for C++ API, the Alces application, the Elk application, and any part or component thereof (hereinafter "CIP4 Software"). Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 13-62 VarioLink 9522 (Version 2)
Page 319
4.1 above until they begin to sell, market or attempt to sell such products. 5 END USER DOCUMENTATION VarioLink 9522 (Version 2) 13-63...
Page 320
L. Peter Deutsch. Thanks to all the people who reported problems and suggestd various imporvements in zlib; they are too numerous to cite here. libjpeg This software is based in part on the work of the independent JPEG Group 13-64 VarioLink 9522 (Version 2)
