18. Untie and discard the wire tie on the Upright
Wire (60).
Orient the Console Cover (11) as shown. While
a second person holds the Console Cover near
the Upright (5), insert the Upright Wire (60) and
the Extension Wire (121) upward through the
Console Cover.
Then, slide the Console Cover (11) onto the
Upright (5).
19. Have a second person hold the Handlebar (10)
near the Upright (5).
Locate the Pulse Wires (79) in the Handlebar
(10). Insert the Pulse Wires into the hole in the
front of the Upright (5). Then, pull the Pulse
Wires upward out of the top of the Upright.
20. Insert the Upright Wire (60), the Extension Wire
(121), and the Pulse Wires (79) upward through
the Handlebar (10).
Tip: Avoid pinching the wires. Attach the
Handlebar (10) to the Upright (5) with two M8 x
16mm Screws (102).
18
121
60
19
79
20
102
60
15
11
5
10
5
Avoid pinching
the wires
79
10
5
121
