Wires on J7 (below small relays)
Brown to White
Blue to J11 (Lwr oven relay board only)
Black jumper to J11
Red to J11 (Lwr oven relay board only)
Violet with white to J11
Black to J11
White with Black to J11 (Upr oven relay
board only)
White with Red to J11 (Upr oven relay
board only)
0 ohms when oven light is on
120V when convection fan turns CCW
120V when convection fan is on
120V when convection fan turns CW
120V when broil element is on
120V when oven door latch is activated
120V when cooling fan is in high speed
120V when cooling fan is in low speed
– 49 –
(Continued Next Page)
