GE Profile PT925 Technical Service Manual page 36

4. Remove the three 1/4-in. hex-head screws
that attach the broiler element to the oven
cavity.
5. Carefully pull out the sensor approximately 2
inches from the broiler element bracket.
6. Remove the four 1/4-in. hex-head screws that
attach the broil element to the top of the oven.
7. Carefully pull, then lower the broiler element
towards the front of the oven to remove.
Bake Element
The upper bake element is rated at 1700 watts, and
the lower element is rated at 2200 watts.
The bake element terminals are located behind the
main rear access panel.
To remove the bake element:
1. Remove the main rear access panel. (See
)
Access Panels.
IMPORTANT: The lower wattage elements use
3/16-in. terminal connections. The higher wattage
elements use 1/4-in. terminal connections.
2. Disconnect the wires from the bake element.
Disconnect
3. Remove the two 1/4-in hex-head screws that
hold the bake element to the back of the oven.
4. Carefully pull the bake element out through the
front of the oven.
Convection Fan Blade
The convection fan blade is located on the back wall
of the oven cavity and is removed separately from
the convection fan motor.
To remove the convection fan blade:
1. Remove the oven racks.
2. Remove the four 1/4-in. hex-head screws that
hold the convection cover to the back wall of the
oven cavity.
Rear
3. The fan blade is attached to the motor shaft
with a reverse-threaded 1/2-in. hex-nut. Turn
the nut clockwise to remove.
Disconnect
