Intel Xeon Processor E5-1600 Datasheet page 21

Overview
Enhanced Intel
SpeedStep® Technology
Execute Disable Bit
Flit
Functional Operation
IMC
IIO
Intel® ME
Intel® QuickData
Technology
Intel® QuickPath
Interconnect (Intel® QPI)
Intel® 64 Technology
Intel® Turbo Boost
Technology
Intel® TXT
Intel® Virtualization
Technology (Intel® VT)
Intel® VT-d
Intel® Xeon® processor
E5-1600 product family
and Intel® Xeon®
processor E5-2600
product family
Intel® Xeon® processor
E5-4600 product family
Integrated Heat Spreader
(IHS)
Jitter
IOV
LGA2011-0 land FCLGA10
Socket
Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families
Datasheet Volume One
Term
Allows the operating system to reduce power consumption when performance is
not needed.
The Execute Disable bit allows memory to be marked as executable or non-
executable, when combined with a supporting operating system. If code
attempts to run in non-executable memory the processor raises an error to the
operating system. This feature can prevent some classes of viruses or worms
that exploit buffer overrun vulnerabilities and can thus help improve the overall
security of the system. See the Intel® 64 and IA-32 Architectures Software
Developer's Manuals for more detailed information.
Flow Control Unit. The Intel QPI Link layer's unit of transfer; 1 Flit = 80-bits.
Refers to the normal operating conditions in which all processor specifications,
including DC, AC, system bus, signal quality, mechanical, and thermal, are
satisfied.
The Integrated Memory Controller. A Memory Controller that is integrated in the
processor die.
The Integrated I/O Controller. An I/O controller that is integrated in the
processor die.
Intel® Management Engine (Intel® ME)
Intel QuickData Technology is a platform solution designed to maximize the
throughput of server data traffic across a broader range of configurations and
server environments to achieve faster, scalable, and more reliable I/O.
A cache-coherent, link-based Interconnect specification for Intel processors,
chipsets, and I/O bridge components.
64-bit memory extensions to the IA-32 architecture. Further details on Intel 64
architecture and programming model can be found at
http://developer.intel.com/technology/intel64/.
Intel® Turbo Boost Technology is a way to automatically run the processor core
faster than the marked frequency if the part is operating under power,
temperature, and current specifications limits of the Thermal Design Power
(TDP). This results in increased performance of both single and multi-threaded
applications.
Intel® Trusted Execution Technology
Processor virtualization which when used in conjunction with Virtual Machine
Monitor software enables multiple, robust independent software environments
inside a single platform.
Intel® Virtualization Technology (Intel® VT) for Directed I/O. Intel VT-d is a
hardware assist, under system software (Virtual Machine Manager or OS)
control, for enabling I/O device virtualization. Intel VT-d also brings robust
security by providing protection from errant DMAs by using DMA remapping, a
key feature of Intel VT-d.
Intel's 32-nm processor design, follow-on to the 32-nm 2nd Generation Intel®
Core™ Processor Family design. It is the first processor for use in Intel® Xeon®
processor E5-1600 and E5-2600 product families-based platforms. Intel®
Xeon® processor E5-1600 product family and Intel® Xeon® processor E5-2600
product family supports Efficient Performance server, workstation and HPC
platforms
Intel's 32-nm processor design, follow-on to the 32-nm processor design. It is
the first processor for use in Intel® Xeon® processor E5-4600 product family-
based platforms. Intel® Xeon® processor E5-4600 product family supports
scalable server and HPC platforms for two or more processors, including glueless
four-way platforms.
A component of the processor package used to enhance the thermal
performance of the package. Component thermal solutions interface with the
processor at the IHS surface.
Any timing variation of a transition edge or edges from the defined Unit Interval
(UI).
I/O Virtualization
The processor mates with the system board through this surface mount,
LGA2011-0 land FCLGA10 contact socket, for the Intel® Xeon® processor E5
product family-based platform.
Description
21
