Intel Xeon Processor E5-1600 Datasheet page 172

2. This table is intended to aid in reading discrete points on graph in
3. The loadlines specify voltage limits at the die measured at the VCC_SENSE and VSS_VCC_SENSE lands.
Voltage regulation feedback for voltage regulator circuits must also be taken from processor VCC_SENSE
and VSS_VCC_SENSE lands. Refer to the VR12/IMVP7 Pulse Width Modulation Specification for loadline
guidelines and VR implementation details.
4. The Vcc_min and Vcc_max loadlines represent static and transient limits. Please see
Overshoot specifications.
5. The Adaptive Loadline Positioning slope is 0.8 m .
6. The 8/6-core Icc ranges are as follows:
• 0-185 A for 150 W processor
• 0-165 A for 135 W, 130 W, 115 W processors
• 0-135 A for 95 W, LV95W-8C processors
• 0-100 A for 70 W, LV70W-8C processors
• 0-85 A for 60 W processors
Figure 7-3. 8/6-Core: V
Table 7-14. 4/2-Core: Processor V
I (A)
CC
0
5
10
15
19
25
30
35
40
45
50
55
172
Static and Transient Tolerance Loadlines
CC
Static and Transient Tolerance (Sheet 1 of 2)
CC
V (V) V
CC_MAX CC_TYP
VID + 0.015 VID - 0.000
VID + 0.011 VID - 0.004
VID + 0.007 VID - 0.008
VID + 0.003 VID - 0.012
VID + 0.000 VID - 0.015
VID - 0.005 VID - 0.020
VID - 0.009 VID - 0.024
VID - 0.013 VID - 0.028
VID - 0.017 VID - 0.032
VID - 0.021 VID - 0.036
VID - 0.025 VID - 0.040
VID - 0.029 VID - 0.044
Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families
Figure 7-3.
(V) V (V)
CC_MIN
VID - 0.015
VID - 0.019
VID - 0.023
VID - 0.027
VID - 0.030
VID - 0.035
VID - 0.039
VID - 0.043
VID - 0.047
VID - 0.051
VID - 0.055
VID - 0.059
Electrical Specifications
Section 6 for Vcc
Notes
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
1,2,3,4,5,6
Datasheet Volume One
