Handling rolls

Handling rolls
Attaching the Roll Holder to Rolls ...................................................................................................................... 439
Loading Rolls in the Printer ................................................................................................................................ 442
Changing the Type of Paper .............................................................................................................................. 445
Specifying the Paper Length .............................................................................................................................. 447
Removing the Roll from the Printer ..................................................................................................................... 447
Removing the Roll Holder from Rolls ................................................................................................................. 450
Feeding Roll Paper Manually ............................................................................................................................. 451
Keeping Track of the Amount of Roll Paper Left ................................................................................................ 452
Specifying the Ink Drying Time for Rolls ............................................................................................................ 452
Specifying the Cutting Method for Rolls ............................................................................................................. 454
Cutting the Leading Edge of Roll Paper Automatically ...................................................................................... 458
Reducing Dust from Cutting Rolls ...................................................................................................................... 460

Attaching the Roll Holder to Rolls

Attaching the Roll Holder to Rolls

When printing on rolls, attach the Roll Holder to the roll.
Rolls have a two- or three-inch paper core. Use the correct attachment for the paper core. The printer comes equipped
with the 2-Inch Paper Core Attachment installed.
Using Rolls with a 2-Inch Paper Core
Holder Stopper (Left Side)
2-Inch Paper Core Attachment
•
Set the roll on a table or other flat surface so that it does not roll or fall. Rolls are heavy, and dropping a roll may cause injury.
Caution
•
When handling the roll, be careful not to soil the printing surface. This may affect the printing quality. We recommend wearing
clean cloth gloves when handling rolls to protect the printing surface.
Important
•
Use scissors or a cutting tool to cut the edge of the roll paper if it is uneven, dirty, or has tape residue. Otherwise, it may
cause feeding problems and affect the printing quality. Be careful not to cut through any barcodes printed on the roll.
•
Align the edges of the paper on both ends of the roll. Misalignment may cause feeding problems.
User's Guide
Roll Holder (Right Side) Holder Stopper (Left Side)
No Attachment Needed 3-Inch Paper Core Attachment L
Using Rolls with a 3-Inch Paper Core
Roll Holder (Right Side)
3-Inch Paper Core Attachment R
Attaching the Roll Holder to Rolls
439
