ADTRAN T3SU 300 User Manual

Hide thumbs Also See for T3SU 300:
Table of Contents

Advertisement

Quick Links

Download this manual
T3SU 300 User Manual
1202217L1 DC Version Including AC Mains Power Supply
1200218L1 HSSI DTE Interface Card
1200219L1 V.35 DTE Interface Card
1200284L1 Quad DSX-1 Interface Card
1200655L1 Quad Bridge Module
1202217L2 AC Version
1202217L4 DC Version
61202217L1-1B
June 2004

Advertisement

Table of Contents
loading

Related Manuals for ADTRAN T3SU 300

Summary of Contents for ADTRAN T3SU 300

  • Page 1 T3SU 300 User Manual 1202217L1 DC Version Including AC Mains Power Supply 1200218L1 HSSI DTE Interface Card 1200219L1 V.35 DTE Interface Card 1200284L1 Quad DSX-1 Interface Card 1200655L1 Quad Bridge Module 1202217L2 AC Version 1202217L4 DC Version 61202217L1-1B June 2004...
  • Page 2 Spectrum is a registered trademark of Cabletron. Netview is a registered trademark of IBM. 901 Explorer Boulevard P.O. Box 140000 Huntsville, AL 35814-4000 (256) 963-8000 © 2004 ADTRAN, Inc. All Rights Reserved. Printed in U.S.A. T3SU 300 User Manual 61202217L1-1B...

  • Page 3: About This Manual

    The following is an overview of the contents of this manual: • Chapter 1, Introduction, familiarizes you with fiber networks and T3SU 300 highlights and gives a brief explanation of the option cards that may be purchased for use with the T3SU 300.

  • Page 4: Safety Instructions

    Use only the power cord, power supply, and/or batteries indicated in the manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for special disposal instructions. Save These Important Safety Instructions T3SU 300 User Manual 61202217L1-1B...
  • Page 5 (CPE) to 1.544 Mbps or subrate digital services. Until such time as subrate digital terminal equipment is registered for voice applications, the affidavit requirement for subrate services is waived. 61202217L1-1B T3SU 300 User Manual...
  • Page 6 I attest that the operator(s)/maintainer(s) of the digital CPE responsible for the establishment, maintenance, and adjustment of the encoded analog content and billing information has (have) been trained to perform these functions by successfully having completed one of the following (check appropriate blocks): T3SU 300 User Manual 61202217L1-1B...
  • Page 7 _________________________________Signature _________________________________Title _________________________________ Date Transcribed and sworn to before me This ________ day of _______________, _______ _________________________________ Notary Public My commission expires: _________________________________ 61202217L1-1B T3SU 300 User Manual...
  • Page 8 Advance notification and the opportunity to maintain uninterrupted service are given. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected or it is certain the equipment is not malfunctioning.
  • Page 9 This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. Contact your state public utility commission or corporation commission for information. 61202217L1-1B T3SU 300 User Manual...

  • Page 10: Federal Communications Commission Radio Frequency Interference Statement

    Shielded cables must be used with this unit to ensure compliance with Class A FCC limits. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. T3SU 300 User Manual 61202217L1-1B...
  • Page 11 “Digital Apparatus,” ICES-003 of the Department of Communications. Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee par le ministre des Communications. 61202217L1-1B T3SU 300 User Manual...

  • Page 12: Warranty And Customer Service

    PURPOSE. SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES, SO THIS EXCLUSION MAY NOT APPLY TO CUSTOMER. In no event will ADTRAN or its suppliers be liable to the Customer for any incidental, special, punitive, exemplary or consequential damages experienced by either the...
  • Page 13 ADTRAN is not liable for damages for any cause whatsoever (whether based in contract, tort, or otherwise) in excess of the amount paid for the item. Some states do not allow the limitation or exclusion of liability for incidental or consequential damages, so the above limitation or exclusion may not apply to the Customer.
  • Page 14 Customer Service, Product Support Information, and Training ADTRAN will repair and return this product if within 5 years from the date of shipment the product does not meet its published specification or the product fails while in service. A return material authorization (RMA) is required prior to returning equipment to ADTRAN.
  • Page 15 Pre-Sales Inquiries and Applications Support Your reseller should serve as the first point of contact for support. If additional pre- sales support is needed, the ADTRAN Support web site provides a variety of support services such as a searchable knowledge base, latest product documentation, application briefs, case studies, and a link to submit a question to an Applications Engineer.
  • Page 16 Installation and Maintenance Support The ADTRAN Custom Extended Services (ACES) program offers multiple types and levels of installation and maintenance services which allow you to choose the kind of assistance you need. This support is available at: http://www.adtran.com/aces For questions, call the ACES Help Desk.

  • Page 17: Table Of Contents

    ADTRAN Shipments Include ........
  • Page 18 DTE Leads ............74 T3SU 300 User Manual...
  • Page 19 Glossary ..........127 61202217L1-1B T3SU 300 User Manual...
  • Page 20 T3SU 300 User Manual 61202217L1-1B...
  • Page 21 Figure 2-1. DC Power Connector ........33 Figure 2-2. T3SU 300 Rear View (AC Version) ......35 Figure 2-3.
  • Page 22 Figure 7-5. Voice Application .........115 T3SU 300 User Manual...
  • Page 23 Table A-4. V.35 Interface Card Pin Assignments ......119 Table A-5. Quad DSX-1 Interface Card Pin Assignments ....120 61202217L1-1B T3SU 300 User Manual...
  • Page 24 T3SU 300 User Manual 61202217L1-1B...

  • Page 25: Product Overview

    The T3SU 300 has a built-in HSSI (high speed serial interface) port along with three expansion slots which accept additional HSSI, V.35, Quad DSX-1, or Ethernet Bridge interface cards. The HSSI interfaces support rates between 75 kbps and 44.2 Mbps in 75 kbps...

  • Page 26: T3 Overview

    Internet backbones and public organizations needing broad bandwidth for WAN (wide area network) connectivity. SNMP The T3SU 300's embedded SNMP feature allows the unit to be accessed and controlled by a network manager through either the auxiliary (AUX) control port or the 10BaseT local area network...

  • Page 27: Telnet

    TELNET Telnet provides a password-protected, remote login facility to the T3SU 300 that allows a remote user to control the T3SU 300 through the terminal menus. Only one Telnet session may be active at a time.

  • Page 28: Hssi Card

    Quad DSX-1 Card The optional Quad DSX-1 interface card plugs into the card slots on the rear of the T3SU 300. This card allows you to transport up to four DSX-1 lines per card over the DS3 interface of the T3SU 300 along with high-speed data from the other HSSI/V.35 ports.

  • Page 29: Ethernet Bridge Card

    Ethernet Bridge Card The optional Quad DSX-1 interface card plugs into the card slots on the rear of the T3SU 300. This card provides four auto-sensing 10/ 100 BaseT Ethernet ports. The Bridge module provides LAN-to- LAN connectivity using bridging over the WAN. Additionally, this module acts as a LAN switch to provide Layer 2 Ethernet switching between each of the ports on the module.
  • Page 30 Chapter 1. Introduction T3SU 300 User Manual 61202217L1-1B...

  • Page 31: Receiving Inspection

    Installation and Operation Chapter 2 RECEIVING INSPECTION Carefully inspect the T3SU 300 for any damage that may have occurred in shipment. If damage is suspected, file a claim immediately with the carrier and contact ADTRAN Technical Support (see the front section of this manual for contact information).

  • Page 32: Customer Provides

    115 VAC, 60 Hz receptacle. A three-position terminal block which accommodates 12 to 26 AWG wire is located on the rear panel of the T3SU 300 DC version. The positive (+) and negative (-) terminals connect to a 24 to 48 VDC, 0.4A power source. Figure 2-1 on page 33 provides an illustration of the terminal block power connector, along with definitions for the three connector symbols.

  • Page 33: Installing The Unit

    INSTALLING THE UNIT The T3SU 300 can be used as a desktop stand-alone device or mounted into a standard 19-inch equipment rack. The chassis can also be installed in a 23-inch equipment rack by using the 23-inch Rack Kit (P/N 1200171L1).

  • Page 34: Desktop Installation

    Desktop Installation Follow these steps when using your T3SU 300 as a desktop unit: Affix the four adhesive-backed rubber feet to the bottom of the unit, one in each of the four corners. The feet should be placed...

  • Page 35: Dte Port Interface Card Slots

    T3 service connection Figure 2-2. T3SU 300 Rear View (AC Version) DTE Port Interface Card Slots The T3SU 300 rear panel has three card slots for the installation of optional interface cards. To insert cards, perform the following procedure: Remove blank slot cover from the rear of the T3SU 300.

  • Page 36: Dte Port 1 (Hssi Interface)

    (POTS) connection for the internal V.34 modem. The T3SU 300 can be configured as a dial-in host and also as a dial- out-on-TRAP device (meaning that the unit dials out to a specified host to report error conditions). Configure the modem parameters...

  • Page 37: Ds3 Interface

    T3SU 300 is connected to the connector. TX OUT FRONT PANEL The T3SU 300 faceplate is shown in Figure 2-3. Descriptions of each part of the front panel follow. Figure 2-3. T3SU 300 Front Panel Control Port The T3SU 300 has an 8-pin modular jack labeled .

  • Page 38: Figure 2-4. Terminal Main Menu

    M OGOUT menu or by pressing Ctl-C at any time. Figure 2-4. Terminal Main Menu Navigating Within the Menus Navigate within the T3SU 300 terminal menus using the following procedures: If you want to... Press... select an item the number corresponding to your choice, and then press the Enter key.
  • Page 39 Remote Login The R selection allows you to configure the remote EMOTE OGIN T3SU 300. The remote unit’s password is required at login. The option (in the DS3 N menu) ETWORK ONFIGURATION must be enabled in order to perform remote configuration.

  • Page 40: Led Descriptions

    Remote Active This LED is solid when a remote configuration session is taking place through a Telnet session or from the remote end T3SU 300. It flashes when the unit is being accessed locally through the front panel port.
  • Page 41 This LED is active when the DTE interface is in a loopback condition or is performing a BERT test. This LED is active when the T3SU 300 DTE port is transmitting data. This LED is active when the T3SU 300 DTE port is receiving data. 61202217L1-1B T3SU 300 User Manual...
  • Page 42 Chapter 2. Installation and Operation T3SU 300 User Manual 61202217L1-1B...
  • Page 43 Configuration Chapter 3 The T3SU 300 can be configured locally and remotely. Local configuration is accomplished through a 10BaseT Ethernet connection, a SLIP/PPP port, or a VT100 terminal. Remote configuration can take place through the T3 datalink using a local T3SU 300.

  • Page 44: Ds3 Network

    DS3 NETWORK Select 1 DS3 N to access the network configuration ETWORK parameters. Configure the T3SU 300 network settings to match the T3 signal received from the service provider. During remote configuration, this menu is read-only. The DS3 N ETWORK menu is shown in Figure 3-2 on page 45.

  • Page 45: Ds3 Framing

    225 feet. HORT DS3 Timing Set the timing to L if the T3SU 300 is to derive timing from the network; set to L if the unit is to be the master timing source OCAL for the circuit.

  • Page 46: Ds3 Scrambler

    Data Link Set to E to allow for remote configuration. When enabled, the NABLE T3SU 300 provides a channel between the local and the remote DSU for point-to-point remote configuration. Remote Auto-Configuration This feature allows one T3SU 300 (set to M...

  • Page 47: Port Selections 1-4

    Table 3-2 on page 50 lists the menu fields available for V.35 interfaces (in addition to those listed in Table 3-1). • Table 3-3 on page 52 lists the menu fields available for DSX-1 interfaces. 61202217L1-1B T3SU 300 User Manual...

  • Page 48: Figure 3-4. Port Configuration Menu (V.35 Interface Card)

    Chapter 3. Configuration • Table on page 54 lists the menu fields available for Ethernet Bridge interfaces. Figure 3-4. Port Configuration Menu (V.35 Interface Card) T3SU 300 User Manual 61202217L1-1B...

  • Page 49: Table 3-1. Hssi And V.35 Configuration Selections

    10.5 Mbps). Changes to this field do not take effect until PPLY is selected. ETTINGS This read-only status field shows the amount of bandwidth that will be ANDWIDTH available if the selection made in the field is applied. LOCKS 61202217L1-1B T3SU 300 User Manual...

  • Page 50: Table 3-2. Additional V.35 Interface Port Configuration Selections

    Select this field after making all configuration changes for the selected PPLY ETTINGS port. The changes are then applied to the unit immediately. Applying the settings briefly affects all ports of the T3SU 300. You may cancel changes made to the current menu by pressing ONFIGURATION the ESC key.
  • Page 51 LOCK Transmit Clock Selects the source of the clock used to transfer data from the DTE to the T3SU 300. Use the following chart to determine your selection: Select... If... you want the transmit clock to be derived from the ORMAL T3SU 300.

  • Page 52: Figure 3-5. Port Configuration Menu (Quad Dsx-1 Interface Card)

    NSTALLED 1 interface. Displays the amount of bandwidth (in 75k increments) not already NALLOCATED allocated to any of the T3SU 300 DTE ports. LOCKS If an individual DSX-1 interface is installed but not currently in use, set TATE . Set to to activate a port.
  • Page 53 STUFFING Set the line length for each DSX-1 interface according to the distance ENGTH from the T3SU 300 to your DTE device. Set to 7.5 dB if the attached DTE device only supports DS-1 levels. DSX-1 T For each Quad DSX-1 card pair (the near- and far-end Quad DSX-1 IMING cards), there must be only one source of timing.

  • Page 54: Figure 3-6. Port Configuration Menu (Ethernet Bridge Interface Card)

    NSTALLED Ethernet Bridge interface. Displays the amount of bandwidth (in 75k increments) not already NALLOCATED allocated to any of the T3SU 300 DTE ports. LOCKS If an Ethernet Bridge module is installed but not currently in use, set to TATE .

  • Page 55: Timed Profiles

    For example, you can assign more bandwidth to the corporate LAN during business hours and more bandwidth to a backup machine in the evenings. The T3SU 300 can store two separate user profiles which have bandwidth selections for each of the four ports.

  • Page 56: Figure 3-7. Timed Profiles Screen

    (2) the profile is disabled manually through the A selection. CTIVE ROFILE Active Profile Use this field to either manually force a profile to become active (regardless of the time of day) or disable the profile completely. T3SU 300 User Manual 61202217L1-1B...

  • Page 57: System Management

    300 for management through SNMP, Telnet, or a VT100 interface. Embedded SNMP and Telnet are available through either a SLIP/ PPP or a 10BaseT Ethernet port. The S YSTEM ANAGEMENT menu is shown in Figure 3-9. ONFIGURATION Figure 3-9. System Management Configuration Menu 61202217L1-1B T3SU 300 User Manual...

  • Page 58: Local Ip Address

    Chapter 3. Configuration Local IP Address Enter the T3SU 300 IP address. This IP address applies to the Ethernet or auxiliary port (when configured for PPP or SLIP). This address is available from the network administrator. Subnet Mask Enter the subnet mask of the T3SU 300. This address is available from the network administrator.

  • Page 59: Management Port

    The port, located on the rear panel of the T3SU 300, provides a telephone line (POTS) for connecting to the internal V.34 modem. The modem interface can be configured for dial-in service in VT100, SLIP, and PPP modes.

  • Page 60: Trap Ip Addresses

    Chapter 3. Configuration Trap IP Addresses Enter up to five IP addresses of SNMP managers to which the T3SU 300 sends traps. Trap Generation This selection determines which trap types (if any) are generated by the unit. Use this menu (see Figure 3-10) to enable or disable N...

  • Page 61: Table 3-5. Near End Alarm Trap Descriptions

    Out of Frame (OOF) when the unit receives indication from the far end unit through the FEAC channel that the far end unit has lost frame synchronization with the network. 61202217L1-1B T3SU 300 User Manual...

  • Page 62: Table 3-7. Mib Ii Standard Trap Descriptions

    Link Down when a network condition prevents data transmission. This could be either an alarm or a network test. Auth. Failure when an SNMP request is made with the wrong read or write community names. T3SU 300 User Manual 61202217L1-1B...

  • Page 63: Password

    (previously described) between their disabled and enabled states. Password Set the password required at login (up to 32 characters). The default password is adtran (all lower case). Control Port Set the baud rate for the Control Port. The baud rate can be set to 57600 bps or 9600 bps.

  • Page 64: Unit Id

    If enabled, the alarm circuit is activated when a network alarm occurs. Dialup Options Configure the dial-up capabilities of the T3SU 300. See Figure 3-11 on page 65. Descriptions of the individual fields of this menu follow the figure.

  • Page 65: Figure 3-11. Dialup Options Menu

    Chapter 3. Configuration Figure 3-11. Dialup Options Menu Primary and Secondary Phone Numbers When the T3SU 300 dials out to send a trap, it first dials the . If the call is unsuccessful, it tries the RIMARY HONE UMBER . Attempts between the two numbers...
  • Page 66 The T3SU 300 waits the number of seconds entered in this field between redial attempts. Dialout On Trap Enable or disable the T3SU 300’s ability to dial out to report traps. When configured for D VT100 , the unit reports error...

  • Page 67: Utilities

    (including self-test results), revert to default configuration settings, update the flash software of the local unit, update the flash software of the far-end T3SU 300, or reset the unit. The S menu is shown in Figure 3-12 on page 68.

  • Page 68: Save Configuration

    SAVE CONFIGURATION The S selection commits the current ONFIGURATION configuration changes to nonvolatile memory. If this option is not selected after making changes to the configuration, the unit reverts to its previous configuration when powered down. T3SU 300 User Manual 61202217L1-1B...

  • Page 69: Network Port

    Information for the network port and the DTE ports is provided. The S menu is shown in Figure 4-1. TATUS Figure 4-1. Status Menu NETWORK PORT DS3 Framing The DS3 framing type is shown in this field. 61202217L1-1B T3SU 300 User Manual...

  • Page 70: Network State

    Chapter 4. Status Network State This field displays the current network state of the T3SU 300. Possible conditions are given in the following chart: Condition Description Normal The T3SU 300 is ready to pass data. Alarm The unit is currently receiving an alarm indication. See...

  • Page 71: Data Link State

    The unit detects an out of frame condition from the network. Idle The unit detects an idle sequence from the network. Service is immediately available for use. Eqpt Fail (SA) The network has signaled a service affecting equipment failure condition. 61202217L1-1B T3SU 300 User Manual...

  • Page 72: Dte Ports

    The network has signaled a non-service affecting (NSA) common equipment failure condition. Unknown The T3SU 300 is unable to determine the state of the network or the remote unit. DTE PORTS The following status information is available for DTE Ports 1-4.

  • Page 73: T1 Status

    The DSX-1 port detects an out of frame condition from the network. The DSX-1 port detects a yellow alarm condition. Blue The DSX-1 port detects a blue alarm condition (unframed all ones). The DSX-1 port is in test. 61202217L1-1B T3SU 300 User Manual...

  • Page 74: Bandwidth

    The Quad DSX-1 interface card is unable to lock on to the timing source. When a DSX-1 port is enabled but is not attached to a DTE device, the T3SU 300 will transmit an unframed all ones condition (blue alarm) to the remote site. Bandwidth Displays the amount of bandwidth being used by the port.

  • Page 75: Table 4-1. La And Lb Leads

    Condition TA (terminal available) Asserted by the DTE to indicate readiness to transmit data. CA (communications Asserted by the T3SU 300 to indicate readiness equipment available) to transmit data. LA (loopback circuit A) The condition reflected by this lead is dependent upon the LB lead.

  • Page 76: Ethernet Bridge Status

    Data set ready Local DTE port loopback Remote port payload loopback Test mode. Asserted by the T3SU 300 when either the network or port is being tested. Ethernet Bridge Status View the status of each of the four ports by selecting 1 B...
  • Page 77 This field displays the current speed of the individual Ethernet ports. The status messages are 10 B T and 100 B Duplex This field displays the current duplex mode of the individual Ethernet ports. The status messages are H and F UPLEX UPLEX 61202217L1-1B T3SU 300 User Manual...
  • Page 78 Chapter 4. Status T3SU 300 User Manual 61202217L1-1B...

  • Page 79: Viewing Statistical Information

    24 hours. Also, a cumulative alarm count is given. This count continues indefinitely until reset by the user. If the option is disabled, remote statistics are not available ( -> -> DS3 N ONFIGURATION ETWORK 61202217L1-1B T3SU 300 User Manual...

  • Page 80: Alarm History

    Figure 5-1. Main Local Statistics Menu Screen Alarm History The T3SU 300 keeps track of yellow, blue, and red alarms for the near end. View alarm history information in one of the three time period selections, or view a cumulative alarm count. Information in these fields is for the given time period (if any) since the last reset.

  • Page 81: Figure 5-2. Current Alarm Count Screen

    When a < or > symbol appears in the upper corner of the screen, you can use the arrow keys on your keyboard to scroll right or left to view additional information (see Figure 5-4 on page 82). 61202217L1-1B T3SU 300 User Manual...

  • Page 82: Performance Parameters

    Figure 5-6 on page 84). Unavailable Seconds (UAS) Time in seconds that the network port is unavailable for data delivery. This means that the T3 link is down or in test, or that the signaling state is down. T3SU 300 User Manual 61202217L1-1B...

  • Page 83: Figure 5-5. Network Statistics Menu For Current 15-Minute Interval

    UASs (unavailable seconds) are counted. P-Bit Severely Errored Seconds (PSES) Number of seconds with 44 or more PCVs, one or more out of frame defects, or a detected incoming AIS. This count is not incremented when UASs are counted. 61202217L1-1B T3SU 300 User Manual...

  • Page 84: Figure 5-6. Network Port Statistics 24-Hour History Screen

    Number of seconds with 44 or more CCVs, one or more out of frame defects, or a detected incoming AIS. This count is not incremented when UASs are counted. F-Bit Errors (FBE) Number of times an F-bit framing error has occurred. T3SU 300 User Manual 61202217L1-1B...

  • Page 85: Other Statistics

    90 for examples of the statistical data for the card. A description of each counter is listed in Table 5-1 on page 82, Table 5-2 on page 5-88, and Table 5-3 on page 5-90. 61202217L1-1B T3SU 300 User Manual...

  • Page 86: Figure 5-8. Ethernet Bridge Statistics Menu Screen 1

    TX_UNICAST_ The number of good packets transmitted by a port that PKTS are addressed to a unicast address. The number of collisions experienced by a port during COLLISIONS packet transmissions. T3SU 300 User Manual 61202217L1-1B...

  • Page 87: Table 5-1. Ethernet Bridge Statistics Counters Screen 1

    TX_FRAME_ The number of valid packets received that are IN_DISC discarded by the forwarding process due to lack of space on an output queue. TX_PAUSE_ The number of PAUSE frames transmitted by a port. PKTS 61202217L1-1B T3SU 300 User Manual...

  • Page 88: Figure 5-9. Ethernet Bridge Statistics Menu Screen 2

    The number of packets received by a port that have a length ALIGNMENT_ (excluding framing bits, but including FCS) between 64 and 1522 ERRORS bytes, inclusive, and have a bad FCS with an integral number of bytes. T3SU 300 User Manual 61202217L1-1B...

  • Page 89: Table 5-2. Ethernet Bridge Statistics Counters Screen 2

    Note the RX_OVERSIZE_PKTS counter alone is incremented for packets in the range 1523-1536 bytes inclusive; whereas, both this counter and the RX_OVERSIZE_PKTS counter are incremented for packets of 1537 bytes and higher. 61202217L1-1B T3SU 300 User Manual...

  • Page 90: Figure 5-10. Ethernet Bridge Statistics Menu Screen 3

    The number of packets (including error packets) that are 256T0511_ between 256 and 511 bytes long. OCTETS PKTS_ The number of packets (including error packets) that are 512TO1023_ between 512 and 1023 bytes long. OCTETS T3SU 300 User Manual 61202217L1-1B...

  • Page 91: Table 5-3. Ethernet Bridge Statistics Counters Screen 3

    Chapter 5. Statistics Table 5-3. Ethernet Bridge Statistics Counters Screen 3 (Continued) Counter Name Description PKTS_ The number of packets (including error packets) that are 1024TO1522_ between 1024 and 1522 bytes long. OCTETS 61202217L1-1B T3SU 300 User Manual...
  • Page 92 Chapter 5. Statistics T3SU 300 User Manual 61202217L1-1B...
  • Page 93 The D menu allows you to initiate loopback and BERT IAGNOSTICS tests from the T3SU 300. Figure 6-1 on page 94 shows the main menu. Perform tests for the entire DS3 or for an IAGNOSTICS individual DTE port. If a Quad DSX-1 card is installed, activate loopback tests for an entire card (all four DSX-1s) or for an individual DSX-1 port.

  • Page 94: Figure 6-1. Diagnostics Main Menu

    Chapter 6. Diagnostics Loopback tests may be performed simultaneously on all four DTE ports. Figure 6-1. Diagnostics Main Menu T3SU 300 User Manual 61202217L1-1B...

  • Page 95: Ds3

    See Figure 6-3 on page 96 for a block diagram illustrating the loopback point and the signal paths for this test. This test does not interrupt data flow from the network to the DTE, but it does block all DTE-to-network data. 61202217L1-1B T3SU 300 User Manual...

  • Page 96: Figure 6-3. Ds3 Payload Loopback Test

    Line Loopback This test allows the loop interface (LINE) section of the local T3SU 300 to be tested from the remote T3SU 300 over the actual T3 circuit. Testing from the remote end of the circuit is performed by using a 511 test pattern or DTE data generated by the remote host.

  • Page 97: Dte Ports 1-4

    See the following section for the testing options available for the HSSI and V.35 ports. See the section Quad DSX-1 Diagnostic Options on page 101 for testing options available for the DSX-1 ports. 61202217L1-1B T3SU 300 User Manual...

  • Page 98: Figure 6-5. Hssi Or V.35 Port Diagnostics Menu

    Perform this test to verify the integrity of the portion of the DS3 link connecting the selected port of the T3SU 300 and the remote DTE. This test is non- intrusive to the three other ports. See Figure 6-6 on page 99.

  • Page 99: Figure 6-6. Payload Loopback Test

    DTE Loopback This test is used to verify proper operation of the link between the T3SU 300 and the terminal equipment. During this test, all data sent by the terminal equipment is looped back to the terminal equipment. A block diagram illustrating the loopback point and the signal path is shown in Figure 6-8 on page 100.

  • Page 100: Figure 6-8. Dte Loopback Test

    Perform this test to verify the integrity of the portion of the DS3 link connecting the local DTE and the selected port of the remote T3SU 300. All other ports on both the local and remote units are unaffected.

  • Page 101: Figure 6-10. Quad Dsx-1 Diagnostics Menu

    Chapter 6. Diagnostics the remote T3SU 300 are the same as the Payload Loopback test for the local T3SU 300 (shown in Figure 6-6 on page 99). Quad DSX-1 Diagnostic Options The menu in Figure 6-10 appears if the selected port is a Quad DSX-1.

  • Page 102: Figure 6-11. Dsx-1 Payload Loopback Test

    During this test, all information from the network side (DS3) for the selected DSX-1 interface is looped back towards the network. See Figure 6-12 for an illustration of this test. T3SU 300 Quad DSX-1 DSX-1 DS3 MUX Figure 6-12. Framer Loopback Test T3SU 300 User Manual 61202217L1-1B...

  • Page 103: Figure 6-13. Dsx-1 Local Loopback Test

    During this test, all information on the selected DSX-1 interface, including framing, is looped back towards the DTE. See Figure 6-14 for an illustration of this test. T3SU 300 Quad DSX-1 DSX-1 DS3 MUX Figure 6-14. Line Loopback Test 61202217L1-1B T3SU 300 User Manual...

  • Page 104: Figure 6-15. Payload Loopback Test

    All other ports are unaffected. See Figure 6-15 for an illustration of this test. T3SU 300 T3SU 300 Quad DSX-1 DSX-1 DS3 MUX DS3 MUX Local port in Far-end unit Payload Loopback in Data Mode Figure 6-15. Payload Loopback Test T3SU 300 User Manual 61202217L1-1B...

  • Page 105: Figure 6-16. Dte Loopback Test

    DTE Loopback During this test, the combined information from the four DSX-1 interfaces is locally looped at the multiplexer of the T3SU 300 back towards the Quad DSX-1 interface card. The end result of this test is a loopback of all DSX-1 interfaces towards the DTE. See Figure 6-16 for an illustration of this test.

  • Page 106: Figure 6-17. Payload And Dte Loopback Test

    See Figure 6-18 for an illustration of this test. T3SU 300 T3SU 300 Quad DSX-1 DSX-1 DS3 MUX DS3 MUX Far-end unit responds Local port in Remote to port loopback Port Payload Loopback Figure 6-18. DSX-1 Payload Loopback Test T3SU 300 User Manual 61202217L1-1B...

  • Page 107: Bert Configuration

    2^23-1 The test pattern is used to independently test the operation of the framing circuitry and the network interface of the T3SU 300. Instead of using data from the host, this test uses data generated by the T3SU 300’s internal test pattern generator and detector.
  • Page 108 BERT pattern. Errors Displays the number of BERT errors received by the T3SU 300 since the last reset. Current Err/Sec Displays the number of BERT errors received by the unit in the last second.

  • Page 109: Single Port Full T3 Bandwidth

    44.2 Mbps data over unchannelized T3 circuits. In the application shown in Figure 7-1, the T3SU 300 provides network connectivity for a router running at 44.2 Mbps. The data is frame relay and the unit is SNMP-managed via the local Ethernet.

  • Page 110: Point-To-Point Multiport Application

    When networking requirements call for sharing the bandwidth of a point-to-point T3 circuit, additional data ports can be installed into the T3SU 300 for multiport operation. The T3SU 300 supports up to three port option cards (Quad DSX-1, V.35, or HSSI). These option cards are hot swappable and can be field installed.

  • Page 111: Figure 7-2. Multiport Application

    (using the HSSI ports), as well as the V.35 data connection requirements of the video conferencing unit and the main frame. The bandwidth is split by the T3SU 300 to provide 18 Mbps for each router, 1.5 Mbps for the video conference units, and 6 Mbps for the main frames.

  • Page 112: Fractional T3 Carrier Application

    FRACTIONAL T3 CARRIER APPLICATION When network providers want to provide service at rates less than full T3, T3SU 300 units can be used in pairs for deploying sub-T3 rate services. In this application example (shown in Figure 7-3 on page 113), a carrier provides fractional T3 access at 8 Mbps for internet connectivity.

  • Page 113: Figure 7-3. Fractional T3 Application

    Nothing required. Remote unit can System be managed using the local T3SU Management Subnet Mask - 255.255.255.0 300. Gateway IP Address - 12.6.12.1 IP Security - Disabled Trap IP Address - 12.6.12.10 Management Port - LAN 61202217L1-1B T3SU 300 User Manual...

  • Page 114: Remote Snmp Management Application

    Chapter 7. Applications REMOTE SNMP MANAGEMENT APPLICATION A remote T3SU 300 can be managed by a local management station if the remote unit is assigned its own IP address. This address must be assigned at both the near and far ends. Also, the D option must be enabled on both units.

  • Page 115: Voice Application

    Port State - Enabled Port State - Enabled DTE 1 (HSSI) Nx75k blocks - 240 Nx75k blocks - 240 DTE 2 (HSSI) Port State - Enabled Port State - Enabled Nx75k blocks - 80 Nx75k blocks - 80 61202217L1-1B T3SU 300 User Manual...

  • Page 116: Quad Dsx

    Nothing required. Remote unit can be managed using the local Management Subnet Mask - 255.255.255.0 T3SU 300. Gateway IP Address - 10.4.10.1 IP Security - Disabled Trap IP Address - 10.4.10.10 Management Port - LAN T3SU 300 User Manual 61202217L1-1B...

  • Page 117: Appendix A Pinouts

    Pinouts Appendix A The following tables give the pin assignments for the connectors located on the T3SU 300. For more information on these connectors, see Chapter 2, Installation and Operation, on page 31. Table A-1. Control Port Pin Assignments RJ Pin#...

  • Page 118: Table A-2. Hssi Interface Pin Assignments

    Terminal Timing (TT) Loopback Circuit A (LA) Send Data (SD) Loopback Circuit B (LB) Signal Ground (SG) 14-18 39-43 Five Ancillary to DCE Signal Ground (SG) 20-23 45-48 Five Ancillary from Test Mode (TM) Signal Ground (SG) T3SU 300 User Manual 61202217L1-1B...

  • Page 119: Table A-3. Lan Port/Ethernet Bridge Pin Assignments

    Description Protective Ground (PG) Signal Ground (SG) Request to Send (RTS) Clear to Send (CTS) Data Set Ready Received Line Signal Detector (CD) – Data Terminal Ready (DTR) – not used – Local Loopback (LL) 61202217L1-1B T3SU 300 User Manual...

  • Page 120: Table A-5. Quad Dsx-1 Interface Card Pin Assignments

    Table A-5. Quad DSX-1 Interface Card Pin Assignments Name Description R1 TXDATA-RING Send data toward DTE T1 TXDATA-TIP Send data toward DTE UNUSED not used R RXDATA-RING Receive data from DTE T RXDATA-TIP Receive data from DTE 6,7,8 UNUSED not used T3SU 300 User Manual 61202217L1-1B...

  • Page 121: Appendix B Specifications Summary

    Specifications Summary Appendix B SPECIFICATIONS AND FEATURES This section describes the standard specifications and features incorporated in the T3SU 300. Network Interface Clear channel, non-channelized DS3 Line length: short (less than 225 feet) and long (greater than 225 feet) Framing format: M13 and C-bit parity Line rate: 44.736 Mbps...
