Back to Contents Page
Front Bezel
Dell™ Inspiron™ 535s/537s/545s/546s Service Manual
Removing the Front Bezel
Replacing the Front Bezel
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
WARNING:
To guard against electrical shock, always unplug your computer from the electrical outlet before removing the cover.
WARNING:
Do not operate your equipment with any cover(s) (including computer covers, bezels, filler brackets, front-panel inserts, etc.)
removed.
Removing the Front Bezel
1. Follow the procedures in
Before You
2. Remove the computer cover (see
1 bezel inserts (3) 2 bezel clamps (3)
3 bezel grips (3)
4 bezel
3. Grasp and lift the bezel grips one at a time to release it from the front panel.
4. Rotate and pull the bezel away from the front of the computer to release the bezel clamps from the bezel inserts.
5. Set aside the bezel in a secure location.
Replacing the Front Bezel
1. Align and insert the bezel clamps into the bezel inserts.
2. Rotate the bezel towards the computer until the bezel grips snap into place.
3. Replace the computer cover (see
Back to Contents Page
Begin.
Removing the Computer
Cover).
Replacing the Computer
Cover).
