System Setup
Dell™ Inspiron™ 535s/537s/545s/546s Service Manual
Overview
Entering System Setup
Clearing Forgotten Passwords
Clearing CMOS Settings
Flashing the BIOS
Overview
Use System Setup:
To change the system configuration information after you add, change, or remove any hardware in your computer.
l
To set or change a user-selectable option such as the user password.
l
To read the current amount of memory or set the type of hard drive installed.
l
Before you use System Setup, it is recommended that you write down the system setup screen information for future reference.
CAUTION: Do not change the settings in system setup unless you are an expert computer user. Certain changes can cause your computer to work
incorrectly.
Entering System Setup
1. Turn on (or restart) your computer.
2. When the DELL logo appears, press <F2> immediately.
NOTE: Keyboard failure may result when a key on the keyboard is held down for extended periods of time. To avoid possible keyboard failure,
press and release <F2> in even intervals until the system setup screen appears.
If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft® Windows® desktop, then shut down your
computer and try again.

System Setup Screens

Options List — This field appears on the top of the system setup window. The tabbed options contain features that define the configuration of your computer,
including installed hardware, power conservation, and security features.
Option Field — This field contains information about each option. In this field you can view your current settings and make changes to your settings. Use the
right- and left-arrow keys to highlight an option. Press <Enter> to make that selection active.
Help Field — This field provides context sensitive help based on the options selected.
Key Functions — This field appears below the Option Field and lists keys and their functions within the active system setup field.

System Setup Options

NOTE: Depending on your computer and installed devices, the items listed in this section may not appear, or may not appear exactly as listed.
Inspiron 535s/537s
System Info
Displays the computer model number.
System
Shows the BIOS version number and date information.
BIOS Info
Displays the asset tag for the computer, if present.
Asset Tag
Displays the service tag of the computer.
Service Tag
Displays the processor type.
Processor Type
Displays the amount of processor Level 2 cache.
Processor Level 2
