1 screw 2 chassis fan
Replacing the Chassis Fan
1. Follow the procedures in
Before You
2. Align the top and bottom chassis fan tabs with the projections in the chassis, and slide the chassis fan towards the back of the computer.
1 bottom tab 2 top tabs (2) 3 screw
3. Replace the screw that secures the chassis fan.
4. Connect the chassis fan cable to the chassis fan connector on the system board (see
5. Replace the computer cover (see
6. Connect your computer and devices to an electrical outlet, and turn them on.
Back to Contents Page
Begin.
Replacing the Computer
Cover).
System Board
Components).
