Replacing An Optical Drive - Dell Inspiron 535s Service Manual

1 data cable 2 power cable 3 securing tab
4 shoulder screws (2) 5 optical drive
6. Replace the front bezel (see
7. Replace the computer cover (see
8. Connect your computer and devices to electrical outlets, and then turn them on.
9. Configure the drives in system setup (see
Replacing an Optical Drive
1. Follow the procedures in Before You
2. Remove the computer cover (see
3. Remove the front bezel (see
4. If not present, attach the two shoulder screws to the optical drive.
5. Gently slide the optical drive into place.
6. Connect the power and data cables to the optical drive.
7. Connect the data cable to the system board connector.
NOTE: The location of the connectors may vary depending on your system type. For more information, see
8. Replace the front bezel (see
9. Replace the computer cover (see
10. Connect your computer and devices to their electrical outlets, and turn them on.
See the documentation that came with the drive for instructions on installing any software required for drive operation.
11. Check the System Setup for drive configuration changes (see
Back to Contents Page
Replacing the Front Bezel).
Replacing the Computer Cover).
System Setup Options).
Begin.
Removing the Computer Cover).
Removing the Front Bezel).
Replacing the Front Bezel).
Replacing the Computer Cover).
Entering System
System Board
Setup).
Components.
