Appendix C. Cabinet Configurations
Unpacking the Deskside Cabinet
Unpacking the Deskside Cabinet
To unpack the deskside cabinet, perform the following steps:
1.
Cut the strapping bands, and slide the fully-packaged product off of the pallet as shown in
View 1
2.
Remove the four plastic clips and lift the carton off of the cabinet. Also, remove the accessory tray and
then remove the top, front, and rear foam cushioning as shown in
3.
Lift one edge of the cabinet, and then remove the bottom cushion from the opposite side. Repeat this
step for the other side of the cabinet. See
4.
Roll the cabinet off of the bottom tray as shown in
224
Figure
Figure
38, View 3
Figure
38, View 4
Figure
38,
38, View 2.
