Appendix C Pin Assignment
C.17

PJ6003 Speaker Connector (right) (3-pin)

Table C-17 Speaker connector (right) pin assignment (3-pin)
Pin No. Signal name
1 SPKOTR-EXN
3 SPKOTR-EXP
C.18

PJ7000 CD key I/F connector (18-pin)

Pin No. Signal name
1 M5V
3 CDMODE-E5N
5 CDPREV-S5N
7 CDPLAY-S5N
9 GND
11 BAT1B2-M5N
13 PWLE02-M5N
15 M5V
17 DCINB2-M5N
Satellite M30-35 Maintenance Manual (960-455)
I/O Pin No.
O
O
Table C-18 CD key I/F connector (18-pin)
I/O Pin No.
-
O
I
I
-
O
O
-
O
Signal name
2 N.C
Signal name
2 MP3MOD-E5N
4 MODBTN-S3N
6 CDNEXT-S5N
8 CDSTOP-S5N
10 BAT102-M5N
12 M5V
14 PWLEB2-M5N
16 DCINO2-M5N
18 M5V
Appendices
I/O
-
I/O
O
I
I
I
O
-
O
O
-
C-15
