TOSHIBA
Satellite® M35 Special Edition
Feature Model(s):
Satellite M35-S456
Pentium M 735/15.4"WXGA CSV/512MB/80GB/DVD SuperMulti/ Mdm/LAN/Wi-Fi/WinXP Home
Satellite M35-S4561
Pentium M 735/15.4"WXGA CSV/512MB/80GB/DVD SuperMulti/ Mdm/LAN/Wi-Fi/WinXP Pro
Product Highlights
Performance
•
Intel® Centrino™ mobile technology
Intel® Pentium® M processor 735
o
Intel® 855PM chipset
o
Intel® PRO/Wireless 2200BG
o
•
512MB of Main Memory
Slim Design
•
80GB** hard disk drive
•
DVD SuperMulti drive
Great Features
•
15.4" WXGA active-matrix screen display*** with TruBrite™
Screen Technology
•
High-Quality Video Engine
•
NVIDIA® GeForce™ FX Go5200 graphics controller; 64MB DDR
SDRAM external video memory
•
Composite Monitor-IN port
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
•
Integrated 802.11b/g Wireless LAN module
System Characteristics
Operating System
•
Microsoft® Windows XP Home pre-installed (M35-S456)
•
Microsoft® Windows XP Pro pre-installed (M35-S4561)
CPU/Chipset information
•
Intel® Pentium® M processor 735*
(1.70GHz, 2MB L2 Cache, 400MHz Front Side Bus)
o
•
Intel® 855PM Chipset
•
Intel® PRO/Wireless 2200BG
Memory
•
512MB DDR SDRAM (Both slots may be occupied at time of
purchase) , expandable to 2048MB (2 DIMM)
•
Optional available expansion memory modules:
256MB/512/1028MB, SODIMM: Memory compatible with PC2100
DDR266 and PC2700 DDR333
Data/Address Bus Width: 64bit/32bit
Mass Storage - HDD/Optical Drive
•
Primary Hard Disk Drive: 80GB** hard disk drive, Enhanced
IDE (ATA-5) interface, 4200rpm drive rotation; 9.5mm height,
0.2lbs, Service Removable
•
DVD Super Multi drive: 12.7mm, Enhanced IDE Interface;
service removable
Maximum speed: CD-ROM(24x), CD-R(16x), CD-RW(8x), DVD-
ROM(8x), DVD-R(4x), DVD-RW(2x), DVD+R(2.4x),
DVD+RW(2.4x), DVD-RAM(2x)
Compatibility: CD-ROM(read), CD-R(read/write), CD-
RW(read/write), DVD-ROM(read), DVD-R(read/write), DVD-
RW(read/re-write), DVD+R(read/write), DVD+RW(read/write),
DVD-RAM(read/re-write)
Graphics/Video
•
15.4" WXGA*** active-matrix display with TruBrite Screen
Technology; internal display supports up to 16M colors at 1280 x
800 internal LCD resolution
•
NVIDIA® GeForce™ FX Go5200 graphics controller with 64MB
DDR SDRAM external video memory, AGP 4X interface
•
Supported external Resolution/color/maximum external
refresh rate:
• 640 x 480
16bit/32bit
• 800 x 600
16bit/32bit
• 1024 x 768
16bit/32bit
• 1280 x 1024
16bit/32bit
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
©2004 Toshiba America Information Systems, Inc. All rights reserved
.Satellite_M35-S456
60/75/85/100Hz
60/75/85/100Hz
60/75/85/100Hz
60/75/85/100Hz
Created on 6/7/2004 3:31 PM
• 1280 x 800
16bit/32bit
• 1600 x 1200;
16bit/32bit
• 1920 x 1440;
16bit/32bit
• 2048 x 1536;
16bit/32bit
•
Brightness NIT (cd/m
•
Level 8;
220
•
Level 7;
200
•
Level 6;
165
•
Level 5;
125
•
Level 4;
90
•
Level 3;
50
•
Level 2;
20
•
Level 1;
10
•
Contrast Ratio: 300:1
•
High quality Video Engine (HVE):
Black extension, White extension, Sharpness, LCD
o
Over Drive, Edge Enhancement (only Monitor-IN), 3D-
Comb filter (only Monitor-IN), Noise Reduction (only
Monitor-IN), 10-bit AD Converter (only Monitor-IN),
NTSC/PAL Video decoder (use for Monitor-IN)
Sound
•
STAC9750TG Codec Chip; Software Sound; 16-bit stereo, full
duplex support, AC'97 Rev2.2 compatible
•
Built-in harman/kardon stereo speakers
•
Built-in Microphone (monaural); Direct 3D Sound (supported by
driver), DirectSound (supported by driver) and DirectMusic
(supported by driver); MIDI (playback) Support; Sound Volume
(by Dial);
•
Ports: External Microphone port (monaural), Headphone port
(stereo), Line-in port (shared with Monitor-IN)
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® keys support; HotKey
function; Integrated TouchPad pointing device with Scroll function
(by software on Touchpad)
•
CD Control Function: Mode Control Switch (CD/DVD/Digital
Audio), Skip to Previous Track, Play, Stop, Skip to Next Track
•
Express Media Player button
•
TV-out button
•
Monitor-IN button
Expandability
•
2 Memory slots – Both slots may be occupied at time of purchase
•
1 PC Card slot supports 1 Type II PC Card
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible transmission
rates during download. Actual data transmission speeds will vary depending on line
conditions.
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless LAN (Intel 802.11b/g)
Ports
•
Composite In (Monitor-IN) port
•
RGB (monitor) port
•
4 Universal Serial Bus ports (USB)
•
TV-Out (S-Video)
•
RJ-45 LAN Port
•
RJ-11 modem port
•
i.LINK™ (IEEE 1394)
•
Secure Digital® (SD) card slot
•
Line-In port
Physical Description
•
Dimensions (LxWxH): 14.2" x 10.6" x 1.4"
•
Weight: 6.17 lbs****
•
LED Indicators: Power (common with Power/System Sleep
Rev. 1.0
Part Numbers
PSM33U-001001
PSM33U-001003
60/75/85/100Hz
60/75/85/100Hz
60/75Hz
60/75Hz
2
)
Page 1 of 4
