Table 13-20
Class: SMX_MemoryRedundancySet
Property name
OtherTypeOfSet
LoadBalanceAlgorithm
RedundancyStatus
OperatingSpeed
AvailableMemory
TotalMemory
CurrentConfiguration
Property implementation
OtherTypeOfSet[0] contains the type of redundancy
when the property TypeOfSet[0] = 1 (Other). In this
case, the property will contain the value Advanced ECC
or Lockstep, otherwise the property is not populated.
2 (No Load Balancing)
The current memory redundancy status as follows:
•
2 (Fully Redundant)—System is operating properly
in the Advanced Memory Protection mode given in
the TargetConfiguration property.
•
3 (Degraded Redundancy)—Degraded
Redundancy can occur in either of two conditions:
○ System is not operating in the
TargetConfiguration mode (the
CurrentConfiguration mode does not match the
TargetConfiguration mode).
○
System is operating in the TargetConfiguration
mode but memory module(s) have correctable
errors exceeding the condition for pre-failure
warranty.
HP_MemoryRedundancySet
The current operating speed of the Advanced Memory
Protection subsystem in MHz
The size of the memory as seen by the operating
system in MB
Total size of memory as seen by the operating system
and memory used for Advanced Memory Protection
configurations in MB
The current operating mode of the Advanced Memory
Protection system. The value in this property
corresponds to the value populated in the property
TypeOfSet[0].
CurrentConfiguration is one of the following:
•
Advanced ECC, when the system is operating in
Advanced ECC mode
•
RAID, when the system is operating in RAID (XOR)
mode
•
Mirrored, when the system is operating in Mirrored
mode
•
Online Spare, when the system is operating in
Online Spare mode
•
Lockstep, when the system is operating in Lockstep
mode
