SMX_MemberOfFanCollection

9-3-6
SMX_MemberOfFanCollection is used to represent an association between HP_Fan and
HP_FanCollection.
Table 9-7
Class: SMX_MemberOfCoolingCollection
Property name
Collection
Member

SMX_HostedFanCollection

9-3-7
SMX_HostedFanCollection is used to represent an association between HP_FanCollection and the
computer system that contains this collection.
Table 9-8
Class: SMX_HostedFanCollection
Property name
Antecedent
Dependent

SMX_SystemFan

9-3-8
SMX_SystemFan is used to represent an association between HP_Fan and the computer system that
contains this fan.
Table 9-9
Class: SMX_SystemFan
Property name
GroupComponent
PartComponent

SMX_FanLocation

9-3-9
HP_FanLocation is used to model fan locations on Servers.
Table 9-10
Class: SMX_FanLocation
Property name
Caption
Property implementation
References HP_FanCollection
References HP_Fan
Property implementation
References HP_ComputerSystem
References HP_FanCollection
Property implementation
References HP_ComputerSystem
References HP_Fan
Property implementation
CIM_ManagedElement
Short description of the fan location including the name
displayed by the MP or iLO.
For example: Fan 1 at CabinetFan=01
System Fan 273
