Table 9-12
Class: SMX_FanModule
Property name
Caption
Description
ElementName
OperationalStatus[0]
StatusDescriptions[0]
HealthState
Name
CreationClassName
Tag
RemovalConditions
PackageType

SMX_SystemPhysicalFan

9-3-12
SMX_SystemPhysicalFan class implements the HP_SystemPhysicalFan class and association the
HP_ComputerSystemChassis instance with HP_FanModule.
Table 9-13
Class: SMX_SystemPhysicalFan
Property name
Property implementation
Short description of this fan from the name displayed
by the MP or iLO and the location.
For example: Fan 1 at CabinetFan=01
Fan n provides cooling for FanType. StatusDescription
where n represents the number of the fan instance,
FanType represents the corresponding string value of
the FanType enumeration and StatusDescription
represents the value of StatusDescriptions[0]
Short description of this fan from the name displayed
by the MP or iLO and the location.
For example: Fan 1 at CabinetFan=01
CIM_Managed SystemElement
2 (OK) – if fan is operating properly
3(Degraded) – if fan is degraded
6 (Error) – if fan has failed
Fan is operating properly – if OperationalStatus[0] is 2
(OK)
Fan is degraded – if OpertionalStatus(0) is 3
(Dedgraded)
Fan has failed – if OperationalStatus is 6 (Error)
5 (OK) – if fan is operating properly;
10(Degraded) if fan is degraded
20 (Major Failure) – if fan has failed
Fan n, where n represents the number of the fan
instance
CIM_PhysicalElement
SMX_FanModule
Unique identifier for this fan instance
CIM_PhysicalPackage
0 (Unknown)
3 (Removable when off)
4 (Removable when on or off)
7 (Fan)
Property implementation
System Fan 275
