Intel® Server Board X38ML
select the menus listed. Some menus are hidden and become available by scrolling to the left or
right of the selections.
4.3.2

BIOS Setup Screens

The following sections describe the screens available for the configuration of a server platform.
In these sections, tables are used to describe the contents of each screen. These tables follow
these guidelines:
The text and values in the Setup Item, Options, and Help columns in the tables are
displayed on the BIOS Setup screens.
Bold text in the Options column of the tables indicates default values. These values are
not displayed in bold on the setup screen. The bold text in this document is to serve as a
reference point.
The Comments column provides additional information where it may be helpful. This
information does not display in the BIOS Setup screens.
Information in the screen shots that is enclosed in brackets (< >) indicates text that
varies, depending on the option(s) installed. For example, <Current Date> is replaced by
the actual current date.
Information that is enclosed in square brackets ([ ]) in the tables indicates areas where
the user needs to type in text instead of selecting from a provided option.
Whenever information is changed (except Date and Time), the systems requires a save
and reboot to take place. Pressing <ESC> discards the changes and boots the system
according to the boot order set from the last boot.
4.3.2.1 Main Screen
The Main screen is the screen that is first displays when the BIOS Setup is entered, unless an
error has occurred. If an error occurred, the Error Manager screen displays instead.
