Functional Architecture
The SPI Flash Memory device is an Atmel* AT26DF321 - a 32 mbit, 2.7 to 3.6 volt serial
interface FLASH memory, Intel part number D64145-001/D64145-002. This device is installed
directly onto the server board without the use of sockets.
3.2.2.12 Manageability
®
The Intel ICH9 integrates several functions to manage the system and lower the total cost of
ownership (TCO) of the system. These system management functions report errors, diagnose
the system, and recover from system lockups without the aid of an external microcontroller.
The management engine includes the following features:
TCO timer to detect system locks
Process Present Indicator to determine if the processor fetches the first instruction after
reset
ECC Error reporting from the host controller
Function Disable to prevent a disabled function from generating interrupts and power
management events
Intruder Detect input for system cases
3.3

Integrated Baseboard Management Controller

A ServerEngines* Baseboard Management Controller (Integrated BMC) is integrated onto the
server board. This integrates the baseboard management controller (BMC and KVMS
subsystem), graphics controller (graphics subsystem), and Super I/O interface (Super I/O
subsystem). The Intel

Functionality Overview

3.3.1
Baseboard management controller
IPMI 2.0 compliant
-
Integrated 250 MHz 32-bit ARM9 processor
-
2
Six I C SMBus Modules with master-slave support
-
Two independent 10/100 Ethernet controllers with RMII support
-
LPC master interface for non-volatile code storage
-
SPI Flash interface
-
Three UART for ICMB support
-
DDR2 16-bit up to 667 MHz memory interface
-
Sixteen mailbox registers for communication between the host and the BMC
-
Watchdog timer
-
Three general purpose timers
-
Dedicated real-time clock for BMC
-
Up to 16 direct and 64 serial GPIO ports
-
Ability to maintain text and graphics controller history
-
Twelve 10-bit analog to digital converters
-
12
®
Server Board XM38ML does not support remote KVMS features.
